Owner's Manual: Universal Fire Extinguisher Seat Mount
Thank you for your purchase! This versatile mount provides a secure platform to install a fire extinguisher in a
vehicle while avoiding the need to drill mounting holes. It can attach to existing mounting holes from 8 7/8" to
19 1/4" apart, and is designed to work with a wide variety of automobile seats.
Illustrated parts list
Item #
1
MAIN SUPPORT BAR
2
SUPPORT BAR ADJUSTER
3
SMALL MOUNTING TAB
4
LARGE MOUNTING TAB
5
EXTENSION ARM
6
MEDIUM WASHER
7
LARGE LOCK NUT
8
SOCKET HEAD CAP SCREW
9
LARGE WASHER
10
PHILLIPS SCREW
11
SMALL LOCK NUT
12
SMALL WASHER
4 83
M
103 H Street, Petaluma, CA 94952 T (800) 249-4289 F (707) 765-3395 h3rinfo@H3Rperformance.com www.H3Rperformance.com
(Models SM01BR and SM01BK)
Description
R – 100219
Qty.
1
1
2
2
2
8
4
4
2
4
4
3
Advertisement
Summary of Contents for H3R SM01BR
- Page 1 R – 100219 Owner’s Manual: Universal Fire Extinguisher Seat Mount (Models SM01BR and SM01BK) Thank you for your purchase! This versatile mount provides a secure platform to install a fire extinguisher in a vehicle while avoiding the need to drill mounting holes. It can attach to existing mounting holes from 8 7/8” to 19 1/4”...
- Page 2 Limited Warranty H3R Performance, Inc. (“H3R”) warrants this product for a period of one (1) year from the date of purchase to be free from defects in material and workmanship. During the warranty period any such defects will be repaired or the defective mount replaced. This warranty does not cover defects resulting from modification, alteration, misuse, exposure to corrosive conditions or improper installation or maintenance.
