FAULT FINDING GUIDE
STAIRLIFT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEGASUS-NOVA-mps2 and is the answer not in the manual?

Questions and answers

Summary of Contents for rigert PEGASUS-NOVA-mps2

  • Page 1 FAULT FINDING GUIDE STAIRLIFT...

  • Page 2: Table Of Contents

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 Contents Foreword ......................... 4 Fault finding guide......................6 Mains connection, Fuses, Frequency controller and travel recognition PCB....6 2.1.1 Check main supply on main control box ............... 6 2.1.2...
  • Page 3 Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 The information in this document is based on the general information that belongs with the construction, material characteristics and work methods that are known at the moment of publication, so that we retain the right to make changes without prior notice.

  • Page 4: Foreword

    Authorised service engineers are trained for this purpose by rigert Ltd., Stairlifts and they are kept up to date with regard to changes and adaptations so that they can carry out all repairs on all models.
  • Page 5 Date: 13.03.06 Maintenance and repairs Maintenance and repairs are the sole province of an authorised rigert Ltd., Stairlifts service engineer, taking into consideration the safety regulations and instructions stated in this document. Tools Always use tools, original parts, materials and service techniques approved by the manufacturer.

  • Page 6: Fault Finding Guide

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 2 Fault finding guide 2.1 Mains connection, Fuses, Frequency controller and travel recognition PCB 2.1.1 Check main supply on main control box a) Single phase controller: Incoming tension Measure between terminals: L1 –...

  • Page 7: Check Fuses

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 2.1.2 Check fuses Switch off main switch, execute the work mentioned, switch on the main switch again a) Fuses F1 and F2 Check whether tripped or not – press them in, if required 1.6A...

  • Page 8: Check Frequency Converter (Fc) (If Applicable)

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 2.2 Check frequency converter (FC) (if applicable) Check whether the LED is blinking (not when you are switching on/off the controller) (depending on the type of FC you need to take off the cover) or if the error code 33”WARN FU”...

  • Page 9: Adjustments

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 3 Adjustments 3.1 Check setup Check the setup menu for correct adjustments against the specification sheet (FO3161) Encoder Turn encoder till the menu “Setup” Turn the encoder and check whether...

  • Page 10: Check Adjustments On Carriage Pcb

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 3.2 Check adjustments on carriage PCB Check adjustments for compliance with the specification sheet FO3161 (at bottom of spec. sheet) If adjustments comply, proceed to point 4 If not, go to point 3.2.1...

  • Page 11: Communication

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 4 Communication 4.1 Check communication Switch on the stairlift on the call station – key switch Turn the encoder till “Modem Status” appears Projected status: “+”-symbols shown on lower line which change alternatively with “p”-symbols If OK, proceed to point 5 if not, proceed to point 4.1.1...

  • Page 12: Communication With Call Stations

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 4.1.2 Communication with call stations Take off the front cover of the call station which does not show communication LED ON: tension present LED ON: communication ok...

  • Page 13: Check Safety Circuit I And Ii

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 5 Check safety circuit I and II Check the safety circuit along: Any switch not Safety end limit switch top end present, needs to Arrestor / overspeed governor...

  • Page 14: Status Of Call Stations (Rs)

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 6 Status of call stations (RS) 6.1 Check call stations Switch off installation by the key switch on the call station (LED OFF). Turn the encoder till “FZ/RS Status” appears...

  • Page 15: Status Of Carriage (Fz)

    Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 If one of the indications above appears, even the relevant button is not activated, take off the wire on the switch (not on the emergency stop – see diagram) and check again the call station (RS) status.

  • Page 16: Check Platform Position Of Carriage

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 7.1.4 Check platform position of carriage Check whether the controller recognizes the various positions of the platform. Run the carriage onto a landing (maybe hand winding required) Press the emergency stop (display changes from “ok”...

  • Page 17: Explanation Of Display For Menu Fz Status

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 7.1.5 Explanation of display for menu FZ status Display PFTrsp < >2 Position No. Display ^’ Position No. Display menu Directional button pressed on carriage (Call stations...

  • Page 18: Search For Faults

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 7.2 Search for faults 7.2.1 Safety switches “< , v, > “ Identifies a safety switch within safety circuit 1. The controller recognizes the single switch.

  • Page 19: Switch Locations On Carriage

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 7.2.3 Switch locations on carriage = Safety switches = Safety circuit I 1600.i.001 Side wall general BLUE = Position switches = Safety circuit II 7.2.3.1 Side wall Speed control Barrier arm –...
  • Page 20 Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 7.2.3.2 Platform 1600.i.010 Platform general S18.I / S18.II S10X.I / S10X.II Ramp monitoring Activation safety bottom Platform up / down S10A.I / S10A.II S10C.I / S10C.II...

  • Page 21: Rail / Rope

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 8 Rail / Rope 8.1 Check for continuity rail / rope For all work within chapter 8: switch OFF main switch. Switch ON after termination only...

  • Page 22: Bridge Rope / Rail

    Ltd., Stairlifts Operating manual Nr.: AW4231 CH-6405 Immensee Fault finding PEGASUS-NOVA-mps2 Date: 13.03.06 8.3 Bridge rope / rail Take off wires on 37 / 38 at the main controller (installation side) Unplug rope / rail connection in the carriage Take a long wire (2 cores –...
