Albion Chairs G+6 User Instructions

USER INSTRUCTIONS FOR G+6 CHAIR
When you are sat in your chair there are 3 levers and a rod on the right side of your seat
and a bar under the front edge.
The bar under the front
1
edge is for sliding the seat
forward or back.
The rod at the front right
2
hand corner pulls in or out
to control the forward (-ve)
tilt of the seat.
The 3 levers to the side:
3
The front lever controls
the seat tilt
The middle lever controls
4
the gas lift for seat height
adjustment
The back lever adjusts the
5
angle of the backrest.
The tension of the tilt is
controlled by the
handwheel under the seat.
Our recommended order of adjustments for the user is as

Seat height:

To raise the seat up lift the gas lift lever when not seated.
To lower the seat, lift the lever with your weight in the chair.

Seat depth:

Use the bar at the front of the seat similarly to the mechanism in car seats; lift the bar and slide
your bottom forward or back to increase or decrease the seat depth.
Albion House, Lane End Road, Sands, High Wycombe, Bucks HP12 4HG
tel: +44(0)1494 464656
email: info@albionchairs.com

The Mechanism

There is wording on the handles to help
follows:
