Summary of Contents for Genie 360 Z-40/23N &RJ
- Page 1 TECH TIPS Service Call: No Operations - Various Trouble Codes Pertaining to Can Bus including but not limited too: 71-11, 78-13, 77-13,63-16, 17-22, 58-13 Tools Needed: Volt-OHM meter, 7/16 wrench Model: Genie Z-40/23N &RJ...
- Page 2 TECH TIPS Step 1 Connect the Meter to the Can-Bus at the TCON, use the Can- Bus connection in Pic 1, Remove the Black Cover (the black cover will have one black wire connected to it, not shown) ground one lead of the meter to a good ground and put the positive lead to yellow can bus wire.
- Page 3 TECH TIPS Step 3 Remove the cover over the drive end of the frame. To check the Right Motor Controller with the meter lead still connected to the Can-Bus At The TCON location unhook the Duetch connector at the Right Motor Controller. If the voltage does not go to 2.6 and 2.1 the Motor Controller is not defective.
- Page 4 TECH TIPS Step 5 To check the VCON (display module at the platform) with the meter still connected at the TCON location unhook the Can- Bus at the VCON. If the voltage goes to 2.6 and 2.1 the VCON is defective. If all readings are good proceed to step 6 and 7 to check the OHMS readings.
- Page 5 TECH TIPS Step 7 With the TCON, PCON, VCON and Right Motor Controller connectors containing the yellow and green Can Bus disconnected check the OHMS at the Can-Bus Connector located in close proximity to the TCON as pictured. The OHMS should read approximately 120.9.
- Page 6 TECH TIPS...
- Page 7 TECH TIPS...
- Page 8 TECH TIPS...
- Page 9 TECH TIPS...
- Page 10 TECH TIPS...
