Outdoor Plus OPT-TTM Series Manual

Top torches stainless steel / corten
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER:
Leave this manual with the appliance
CONSUMER:
Retain this manual for future reference.
T H E O U T D O O R P L U S . C O M
TOP TORCHES
STAINLESS STEEL / CORTEN
OPT-TT(X)M
2 3 5 E A S T M A I N S T
P A G E 1
9 0 9 . 4 6 0 . 5 5 7 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPT-TTM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Outdoor Plus OPT-TTM Series

  • Page 1 TOP TORCHES INSTALLER: Leave this manual with the appliance STAINLESS STEEL / CORTEN CONSUMER: Retain this manual for future reference. OPT-TT(X)M P A G E 1 T H E O U T D O O R P L U S . C O M 2 3 5 E A S T M A I N S T 9 0 9 .

  • Page 2: Safety Warnings

    T O P T O R C H E S SAFETY WARNINGS WARNING AVERTISSEMENT   Improper installation, adjustment, alteration, Une installation, un ajustement, une service, or lack of maintenance can cause injury modification, une réparation ou un entretien or property damage. inapproprié...
  • Page 3 T O P T O R C H E S SAFETY WARNINGS WARNING AVERTISSEMENT   If you smell gas: Si’l y une odeur de gaz: õ Shut off gas to the appliance Coupez l’admission de gaz de l’appareil. õ õ...
  • Page 4 T O P T O R C H E S SAFETY WARNINGS WARNING  Installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 / NFPA 54, or International Fuel Gas Code. The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electric Code, ANSI/NFPA 70, if applicable.

  • Page 5: General Informations

    T O P T O R C H E S GENERAL INFORMATIONS Fuel Type - Before making gas connections ensure appliance being installed is compatible with the available gas type. Check the label on the appliance to confirm appliance gas type requirement. Gas Pressure - Proper input gas pressures are required for optimum appliance performance.

  • Page 6: Installation

    T O P T O R C H E S INSTALLATION Note: Installation should be done by a qualified service technician that is locally licensed. TIKI TORCH COMPONENTS MANUAL SHUT OFF OPTIONS OPTION 1 OPTION 2 Torch Head Manual gas shut off located at torch. Manual gas shut off located on torch pole (Requires you to drill a hole.) Manual Gas...
  • Page 7 T O P T O R C H E S INSTALLATION STEP 3 If you are installing the Manual Gas Shutoff on the Tiki Pole (Option 2 from page 7) first remove the handle from the Ball Valve and then install the ball valve on the ½” gas riser as shown in diagram 3.
  • Page 8 T O P T O R C H E S INSTALLATION STEP 6 Install ½” gas hose to your gas riser (or manual gas shutoff valve) so that the end of the ½” gas line is 1” SHORTER than the pole (measurement “B” from the previous page) In addition, bring the wires previously installed up along the gas line and tape it to the gas line in...
  • Page 9 T O P T O R C H E S INSTALLATION THE TORCH HEAD STEP 9 Connect the gas line to the head of the tiki torch. Do NOT use pipe dope or plumbers tape on flared connections. Ensure connections are tight to prevent any gas leaks.

  • Page 10: Maintenance

    T O P T O R C H E S FIRE PIT OPERATION WARNING: before use, be sure to test all gas connections for leaks. Do not use torches if there is any evidence of leaking gas. If leaking gas suspected, turn off the main gas supply and repair immediately. WARNING: Wind and gusty conditions will affect the flame in an unpredictable manner.

  • Page 11: Cleaning, Maintenance And Storage

    The cover will help protect enclosed area. your fire pit from detrimental effects of weather and environmental pollutants (see your local Outdoor Plus Ensure the appliance has ample time to cool off after dealer for details).

  • Page 12: Replacement Parts

    T O P T O R C H E S REPLACEMENT PARTS A complete catalog of products and replacement parts available from The Outdoor Plus can be found online at www.theoutdoorplus.com You can find a full range of products and accessories, including: õ...

  • Page 13: Clearance From Combustibles

    T O P T O R C H E S CLEARANCE FROM COMBUSTIBLES INSTALLATION SERVICE We suggest that our products be installed by We suggest that our products be serviced by a professionals that are locally licensed by the authority professional certified in the US by the National Fireplace having jurisdiction in gas piping.
