Summary of Contents for Samlexpower PDS-10 V2.0
- Page 1 PIR DC-SWITCH DC Passive infra-red Detector Model No. PDS-10 V2.0 Owners Manual Please read this manual before operating your DETECTOR...
-
Page 2: Installation
Read the user manaul thoroughly before connecting the PDS10! DESCRIPTION The PDS10 (PDS) is a motion-activated switch for 12 V and 24 V systems. The switch uses a Passive Infrared (PIR) sensor. A 12 V or 24 V lamp or other load can be connected to the PDS’... -
Page 3: Wiring Diagram
WIRING DIAGRAM 1. INPUT (+) 2. INPUT (-) 3. LOAD (-) 4. LOAD (+) 5. STOP (+) 6. PROG/SWITCH (-) OPERATION The PDS switches the LOAD output if it detects motion or if the PROG/SWITCH input is briefly (<1 sec) connected to the negative (–) pole of the battery. The LOAD will be switched off with a delay once the PDS no longer detects motion and the PROG/ SWITCH input is no longer connected to the negative (–) pole of the battery. -
Page 4: Configuration Table
PROGRAMMING The PDS’ switch-off delay duration can be programmed by connecting the PROG/ SWITCH to the negative (-) pole of the battery. Once the connection has been established for ±15 seconds, the LED and the PDS output will flash once. The connection must then be broken. -
Page 5: General Technical Details
GENERAL TECHNICAL DETAILS Description Value Programmable switching time 10 seconds to 30 minutes Start-up time after overload 30 seconds Undervoltage delay 60 seconds Start-up delay ± 30 seconds Detection angle 60º (horizontal) – 60º (vertical) Detection distance (max) 5 meters Connector type screw Dimensions... - Page 6 www.samlex.com www.samlex-solar.com...
