Summary of Contents for CityGrow Systems CG102IO-MD
Page 1
CG102IO-MD I/O M IRELESS ODULE ANUAL CG101IO-MD ERSION 13 F , 2020 EBRUARY Disclaimers and Copyright Nothing contained in this publication is to be construed as granting any right, by implication or otherwise, for the manufacture, sale, or use in connection with any method, apparatus, or product covered by letters patent, or as insuring anyone against liability for infringement of letters patent.
Page 2
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...
Table of content Introduction ....................1 Understanding the product ................2 Dimension ....................3 Wiring......................4 Installation ....................5 Adding the product to your Home Wireless ZigBee Network ......7 Specification ....................8...
1. Introduction Thank you for choosing CityGrow’s product. The CG102IO-MD Wireless I/O Module is a third-party sensor input interface specially designed for CityGrow automation control system. Description ZigBee wireless remote control. Based on IEEE 802.15.4. 2.4GHz radio frequency. Support various types of sensor to trigger scene control.
4. Wiring Before getting started WARNING! It must be installed by a qualified electrician in accordance to all applicable regulations and building codes. Improper wiring can result in personal injury or damage to control units or other equipment. Always turn off circuit breaker or remove main fuse from power line before doing any work.
5. Installation Please follow the instructions to install the product. STEP 1: IMPORTANT! Turn off main power at the main switch board. STEP 2: Loosen the wire cover screw and remove the wire cover. Wire cover Wire cover screw...
Page 9
Load terminals at the back cabinet of the product. N, L Load, N Output Input STEP 4: The CG102IO-MD module is now powered up and the orange LED will be blinking. Press the Test Button to test the module.
6. Adding the product to your Home Wireless ZigBee Network STEP 1 Open the front cover, you will see an USB socket. STEP 2 Plug the CG101UTU cable into the USB port of the device, and connect the other end of the CG101UTU cable into the mini USB port of the CG101UTC cable.
7. Specification Item CG102IO-MD Wireless I/O Module Power supply AC 220V-240V, 50Hz Wireless communication ZigBee Sensor input 1 input for sensor Scene setting Support Maximum number of devices in each scene RF frequency 2.4GHZ RF control distance 100M (line of sight) Operational temperature 0°C to 40°C...
