72 TEETH DIGITAL
SAVE THIS OWNER'S GUIDE FOR FUTURE REFERENCE
Specifications:
Model NO.
Accuracy
Square Driver
Range(Nm)
Digit
Memory
Operation Modes
Unit Selection
Size(mm)
Weight
Battery
Operation Temperature
Storage Humidity
Operation Humidity
Auto ShutOff
Read Owner's Guide before operating wrenches, Failure to follow instructions listed in this
guide may result in damage of electrical system, wrong torque setting and/or serious injury
AM0609-01
AM0609-02
± 2 %
1/2 inch
40 - 200
0.1
480 x 40 x 40
380 x 35 x 35
1.05 Kg
TORQUE WRENCH
AM0609-03
± 2 %
3/8 inch
1/4 inch
27 - 135
0.1
50 data sets of memory capacity
Peak or Trace
Kg-cm, Kg-m, Ib-in, Ib-ft, N-m
290 x 35 x 35
0.66 Kg
0.4 Kg
AAA DC1.5V x 2 pcs
-10℃~ 60℃ ( 13.9℉~ 139.9℉)
-20℃~ 70℃ ( -4℉~ 157.9℉)
15~90%
After 80 seconds of no use
AM0610
± 4 %
6 - 30
0.1
290 x 35 x 35
± 4 %
1/4 inch
6 - 30
0.1
0.4 Kg
Advertisement
Table of Contents
Summary of Contents for Hinode Tools AM0609-01
- Page 1 TORQUE WRENCH 72 TEETH DIGITAL SAVE THIS OWNER’S GUIDE FOR FUTURE REFERENCE Specifications: AM0609-01 AM0609-02 AM0609-03 AM0610 Model NO. ± 2 % ± 2 % ± 4 % ± 4 % Accuracy Square Driver 1/2 inch 3/8 inch 1/4 inch...
- Page 2 FEATURES 1. 50 data sets of memory capacity. 2. 2 LEDs red / green for visual alerting. 3. 72T Gear teeth. 4. Standard functions: torque setting, measurement setting, mode setting. 5. Operation in both clockwise and counter-clockwise directions. 6. LCD display shows kg/cm, kg/m, lb-in, lb-ft, N/m. 7.
