Rata Vogal Spreadmax 45 Operation Maintenance & Parts Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DOUBLE YOUR SPREADER WARRANTY TO TWO YEARS
By going online to:
RATA INDUSTRIES GROUP LTD
PO BOX 2032
WASHDYKE
NEW ZEALAND 7941
ACQUISITION AND WARRANTY
On delivery of your spreader carefully check for transit damage and report any defects immediately.
The commencement of warranty is based on the purchase date of your machine, provided you are
registered with Rata Industries within 14 days of the purchase date. Warranty claims will only be processed
upon receipt of proof of purchase and warranty registration within 14 days.
If you wish you may also complete the following and post to the address shown.
MODEL
SERIAL NUMBER
OWNER
PURCHASE DATE
DEALER
I, the new owner of the above product, accept the above details are correct and that I
have received sufficient training to operate the machine safely and correctly
OWNER SIGNATURE
Lifestyle Block
How did you hear of Vogal?
1
E:
sales@rataindustries.co.nz
rataindustries.co.nz/register-product
SPREADMAX 45
NAME
ADDRESS
EMAIL
PHONE
COMPANY NAME
SIGNATURE
Dairy Farm
Phone 0800 4 VOGAL (0800 486 425)
Drystock
Orchard/Vineyard
W:
www.rataindustries.co.nz
MAG 45

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vogal Spreadmax 45 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rata Vogal Spreadmax 45

  • Page 1 The commencement of warranty is based on the purchase date of your machine, provided you are registered with Rata Industries within 14 days of the purchase date. Warranty claims will only be processed upon receipt of proof of purchase and warranty registration within 14 days.
  • Page 2 MAG 45 CHECKLIST FOR VOGAL WHOLEGOODS Model Spreadmax 45 Serial Number Pre dispatch Pre Delivery Manufacturer Dealer All Bolts Tight Drive Engagement Greased & Aligned Correctly Oil Level Correct In Gear Box Operators Manual Attached to Machine Checked and Test Run Alignment of Agitator is Correct Spinner Disc Spins Freely Warning Label Attached...
  • Page 3 MAG 45 SPREADMAX MAG 45 Operation, Maintenance & Parts Manual Rata Industries Group Ltd Ferrier Rd Winchester South Island New Zealand Phone 0800 4 VOGAL (0800 486 425) sales@rataindustries.co.nz www.rataindustries.co.nz Phone 0800 4 VOGAL (0800 486 425) sales@rataindustries.co.nz www.rataindustries.co.nz...

  • Page 4: Dear Customer

    DEAR CUSTOMER Rata Industries would like to take this opportunity to welcome you as the new owner of a Vogal Spreader. We want your spreader to be the most efficient and reliable piece of equipment you have. This manual has been produced to assist in the correct operation, maintenance and care of your machine.

  • Page 5: Safety Instructions

    MAG 45 GENERAL Spreadmax fertiliser spreaders have been designed to spread general Granulated fertilisers, Urea, Grass seed, and particularly Causemag, Plus other similar products. The wide wheel base and strong frame design of the Spreadmax Fertiliser ensure safety and stability when towed behind four wheeled ATV’s. CAPACITY AND DIMENSIONS Max Road Hopper...

  • Page 6: Installation

    MAG 45 INSTALLATION PRE-START CHECKS 1. Ensure that the towball on the vehicle is compatible with the spreader. The spreader is designed to accept a 1-7/8” diameter towball. 2. Check the operation of all controls. 3. Check the tyre pressure (10psi minimum to 25psi maximum dependant on load size). 4.
  • Page 7 MAG 45 INSTALLATION OPERATING Before filling the hopper, set the flow from the hopper to the desired position by moving the lever (A) to the setting required (B) and locking it into place with the tri knob (C). Place the shutter lever (A) in the zero position and fill the hopper with the material to be spread. Drive to the area requiring the fertiliser, engage the D pin (D) to the IN position and re-lock the D pin to engage the drive.

  • Page 8: Calibration Settings

    MAG 45 INSTALLATION CALIBRATION To precisely calibrate the spreader carefully read and perform the following instructions. Place a measured amount of fertiliser in the hopper e.g. 10kg (A). Choose an aperture setting to suit the rate required for the type of fertiliser used, e.g. Setting 6 (B). Obtain the desired travel speed (12 to 15 km/hr) and open the aperture to preset setting 6, e.g.

  • Page 9: Maintenance

    MAG 45 MAINTENANCE Maintenance should be undertaken regularly, good maintenance extends the life of the spreader. Check the wheel bearings for play and pack grease every six months. Open the aperture and clean around the aperture blades and holes. Periodically remove the agitator by removing the pin located under the hopper.

  • Page 10: Replacement Parts

    MAG 45 REPLACEMENT PARTS To order replacement parts please quote the spreader model, serial number and date of purchase. The serial number is located on the spreader tow bar as shown below The following pages detail the replacement parts available. Serial Number Phone 0800 4 VOGAL (0800 486 425) sales@rataindustries.co.nz...
  • Page 11 MAG 45 MAG 45 PARTS LIST Phone 0800 4 VOGAL (0800 486 425) sales@rataindustries.co.nz www.rataindustries.co.nz...
  • Page 12 MAG 45 MAG 45 PARTS LIST Item Part No. Description Notes SP122-001 Main Frame SP100-017 Pointer SP100-034 Drive Axle Key SP102-004 Spinner Disc SP102-005 Spinner Fin SP121-006 Drive Slider SP122-006 Agitator SP122-012 Shutter Lever SP100-003 Agitator Bush SP100-016 Drive Stub SP100-020 Shaft Guard (trailed spreader) SP122-007...
  • Page 13 MAG 45 MAG 45 PARTS LIST Item Part No. Description Notes 4353 M10 Nut Nyloc Zinc 4355 M10x25 Bolt Galv 4359 M10x30 Bolt & Nut Galv 4378 M10x65 Bolt Zinc 4379 M10x70 Bolt Zinc 4384 M10x120 Bolt Zinc 4390 M10 Washer Spring Galv 4395 M10 Washer Square Galv (50x50x3) 4398...
