Ultimate Glider WOCD
Field Applied Instructions
Failure to follow these instructions may result in the win-
dow opening control devices (WOCDs) being ineffective
in controlling the window opening.
A copy of the safety information shall be provided to the
owner of the building in which the window opening con-
trol device (WOCD) is installed and to the occupant in
the dwelling where the opening control device is in-
stalled (or is to be installed).
NOTE: This instruction is for Ultimate Glider (UGL).
When installed and used as directed, the Window
Opening Control Device meets the requirements of
ASTM F2090-17.
Building and fire codes shall be consulted before install-
ing WOCDs. Contact local building code department or
fire department for specific applicable codes and install
in accordance.
Follow manufacturer's assembly and installation in-
structions carefully. Failure to do so may result in acci-
dental window falls.
WA RNING!
Possible Fall Hazard
• Young children may fall out of the window if the
window opening control device (WOCD) is not
installed correctly.
• Install the device so that a rigid 4.0-in. (102mm)
diameter sphere does not pass through any space
at the lowest opening portion in the window
opening after the WOCD is in place.
• Young children may fall out of the window if all
installation instructions are not followed.
• Use recommended materials and techniques.
• Make sure that the WOCD is securely installed in
accordance with manufacturer's instructions.
• Make sure that the window frame is in good
condition.
NOTE: Once installation of unit is complete, check
WOCD for proper operation. When the sash is closed
and locked, the WOCD should automatically engage.
NOTE: Available on all 2-panel and 3-panel sizes. Not
available for OXXO units.
Required Tools:
• Phillips screwdriver (No. 2)
• Clamp
• WOCD Stile Jig (UGL)
• WOCD Check Rail Jig (UGL)
• 1/4" ID, 5/16" OD Router Guide
• Router Lock Nut
• Router
• 1/4" Dia. Router Bit for Wood
• 1/4" Dia. Router Bit for Fiberglass
• Two #7 x 7/8" screws
• Drill with 7/64" Drill Bit
• Vacuum
Parts needed or to be replaced:
• If the top or bottom sash is damaged, contact
Customer Support, it may need to be replaced with
a sash with factory-applied WOCD components.
For kit details, refer to Table 1.
4/27/20
19916116
