MFTech USB-Interface Quick Start Manual

Quickstart USB-Interface
2.
Driver installation
Windows 2000 / XP / Vista:
Connect the Interface with your PC
Switch on your R/C transmitter
→ →
short time after connection..
Windows 98 SE / ME:
Connect the USB-Interface with your PC
hardware assistant select "choose manually"
→
compliant device"
Insert the Windows CD to copy the drivers
your R/C transmitter LED flashes
→
If the hardware assistant does not start automatically: Start the
assistant In Control Panel | Hardware manually
wait a short-time LED glows
→ →
LED flashes finished
→
..2 new items in device manager
Windows starts the
→
select "HID-
→
LED glows switch on
→ →
finished
→
"choose manually"
→
then choose HID see Win XP
→
1.
Transmitter settings
Connect your R/C transmitter (in PPM mode, without RF part /
unplugged crystal) with the Interface only if it is switched off!
The R/C Interface is connected with the buddy box. Thus, the
transmitter acts like a slave transmitter. You should set up your
transmitter for slave mode and make any settings necessary for
slave operation. For further information see the instruction
manual of your transmitter(how to switch off the RF part, unplug
the crystal oscillator, special settings, ..).
For USB-Interface III:
Detach all servos, motor controllers, devices and the battery
from the R/C receiver and only connect the receiver cord. The
USB-Interface supplies the receiver with power, no battery may
be connected additionally. First connect the receiver with the
USB-Interface, then connect the Interface with your PC.
Use Stick Mode "Stick Mode 1" in IntCon for the operation with
an receiver. The default setting is "RF G2".
3.
Test
Test in
Control Panel | Game Controller:
do not calibrate, test only!
USB-Interface
4.
Simulator
Connect the Interface with your PC before you attach the
R/C transmitter!
: Controls Analog Control Joystick Interface
FMS
→ →
Mapping / Calibration calibrate
→
Easyfly : Select joystick calibrate
→
Aerofly Pro : Calibrate Joystick Properties
→ →
calibrate, Controls Joystick Properties
→ →
channels
Realflight G2 : Settings Calibrate device
→
select Joystick (manually) calibrate, assign channels
→
in Advanced Settings
Other Simulators:
The USB-Interface can control all simulators (Aerofly,
Piccofly, MS Flight Simulator, ..), car simulators and
games, that can be controlled by a normal joystick, too.
→
→
assign
→
