Automatic Digital
Blood Pressure Monitor
User Manual
Model: KYX8012(D)-USB
Thank for purchasing Automatic Digital Blood Pressure
Monitor. It is mainly designed for general home use.
Before using the device, please read this manual carefully
to ensure proper and safe operation.
Please take good care of the manual for future reference.
Welcome your advice and support.
Advertisement
Table of Contents
Summary of Contents for Maxcare KYX8012-USB
- Page 1 Automatic Digital Blood Pressure Monitor User Manual Model: KYX8012(D)-USB Thank for purchasing Automatic Digital Blood Pressure Monitor. It is mainly designed for general home use. Before using the device, please read this manual carefully to ensure proper and safe operation. Please take good care of the manual for future reference.
-
Page 2: Table Of Contents
Table of Contents About the Products ..........1．Brief Introduction of the Product ..........2．The Constitution of the Product. How to Use 1．Batteries Installation..............02 2．Unit（mmHg/ kPa）Display Setup and Memory Deletion ....02 3．Cuff Connection................03 4．Fitting the Arm Cuff................03. 5．Adjust Your Sitting Posture............04 6．Taking a Measurement..............05 7．Reading Memory................06 8．Manual and Auto Inflation..............07... -
Page 3: About The Products
About the Products 1．Brief Introduction of the Product This new digital blood pressure monitor is an automatic measuring device to be used on the upper arm. It enable simple, accurate and fast measurement of blood pressure and pulse rate by use of the oscillometric method and people-orientated design. -
Page 4: How To Use
How to Use 1．Batteries Installation Press the indicator ▼ on the battery cover and slide the cover off in the direction of the arrow Insert 4 “AA” size batteries, align the polarities of the battery. Note: If the low battery indicator appears in the display, the batteries must be replaced.This monitor can also be operated with USB charging WARNING Pls purchase AC adapter (USB port) with CE certification. -
Page 5: 3．Cuff Connection
3．Cuff Connection Insert the air tube plug into the socket by revolving it. 4．Fitting the Arm Cuff Take off thick clothes, wear thin clothes or unclothe your upper arm for measurement. Lay the cuff on the upper arm. Turn the palm of your hand upward. -
Page 6: 5．Adjust Your Sitting Posture
Note: Both of your arms can be measured, but there are about 10mmHg differences between them. Each measurement should be made with the same arm. 5. Adjust Your Sitting Posture Sit on a chair with your feet flat on the floor. Put your arm on a table with your hand upward, relax and keep the cuff parallel with your heart. - Page 7 (2). After having reached the anticipated value of inflation, the monitor starts to deflate automatically with a constant speed to detect your blood pressure and pulse. (3). When the measurement is completed, your blood pressure and pulse rate will be displayed. Example: SYS: 128mmHg DIA: 78mmHg...
-
Page 8: 7．Reading Memory
Note: Once you feel uncomfortable with inflation or the inflation becomes ceaseless, please loosen the cuff and pull out the air tube immediately. Don’t talk, move your arm or body during the measurement. The monitor will be automatically shut off in 3 minutes without operation. -
Page 9: 8．Manual And Auto Inflation
8. Manual and Auto Inflation ● In most of cases, choose auto inflation. If your systolic pressure is more than 220mmHg, choose manual inflation. ● In the process of inflation, press MEM button for manual inflation. The preset value will be 260mmHg. The preset value will add 20mmHg by each touch. -
Page 10: 2．Table For Classifying Blood Pressure Values（Mmhg
Each time the heart beats, it pumps out blood into the arteries. Blood pressure is at its highest when the heart pumps or ejects blood. This is called Systolic Blood Pressure. Blood pressure is at its lowest when the heart rests ( in- between beats). This is called Diastolic Blood Pressure. -
Page 11: 3．Life Guide For Hypertension Patients
3. Life Guide for Hypertension Patients ※ High blood pressure (Hypertension); A blood pressure of 140/90 or higher is considered high blood pressure. High blood pressure (HBP) is a serious condition that can lead to coronary heart disease, heart failure, stroke, kidney failure, and other health problems. -
Page 12: Safety Instruction
Safety Instructions Warning 1) Hypertension can not be judged by the measured value through this product. The value is used for monitoring blood pressure. 2) Self-diagnosis of measurement results and self-treatment are dangerous. Contact your physician about the measured value. 3) Do not use the device on the injured arm or the arm under medical treatment. -
Page 13: Abnormal Phenomenon And Solutions
7) Do not use the monitor if you find it is damaged or notice anything unusual. 8) Do not take measurement more than necessary. It may cause bruising due to blood flow interference. Abnormal phenomenon and Solutions ERROR INDICATORS Symbol Cause Solutions Fit the cuff correctly... -
Page 14: Maintenance And Storage
Maintentance and storage 1) Do not subject the monitor and package to shocks, such us dropping it onto the floor. 2) Do not submerge the device or any of the components in water. Do not subject the monitor to extreme temperatures, dust, humidity, corrosive gas and drect sunlight, do not use it in an oxygen rich environment. -
Page 15: Technical Specifications
Technical Specifications Model KYX8012(D)-USB Display LCD digital display Pressure: Measuring Range 0kPa~38.6kPa (0mmHg~290mmHg) Pulse: 40~180/min Pressure: within ± 0.4kPa (3mmHg) Accuracy Pulse: within ± 5% of the reading Work Mode Automatic inflation and measurement Measuring Method Oscillometric method Power source DC 6V (4X “AA”batteries ) Temperature: 5℃~40℃... -
Page 16: Guidance And Manufacturer's Declaration
Guidance and Manufacturer’s Declaration Important information regarding Electro Magnetic Compatibility (EMC) This product needs special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided, and this unit can be affected by portable and mobile RF communications equipment. * Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit. - Page 17 Guidance and manufacture’s declaration – electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The customer or the user of device should assure that it is used in such an environment. Electromagnetic environment - Immunity test IEC 60601 test level Compliance level guidance...
- Page 18 Guidance and manufacture’s declaration – electromagnetic immunity is intended for use in the electromagnetic environment specified below. The customer or the device user of the should assure that it is used in such an environment. device Immunity IEC 60601 test Compliance Electromagnetic environment - guidance test...
- Page 19 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered.
- Page 20 EXPLANATION OF SAFETY SIGNS AND SYMBOLS Means type BF applied part. Symbol for “THE OPERATION GUIDE MUST BE READ” Symbol for “MANUFACTURER” Symbol for “COMPLIES WITH MDD 93/42/ECC REQUIREMENTS” DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. IP22: The first number 2:Protected against access to hazardous parts with a finger, and the jointed test finger of 12mm￠,80mm length, shall have adequate...
