FOLDING CLIMBING STEPPER
SF-1115
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US:
support@sunnyhealthfitness.com
or 1- 877 - 90SUNNY (877-907-8669).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-1115 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny Health & Fitness SF-1115

Summary of Contents for Sunny Health & Fitness SF-1115

  • Page 1 FOLDING CLIMBING STEPPER SF-1115 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly.

  • Page 3: Exploded Diagram

    EXPLODED DIAGRAM HARDWARE PACKAGE #14 Pop-Pin 1PC #A Allen Wrench 1PC #B Spanner 1PC...

  • Page 4: Parts List

    PARTS LIST Description Spec. Description Spec. Handlebar Foam Right Pedal Tube Handlebar Cushion Display Console Bolt Bolt Clip Washer Sensor Inner Cap Bolt M3.4 Magnet Spacer Spacer Ring Washer Bearing Sleeve Left Pedal Tube Bolt Bearing Sleeve Hydraulic Cylinder Bolt Main Frame Pop-Pin Bolt...
  • Page 5 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 1: Open the box and remove the Main Frame (No. 13). Unfold the Main Frame (No.
  • Page 6 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 3: Remove the pre-installed 4 Bolts (No. 4), 4 Washers (No. 5) and 4 Nuts (No.
  • Page 7 ADJUSTMENTS & USAGE GUIDE 1. Stand behind your Climbing Stepper with both hands on the handlebar. Place your right foot onto the right pedal and place your left foot on the left pedal. While holding the handlebar, begin stepping up and down in smooth controlled movements. 2.
  • Page 8 ADJUSTMENTS & USAGE GUIDE FOLDING THE STEPPER: Remove the Pop-Pin (No. 14) from the middle of the Main Frame (No. 13). Hold the front support tube in place with one hand and with the other hand pull the rear support tube inward until it rests against the front support tube.

  • Page 9: Exercise Computer

    EXERCISE COMPUTER Our computerized display console on the Sunny Folding Climbing Stepper allows the user to tailor a personalized workout by monitoring their progress. During a workout, the display console will alternately and repeatedly display your Time, Count, Calories, and Total Count. With our easy-to-use console, the user can efficiently track their fitness improvements from one workout to the next.

  • Page 10: Battery Installation And Replacement

    BATTERY INSTALLATION & REPLACEMENT Battery Battery Cover BATTERY INSTALLATION 1. Take out 2 AA batteries from hardware package. 2. Press the buckle of battery cover on the Display Console (No. 3), then remove battery cover. 3. Install 2 AA batteries into the battery case on the back of the Display Console (No. 3). Pay attention to the battery + and –...
