Summary of Contents for CPS Cat 5 Pro
- Page 1 Cat 5 Pro Vacuum OPERATOR’S MANUAL Concrete Polishing Solutions PO Box 520 * Norris, TN 37828 Phone: (865) 494-8200 * Fax: (865) 494-8300 Toll Free: (877) 472-8200 * www.go2cps.com...
-
Page 2: Table Of Contents
We are excited about you joining the growing future of Polished Concrete. When you match up the Cat 5 Pro with the G-320DP or the G-250P , you will now have the capability to go completley cordless. Propane Grinding is the most practical and innovation technology for the concrete flooring industry. -
Page 3: General Information
We advise that you thoroughly check all cartons before you sign for the order. Any claims for merchandise damaged in transit must be filed with the delivering carrier, not CPS. Our Return Policy Please open and inspect your order upon receipt. If you have an issue, please contact a member of our sales and technical staff first so that we can resolve that issue in as short a time as possible. - Page 4 The foregoing may not be altered except by an agreement signed by at least two of the officers of Concrete Polishing Technologies, Inc. CPS will not be liable for delays in shipping due to circumstances beyond the control of CPS. Warranties will not apply if after market alterations, changes, or modifications have been made to the equipment.
-
Page 5: Delivery & Specifications
If damage is discovered, immediately notify the transportation company who delivered your machine. The following items should be included with the delivery of your Cat 5 Pro Vac; please contact Customer Service if anything is missing: a. Cat 5 Pro Vacuum b. -
Page 6: Introduction
A secondary HEPA filter assembly is also a standard feature on your CAT 5 Pro vacuum to capture 99.97% of dust down to 0.3 micron particle size. -
Page 7: Sequence Of Operation
When your CAT 5 Pro vacuum is new for your operators, it will be necessary to experiment with it to determine how long it takes to fill the collection bag. The unique design of the CAT 5 Pro vacuum allows the operator to control the weight/volume of the material in the collection bag to suit his individual or his company’s needs. -
Page 8: Filter Maintenance
Concrete Polishing Solutions- Cat 5 Pro Vacuum Operator’s Manual FILTER MAINTENANCE Filter Maintenance: The CAT 5 Pro vacuum is designed to pick up the finest concrete grinding dusts. It is expected that over some period of time, dust will accumulate on the filter from normal operations. However, if... - Page 9 Concrete Polishing Solutions- Cat 5 Pro Vacuum Operator’s Manual FILTER MAINTENANCE Filter Mounting Hardware- 7) While the filter cover assembly is removed from the vacuum, inspect the edge trim on the top of the filter housing and the gasket on the underside of the filter cover. If there are any gaps or damage, replace these items before continuing vacuum operation.
-
Page 10: Secondary Hepa Filter
SECONDARY HEPA FILTER Secondary HEPA Filter Your CAT 5 Pro vacuum is equipped with a standard secondary HEPA filter. It is necessary to inspect the HEPA filter regularly for damage or leaks. If there is dust exiting the vacuum through the vacuum producer outlet, the secondary filter has failed in some way and it is necessary to be replaced. -
Page 11: Other Maintenance
If your CAT 5 Pro is used as a portable vacuum, regularly check your wire connections between the battery and the solinoid to make sure that they are tight. Frequent moves encountered with portable equipment can result in loose wires. -
Page 12: Continuous Bagging System
Concrete Polishing Solutions- Cat 5 Pro Vacuum Operator’s Manual CONTINUOUS BAGGING SYSTEM Continuous Bagging System A) INSTALLING NEW BAGS 1) Remove the black plastic holder by pressing the three spring steel tabs on the bottom of the metal adaptor. **Note: When the tabs on the bottom are pressed inward, the plastic bag holder will slide downward for removal. - Page 13 Concrete Polishing Solutions- Cat 5 Pro Vacuum Operator’s Manual CONTINUOUS BAGGING SYSTEM CON’T 4) Pull the lose outer end of the continuous bag downward and bring the edges together until there is enough material to tie it off with a tie-wrap to form the bottom of the first bag as shown in photos #4 and #5.
- Page 14 WITH THE DISCHARGE VALVE OPENING OR CLOSING. B) DISCHARGING MATERIAL INTO A COLLECTION BAG The CAT 5 Pro vacuum is equipped with a non-powered discharge valve that opens automatically when the vacuum is shut down or a filter cleaning operation is taking place. Collected debris will discharge from the primary filter housing into the collection bag.
-
Page 15: Manual Backwash Filter Cleaning
Concrete Polishing Solutions- Cat 5 Pro Vacuum Operator’s Manual MANUAL BACKWASH FILTER CLEANING While vacuum is operating, close Manual Blocking valve on inlet manual blocking valve on inlet to vacuum cleaner in operating to vacuum cleaner. position. Vacuum gauge indicates maximum vacuum at 7”-8”... - Page 16 INTERNATIONAL POLISHED CONCRETE INSTITUTE, LLC A CPT INSTITUTION 24/7 Technical Support- Toll Free 1-877-472-8200...
