- Page 1 S 65E S 64E MANUALE DI ASSISTENZA TECNICA SERVICE MANUAL MANUEL D’INSTRUCTIONS POUR L’ASSISTANCE TECHNIQUE WERKSTATT-HANDBUCH MANUAL DE ASISTENCIA TÉCNICA Ed. 05/2018...
- Page 2 1. ERROR MESSAGES The machine can recognise a certain number of malfunction conditions and signals them by displaying the relevant messages. – A – Notice Messages wheel not suitable for performing sensitivity calibration - use a wheel of average size (typically 5.5”X1440”) or a larger wheel weighing no more than 40 kg.
- Page 3 First calibrate sensitivity and then set the zero position for the assembly. If the message persists, check the following: that the search card reads correctly by performing the encoder test (see paragraph “Service programmes”); PK modules and phases as indicated in the paragraph “Service Programmes”. E 3 I/E 2/3 Error condition at end of sensitivity calibration.
- Page 4 Unbalance values greater than 999 grams. 2. TROUBLESHOOTING The wheel balancer is equipped with self-test and self-diagnosis programmes supplying information about most possible faults and the relative interventions (refer to the list of error messages and the paragraph “Troubleshooting” in the User Manual). There are, however, irregular working conditions that the machine is not able to recognise, and which are listed below.
- Page 5 - place the terminals of a tester (used as an alternating voltmeter) in contact with the terminals of the disconnected cables; • press the START key. If the piloting part upstream of the measuring point is working correctly, you should read a voltage value of around 115/230 Volts (based on the type of power supply used).
- Page 6 If the motor does not start up: - check that the motor power supply cable is connected correctly; - check motor operation. If when commanding the spin (or when lowering the guard or pressing the Start key and the button) the wheel turns in the opposite direction (i.e.
- Page 7 Check that the CF was inserted correctly in the graphic card and replace the CF if necessary; • the machine resets. The fault (usually sporadic) can arise due to the temporary absence of a power supply to the main board, or owing to a disturbance or malfunctioning of the main board.
- Page 8 Check the efficiency of the earthing connection of the socket (essential for the correct operation of the machine as well as for safety purposes). the earth cable is correctly connected inside the electric system and on the internal machine parts. 3.
- Page 9 This function allows you: to check with the maximum precision (a tenth of an inch) the match between the values obtained with the sensor and the nominal values of the wheels. - The current value of the angular position transducer of the wheel (encoder), its variation interval, and two numerical values corresponding to the number of impulses counted by the encoder during a spin and the expected value for this count (XXX).
- Page 10 lightly push the search card A in the direction of the metal disc D, tighten the two fastening screws then remove the calibration template. IMPORTANT: after any adjustment or after replacing the encoder board, perform the relative test cycle by performing a spin with a wheel, and check that the two numerical values shown on the right hand side of the row denominated ENCODER TEST in the service environment match.
- Page 11 - perform a spin. The values visualised do not depend on the dimensions set. These data allow to: • to check that the values visualised are within the envisaged intervals, i.e. (see also the paragraph “Pick-up replacement and adjustment”): - internal pick-up signal: >...
- Page 12 fig. 3 5.1 PEAL 32F power board This power board enables the wheel balancer to be powered with single phase AC mains power with a voltage of 100 - 240 Volts +/- 10% (20 fig.3). The following LEDs must illuminate after power-on: - LED LD1 (green) must be lit (indicates that board is receiving 5VDC power), - LED LD20 (green) must be lit (indicates that Sonar sensor is receiving 24VDC power), if these LEDs are not lit, check that the board is receiving power correctly.
- Page 13 fig. 4 After switch-on. the machine loads the graphics. This operation, which lasts approx. 25 seconds, results in the display of a logo with a clock on the monitor if the "clock" logo is displayed for longer, check the correct loading of the SD and replace it if necessary. If the “clock”...
- Page 14 - Press the Escape key to exit. 7.2 Selecting monitor display format This function may be used to change the screen format to suit the monitor used. - access the service environment and, turning the unit, position it to encoder position notch 169; - while still at this notch, press and hold ENTER (with the cursor on the “spin counter”...
- Page 15 - With the machine turned off, set the dip-switch (A, figure 5A) which is necessary for accessing the diagnostics mode, i.e: MBUGRF: SW1 DSW2 to ON; - Turn the wheel balancer on; - The diagnostics programme page “TEST SELECT” will appear on the screen. Use the arrow keys to select the test called “5 E2PROM”; - Press the enter button to confirm the selection.
- Page 16 Fig. 5 - disassemble the keyboard via the adhesive velcro; - remove the ground cable and the picoflex connector from the keypad; - Disconnect the monitor signal and power supply cables; - remove the panel (C, Fig.5); - remove the two cables disconnected previously, feeding through the hole on the cover panel D (Fig.5); - Remove the weight tray cover, unscrewing the four M6 fixing screws.
- Page 17 - MBUGRF board - Main board, manages the wheel balancer and processes data. - SD board, manages the graphics of the wheel balancer. The board is controlled by a microprocessor with relative firmware. The firmware of the MBUGRF card may be updated during maintenance. It should be pointed out that: •...
- Page 18 Fig.5A - Connect the serial cable code 8-21100224 to the “JPS1A” connector of the card itself (see part B figure 5A). The other end of the cable is connected to the RS232 serial port on the PC. If the PC does not have a RS232 port, use the RS232/USB adapter P/N 8-21100226. - Turn the wheel balancer on.
- Page 19 Fig.5C Select Firmware Update (icon B, figure 5B) to start the programming procedure. Fig.5D - “100%” is displayed when programming has been completed successfully. - After the programming procedure, close the application, switch off the machine and return the dip-switch to the original position (all switches OFF).
- Page 20 - Select the "OPEN" icon and load the file with the extension .bin of the firmware version to be updated previously downloaded from the network. - Select the COM serial port where the programming cable is connected to the PC. - Select the "START"...
- Page 21 MSK GRAPHIC VERSION UPDATE (SD BOARD) An SD board may be programmed from Windows (Windows XP or Windows Seven 64 bit) using the application “Win32DiskImager-0.9.5- install.exe” downloadable from the Private Area of the web site. Install the application “Win32DiskImager-0.9.5-install.exe” on your PC, then create a desktop link. Now proceed as follows: Launch the application by double-clicking the link on your desktop.
- Page 22 Fig.5h After selecting, the application starts writing to the SD; the progress of the write process is indicated by the progress bar (Fig.5i). Fig.5i Once the write procedure is complete, the screen shown in figure 5l is displayed. Click OK. Fig.5l Click “Exit”...
- Page 23 Fig.5m INSTRUCTIONS FOR UPDATING SD + MBU SW USING A USB KEY Copy the following file downloaded previously from the internet onto the USB key: GRF_Update.zip Note: - copy the file indicated above to the root of the USB. Do NOT copy into folders! With the machine switched off, connect the USB key to the USB port on the cover panel of the electrical box;...
- Page 24 12. INTERNAL AND EXTERNAL SENSOR (MECHANICAL MEASURING SENSOR OR ULTRASONIC SENSOR) To view the sensor signals access the service environment; Fig. 6 12.1 Diameter sensor Check that the stroke is made up of -110 notches with the lever resting on the bell of the swinging unit see Fig. 7 (maximum error allowed +/- 5 notches in the position indicated).
- Page 25 - disconnect the Picoflex from the sensor; - disassemble sensor B, removing it from its seat; - replace the sensor, assembling it by following the disassembly directions in the reverse order; - check the sensor reads correctly, as indicated above. 12.2 Distance sensor Check that the total stroke is 720 notches (maximum permitted error +/- 5 notches along the entire stroke);...
- Page 26 - Unscrew the fixing screws of the potentiometer support plate; - disassemble the gears and reassemble them on the new potentiometer, tightening the screw so that they rub against the shaft, thus permitting the subsequent adjustment; - reassemble the new potentiometer with its relative gears on the plate and fix everything, ensuring that the teeth of the gears are aligned; - re-hook the spring in the appropriate hole;...
- Page 27 Fig. 8a If the values are not correct, repeat sensor calibration as described in the user and maintenance manual. If the sensor needs to be replaced, proceed as follows: Remove the plastic cover (A, Fig. 8b), undoing the four fastener screws, see figure 8b. Remove the ultrasonic sensor (B, Fig.
- Page 28 13. INTERNAL SENSOR CALIBRATION Fig.9a The internal sensor must be calibrated in the following cases: • the machine displays the message E 4 (sensor calibration not performed) even after having calibrated the external sensor (if present); - the MBE32F main board has been replaced, or board reset diagnostic test “t5” has been performed. •...
- Page 29 Fig.9b • Press "Enter" to calibrate the distance; • Return the sensor to the rest position. Exit the sensor calibration programme by pressing the “Escape” key. If the calibration has been performed successfully, an acoustic consent signal is emitted. If the message A 20 is displayed, this indicates that the position of the sensor during the calibration phase is incorrect.
- Page 30 Fig.9d 14. PICK-UP REPLACEMENT AND ADJUSTMENT To replace the pick-ups, follow this procedure: - Disconnect the connection of the pair of pickups from the MBUGRF board (D fig. 3); - loosen the pick-up pre-load springs completely (A, Fig. 10); Fig. 10 - Unscrew the two M10 dowels and replace the pick-ups (B, Fig.
- Page 31 - Manually tighten the two screws fixing the washers, recovering all the axial play; - use an Allen spanner to tighten the two screws with the washers, making four complete turns with the spanner. - Reconnect the connector of the pick-ups. - Perform some settling spins;...
- Page 32 fig. 12 16. SPIN AND BRAKE DEVICE 16.1 Replacing and adjusting the belt - Remove the weight tray; - Unscrew the fixing screws of the side closing panel on the motor compartment; - Unscrew the nut and locknut used to tighten the belt (A1, A2, Fig. 13); - Loosen the three motor fixing screws (B, Fig.
- Page 33 fig. 13 16.2 Replacing the motor - Remove the weight tray; - Disconnect the motor power cable (B, fig.3) and clamping brake cable (H, fig.3) from the PEAL32F board; - Unscrew the fixing screws of the side closing panel on the motor compartment; - Unscrew the two nuts of the belt tightening screw (A, Fig.
- Page 34 17. AUTOMATIC CLAMPING SYSTEM Fig. 15 Check the following in the event of a malfunction of the PL automatic clamping system: - Check the workshop compressed air system, which must deliver a constant pressure of at least 7 bar (100psi); - check for and, if necessary, clear any debris in the CPL filter at the rear of the machine;...
- Page 35 Fig. 16 Fig.17 The machines equipped with the third version of the pneumatic system (from March 2017) have the internal configuration as indicated in figure 17a:...
- Page 36 Fig. 17a In this version it is possible, in case of anomaly of the automatic locking device, to remove the wheel that may be present on the machine by acting on the rear side of the box as shown in the figure: In machines where there is also an adjustable drain A on the rear side of the body.
- Page 37 it is possible to remove the wheel that may be present on the machine by proceeding as follows: - Close the adjustable drain A by turning clockwise; - Blow compressed air on the fitting B in the figure; - restore the correct functioning of the wheel locking device: run 3 complete turns anticlockwise of the previously closed adjustable outlet A.
- Page 38 Fig. 17c ü Unscrew the hub C completely; - then press the control pedal C (device clamped); - check if air is delivered from the terminal pin by, for example, fitting a balloon onto the terminal pin itself (A, Fig.17d). If the balloon inflates, there is an air leak within the device;...
- Page 39 Fig.17e Check the following if the clamping system does not work and no errors are displayed when the clamping system pedal is pressed: check that NO micro-switch (Normally Open) is connected correctly and that the micro-switch is working correctly (A fig.17f). Undo the nut (B fig.17f) to access the micro-switch;...
- Page 40 Fig.17g - If the RFU valve (A, Fig.17h) is present, proceed as follows: • unscrew the nut (C, Fig.17h) • unscrew the adjustment tap completely (B, Fig.17h) • tighten the nut (C, Fig.17h) - Update the SW MBU version with the 1.5 of 19/02/2018 release and the SD version with the 10.4 of 17/01/2017 release. For the SW update, follow the instructions in the service manual.
- Page 41 18. MOUNTING AND DEMOUNTING THE WHEEL GUARD To assemble and disassemble the wheel guard, refer to the user and maintenance manual. If there the guard works incorrectly (e.g. when the guard is lowered, the machine does not spin, or vice versa), check: - the connection of the micro-switch cable and, if necessary, the connection to the MBUGRF board (G, fig.3).
- Page 42 “RESTART THE MACHINE” Turn the machine off and then on. 20. LED LIGHT AND LASER LINE DEVICE If the led light device does not work, check: • In the menu dedicated to device activation (see user and maintenance manual); • that the power cable between the ILL board (Fig.21) and the MBUGRF board (A, Fig.19) is installed correctly; •...
- Page 43 Fig. 20 fig. 21...
- Page 44 fig. 22 If the laser device does not work, check: • In the menu dedicated to device activation (see user and maintenance manual); • The correct wiring of the Laser cable on the ILL board, that is the red wire must be connected to the positive pole (+) and the black wire to the negative pole (-) see A, Fig.21;...
- Page 46 SECOND VERSION OF PNEUMATIC SYSTEM (from April 2016)
- Page 47 THIRD VERSION OF PNEUMATIC SYSTEM (from March 2017)
- Page 48 FOURTH VERSION OF PNEUMATIC SYSTEM...
- Page 49 ELECTRICAL SYSTEM GENERAL DIAGRAM Power supply unit card Mother board (CPU) Keypad Monitor Search card Internal pickup External pickup Fuse Fuse Motor Main switch Safety guard micro-switch / start button Micro-switch automatic wheel locking system External distance potentiometer Power supply socket Brake / motor disconnection coil Diameter measuring sensor Distance measuring sensor...
- Page 50 PEAL 32F...
- Page 52 MBUGRF-2 LIGHT...
