- Page 1 WIDE NARROW SHILED ASSEMBLY INSTRUCTIONS Patent pending...
- Page 2 PARTS SET OF 2 LEGS WIDE PANEL WITH OPENING L29.5″ W35″ | L75 cm W89 cm WIDE PANEL L36″ W35″ | L91 cm W89 cm SCREWS SPACERS GUIDING PINS ALLEN KEY FOR M6 NARROW PANEL NARROW PANEL WITH OPENING L36″ W20″ | L91 cm W50 cm L29.5″...
- Page 3 Dry with a soft sponge to prevent water spots. × Never use abrasive or highly alkaline cleansers. × Never scrape with razor blades or other sharp instruments. × Never use benzene, acetone, or carbon tetrachloride. × Never use cleaners such as Windex or 409. www.mogogo-buffet.com CATALOG# S-ASV-PR-72-01...
- Page 4 ASSEMBLE SHIELDS AND MORE Unscrew the upper screws using a flat head screwdriver in both legs as shown. Screw one guide pin into one of the units and assemble them together.
