Installation, Regulation and
Maintenance Instructions
Filter, Regulator & Filter Regulators
Series 12, 16 - 3/4", 1"NPT
SIL
IEC 61508
Safety Integrity Level
HOW TO ORDER
TYPE SIZE
04= 1/4" NPT
F= Filter
06= 3/8" NPT
FR= Filter Regulator
08= 1/2" NPT
R= Regulator
12= 3/4" NPT
16= 1" NPT
24= 1" 1/2"NPT*
* only for filters
32= 2"NPT*
FR 06 3 1
FILTER ELEMENT
4= coalescing*
0= None
5= 3 micron
1= 5 micron
for 1/4", 3/8",
2= 25 micron
1/2"NPT
3= 40 micron
PRESSURE GAUGE
0= None
1S= AISI304 or AISI316 case
(SS316 connection)
1B= AISI304 case (brass connect.)
LABEL
Filter Regulator
a
35
14
FILTER ELEMENT 5M
AUTOMATIC DRAIN
IP66
RANGE ACCESSORIES
0=
0= None
2=
1= 0.2-2 bar
3=
2= 0.2-4 bar
4=
3= 0.4-8 bar
5=
4= 0.4-10 bar
5= 0.4-12 bar
6=
1S 5 6 SS
OPTION
00= None
05= No relieving
06= 1/4" gauge port
07= Automatic drain
56= No relieving
1/4" gauge port
57= No relieving
Automatic drain
67= 1/4" gauge port
Automatic drain
REPARING KIT
Contains: 8, 10, 14, 16, 17, 25, 27, 28, 31, 33, 38, 40, 41
+ for 5 micron FR & F: 21a, 21b
+ for 25 micron FR & F: 21b
For technical information refer to the
corresponding technical data sheet
Sitecna Srl a Socio Unico
Via G. Di Vittorio, 22
20068 Peschira Borromeo
Milano - ITALY
a
14
41
FILTER ELEMENT 25M
MANUAL DRAIN
None
SS bracket kit
Panel nut&handwheel
Customised Tag
SS bracket kit +
nut&handwheel
SS bracket kit+custom.Tag
Specials
FK 2 # #
DIAPHRAGM & SEALS MATERIAL
FK= FKM ( WT-25° +90°C )
NB= NBR ( WT-20° +80°C )
LT= EPDM ( WT-40° +80°C )
FL= Special compound (WT-55°+90°C)
HN= HNBR (WT -55 +90°C)
MATERIAL
SS= 316-316L Stainless steel
AL= Copper free aluminum alloy
Tel.
Filter
INOX VERSION
INOX VERSION
11b
35
FILTER ELEMENT 5M
AUTOMATIC DRAIN
PART LIST
Pos. Q.ty Q.ty Q.ty Descrizione/Description
R FR F
1 1 1 0 ADJUSTMENT SCREW
2 1 1 0 LOCK ADJUSTMENT NUT
3 1 1 0 BONNET
4 1 1 0 UPPER SPRING SEAT
5 1 1 0 ADJUSTMENT SPRING
6 1 1 0 LOWER SPRING RESET
7 1 1 0 SLIP RING
8 1 1 0 DIAPRAGHM
9 1 1 0 VALVE SEAT
10 1 1 0 O'RING VALVE SEAT (ONLY FOR
RELIEVING) 5,32X2,62
11a 1 1 0 FR & R BODY
11b 0 0 1 F BODY
12 1 1 0 SIPHON
13 2 2 2 CONNECTION
14 2 2 2 O'RING 37,82X1,78
15 2 2 2 BRACKET
16 1 1 0 VALVE STEAM
17 1 1 0 O'RING 3,69x1,78
18 1 1 0 VALVE
19 1 1 0 VALVE SPRING
20 0 1 1 FILTER ELEMENT SUPPORT
21a 0 2 2 FILTER ELEMENT 5 MICRON
21b 0 2 2 FILTER ELEMENT 25 MICRON
22 0 1 1 FILTER ELEMENT RING
23 0 1 1 FILTER ELEMENT PLUG
24 0 1 1 FILTER ELEMENT SCREW
25 0 1 1 O'RING BOWL 88,58x2,62
26a 0 1 1 MANUAL DRAIN BOWL
26b 0 1 1 AUTOMATIC DRAIN BOWL
27 0 1 1 BENZIN
28 0 1 1 O'RING DRAIN 3,69x1,78
29 0 1 1 MANUAL DRAIN
30 0 1 1 AUTOMATIC DRAIN
31 0 1 1 O'RING AUTO DRAIN 9,92 X 2,62
32 0 1 1 AUTOMATIC DRAIN SEAT
33 0 1 1 O'RING AUTO DRAIN 15,54X2,62
34 0 1 1 AUTOMATIC DRAIN SEAT
35 8 8 8 SCREW M5x16 DIN 912 A2
36 1 0 0 REGULATOR BOTTOM
37 1 0 0 REGULATOR VALVE SEAT
38 1 0 0 O'RING 32,99X2,62
39 0 0 1 FILTER TOP
40 0 0 1 O'RING 61,62x2,62
41 1 1 0 O'RING VALVE 18,72X2,62
