INSTALLATION AND OPERATION MANUAL
Manufactured for DJO
MEDEN - INMED Sp. z o.o.
2 WENEDÓW STREET
KOSZALIN 75-847
POLAND
GALAXY
Massage table
For US product support please call 1-800-494-3395,
or visit djoglobal.com.
For international product support please contact your
local dealer, or your corresponding DJO Global site.
You may also contact us internationally at the below
email address:
internationalproductsupport@DJOglobal.com
For service & repair:
Advertisement
Table of Contents
Summary of Contents for DJO GALAXY Series
- Page 1 For US product support please call 1-800-494-3395, or visit djoglobal.com. For international product support please contact your MEDEN - INMED Sp. z o.o. local dealer, or your corresponding DJO Global site. 2 WENEDÓW STREET You may also contact us internationally at the below KOSZALIN 75-847...
-
Page 2: Table Of Contents
CONTENT 1. INTRODUCTION 2. FEATURES OF GALAXY MASSAGE TABLES 2.1. INTENDED USE 2.2. TECHNICAL DATA 2.3. GALAXY MERCURY CLASSIC 2.4. GALAXY MERCURY S2.FX / S2.FX-H 2.5. GALAXY MERCURY E-S2.FX / E-S2.FX-H 2.6. GALAXY JUPITER S3.FX / S3.FX-H 2.7. GALAXY MERCURY S4.FX / S4.FX-H 2.8. -
Page 3: Introduction
You must report the manufacturer or supplier immediately. 4. Repair of the product must be done by the local DJO office or authorized dealer and registered on the repair list in the warranty card. Failure to do so will void the warranty. -
Page 4: Features Of Galaxy Massage Tables
2. FEATURES OF GALAXY MASSAGE TABLES This manual describes the different execution of the GALAXY table, so not all of the information and drawings contained in it are related to your copy. The manufacturer reserves the right to make changes, not depicted in the current version of the manual, which will not cause degradation of functional and safety conditions of the product. -
Page 5: Galaxy Mercury Classic
GALAXY massage table type MERCURY model CLASSIC, S2.Fx, S4.Fx, E-S2.Fx, type JUPITER model S3.Fx, S5.Fx and type SATURN model P3.Fx, P5.Fx together with equipment is made in accordance With essential requirements for medical devices (class I, rule 12) and have the CE marking, according to the declaration of the manufacturer. GALAXY massage table type MERCURY model S2.Fx-H, S4.Fx-H, E-S2.Fx-H type JUPITER model S3.Fx-H, S5.Fx-H and type SATURN model P3.Fx-H, P5.Fx-H with accessories is made according to the essential requirements for medical devices (class I, rule 12) and have CE... -
Page 6: Galaxy Jupiter S3.Fx / S3.Fx-H
2.6. GALAXY JUPITER S3.Fx / S3.Fx-H Head section inclination angle adjustment from: 0 to +40 degrees Length of the head section: 46 cm (18,1 in) Head section declination angle adjustment from: 0 to -70 degrees Length of the middle section: 54 cm (21,3 in) Leg section inclination angle adjustment from: 0 to +90 degrees Length of the leg section: 101 cm (39,8 in) Picture 4 –... -
Page 7: Galaxy Saturn P3.Fx / P3.Fx-H
2.9. GALAXY SATURN P3.Fx / P3.Fx-H Head section inclination angle adjustment from: 0 to +40 degrees Length of the head section: 46 cm (18,1 in) Head section declination angle adjustment from: 0 to -70 degrees Length of the middle section: 54 cm (21,3 in) Leg section inclination angle adjustment from: 0 to +90 degrees Length of the leg section: 101 cm (39,8 in) Postural Drainage angle adjustment from 0 to +24 degrees... -
Page 8: Design And Functions
3. DESIGN AND FUNCTIONS Table components 3.1. CAUTION ! It is forbidden to modify tables without written authorization from the manufacturer. The frame of the table is made of welded steel sections coated with powder paint. It includes the following components: Picture 9 - Elements of the GALAXY massage table bottom frame... -
Page 9: Equipment And Additional Accessories
additional accessories 3.2. Equipment and CAUTION ! Use only accessories indicated or provided by the manufacturer. Every GALAXY massage table is provided with a breathing slot in the front section and has rails for fastening the stabilization belts in the rear section (except for MERCURY CLASSIC). Additionally, the tables may be equipped with the following accessories: - paper towel hanger (roll size 60 x 14 ) - see. -
Page 10: General Warnings And Cautions
4. GENERAL WARNINGS AND CAUTIONS CAUTION ! To avoid the risk of electric shock, the table must be connected to a grounded electrical service. Do not use any extension cords and/or multiple outlet extension cords. CAUTION ! Do not use a table with a power cord other than provided by the manufacturer. CAUTION ! Galaxy massage table have a limited load capacity! The safe working load should not exceed 200 kg (440 lbs) when lifting and the total load should not exceed 275 kg (606 lbs). -
Page 11: Preparing The Unit For Use
5. PREPARING THE UNIT FOR USE CAUTION ! When setting or changing the place of use of the GALAXY massage table, ensure that there are no objects in the space below the bottom frame of the table. Avoid uncontrolled access to the children's use area, as well as pets (cat, dog, etc.). Do not place objects in the space under the table to avoid damaging during the movement. - Page 12 After initial setting of the table, unpack it from the transport foil and plug the power cord into the mains socket, which is freely accessible when using the table. If the power cord is disconnected from the controller, re-connect it as follows: ①...
-
Page 13: Operating The Table
6. OPERATING THE TABLE CAUTION ! Always maintain a safe distance from the table mechanisms operating at the time of adjusting the height and position of the section table. Moving parts pose a risk mechanisms crease CAUTION ! When using other electrical appliances near the table, make sure that their power cables are not clamped or damaged by moving parts of the table. - Page 14 Height adjustment in the MERCURY, JUPITER and SATURN tables is done by means of a foot controlled frame located at the bottom of the table. To lift the table, push the frame in the direction of the head rest (B). To lower it, push the frame in the direction of the leg rest (A). The table will be lifted or lowered as long as the foot controller frame is kept in its leftmost or rightmost position.
-
Page 15: Adjustment Of The Front (Rear) Section Inclination/Declination Angle
Adjustment of the front (rear) section inclination/declination angle 6.3. CAUTION ! Before adjusting the table, the user should make sure that the patient is in a safe position. CAUTION ! Do not insert your fingers into the gaps between the segments of the table, as this could trap them when lifting or regulating and the position of the table. -
Page 16: Height Adjustment Of The Sides In The Headrest Part
Picture17- Postural Drainage adjustment in GALAXY massage table (version with height adjustment system) Picture 18- GALAXY Postural Drainage adjustment in GALAXY massage table (version with hydraulic height adjustment system) 6.5. Height adjustment of the sides in the headrest part In the Galaxy type MERCURY model S4.Fx, S4.Fx-H, JUPITER S5.Fx, S5.Fx-H and SATURN model P5.Fx, P5.Fx-H there is a possibility of adjusting the height of the sides in the headrest part. -
Page 17: Access Lock (Not Applicable To -H Models)
set in two positions: - WORK (A) - with the table resting on its feet, which can be adjusted for leveling (by screwing the foot in and out – see section 6.1; - TRANSPORT (B) - with the table resting on 4 castors enabling it to be transported. Bottom frame type F0 has two feet at the headrest side and two wheels at the opposite side. -
Page 18: Maintenance
Locked Active Picture 20 – Operation of access lock mechanism Blockade Work Picture 21 – Operation of access lock mechanism in CLASSIC model 7. MAINTENANCE CAUTION ! We recommend cleaning and/or disinfecting the upholstered surfaces and other parts of the tables after each use to ensure proper hygiene level. CAUTION ! Before starting the cleaning of the table make sure that the electrical power supply cable has been disconnected from the supply in the room to prevent accidental... -
Page 19: Cleaning The Upholstery
Avoid extensive wetting of the surface of the table. Disinfect the upholstery and other surfaces using the mild antibacterial detergent. A list of recommended disinfectants is available in the DJO on request. Never use: - cleaning paste, wax, sprays;... -
Page 20: Checking The Gas Springs
Any defects in the operation of the actuator should be reported immediately to DJO for technical service and operation of the table stopped until the cause of the fault has been removed. -
Page 21: Troubleshooting
8.0. TROUBLESHOOTING Failure indication Possible cause Action to be taken If necessary, take the patient from the table with the user's help. To restart the controller,remove the mains plug from the mains electrical outlet in the room and the access lock from the socket and wait for a minimum 1h. - Page 22 WARNING: Use of this equipment adjacent to or stacked with other equipment should be avoided because it could result in improper operation. If such use is necessary, this equipment and the other equipment should be observed to verify that they are operating normally. WARNING: Use of accessories, transducers and cables other than those specified or provided by the manufacturer of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and result in improper operation.
- Page 23 Power frequency 30 A/m 30 A/m Power frequency magnetic fields should be at (50/60 Hz) levels characteristic of a typical location in a magnetic field typical commercial or hospital environment. IEC 61000-4-8 NOTE U is the a.c. mains voltage prior to application of the test level. Guidance and manufacturer’s declaration –...
-
Page 24: Warranty Card
9. The warranty does not cover consumable materials and components (eg gaskets, cables, etc.). 10. DJO Global is not responsible for the safety of the user or the patient during the operation of the installed equipment in case of failure to comply with the supplied installation and operating instructions. - Page 25 Repairs Registry Users Notes 2019-08-30 Galaxy massage - User Manual.doc Page 25 z 25...
