Repositioning SERCOS II and
SERCOS III Boards in
EDGE
®
Pro and MicroEDGE
®
Pro CNCs
Field Service Bulletin
808280
Revision 0
December 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SERCOS II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hypertherm SERCOS II

  • Page 1 Repositioning SERCOS II and SERCOS III Boards in EDGE ® Pro and MicroEDGE ® Pro CNCs Field Service Bulletin 808280 Revision 0 December 2013...
  • Page 2 82 51 701 0358 Fax © 2013 Hypertherm Inc. All rights reserved. EDGE and Hypertherm are trademarks of Hypertherm Inc. and may be registered in the United States and/or other countries. All other trademarks are the property of their respective holders.
  • Page 3 Wear a grounded wrist strap when handling PC boards. Purpose SERCOS II and SERCOS III boards share the PCI bus with many other devices. Certain MS Windows operations, such as reading a USB memory device, can take priority over SERCOS signals and cause a slight delay in SERCOS communication.
  • Page 4 Repositioning SERCOS II and SERCOS III boards in the EDGE Pro CNC Not used Slot 1 Wireless board Slot 2 SERCOS II or SERCOS III master board Slot 3 Utility/serial isolation board Slot 4 Not used Slot 5 Location of boards in EDGE Pro PCI slots As you follow this procedure, set aside all screws and other hardware for reuse.
  • Page 5 To replace the SERCOS II or SERCOS III board: 1. Insert the SERCOS II or SERCOS III board into PCI slot 4 on the motherboard. 2. Fasten the screw in the mounting frame and tighten it to 1.12 N·m (10 lb·in.).
  • Page 6 After you reposition the boards  After a SERCOS II update, if you cannot establish the ring, verify that the RX and TX fiber optic cables are securely plugged into the correct connector. LED 1, for the RX port, should be illuminated in green. For more details, see the EDGE Pro SERCOS II Instruction Manual (807640).
  • Page 7 Repositioning SERCOS II and SERCOS III boards in the MicroEDGE Pro CNC Slot 5 Slot 1 Slot 2 Slot 4 Slot 3 Location of boards in MicroEDGE Pro PCI slots As you follow this procedure, set aside all screws and other hardware for reuse.
  • Page 8  After a SERCOS II update, if you cannot establish the ring, verify that the RX and TX fiber optic cables are securely plugged into the correct connector. LED 1, for the RX port, should be illuminated in green. For more details, see the EDGE Pro SERCOS II Instruction Manual (807640).
