GT PARAGON DL05 Manual

PARAGON
DL05 / DL05WM
HAIR DRYER
Before installing and using this unit, please carefully
read these instructions. Be sure to keep this
available for later reference.
120V, 650/1000W , 5.42/8.33amps
PARTS LIST - STAND
1. Cross Bars (2pcs)
2. Caster Wheels (4pcs)
3. End Caps & Nut (4sets)
4. Top Cap Flange
5. Bottom Cover
6. Flat Washer
7. Spring Washer
8. Bolt
9. Pole Assemble
10. Screw Knob
11. Inner Pole
CAUTION: DO NOT insert inner pole alone into pole
assembly. Strong spring tension may cause serious
injury during assembly / disassembly.
®
STAND ASSEMBLY
REMOVE ALL PACKING MATERIAL BEFORE ASSEMBLING
1. Install end caps using the nuts provided
2. Twist / push in caster wheels
3. Place the cross bars perpendicular to one another
with the caster wheels facing down
4. Place the plastic cap over the cross bars
5. Secure cross bar assembly with bottom cover using
flat washer, spring washer, and bolt. To keep the
stand from wobbling check that the bolt is securely
and tight.
6. Place the pole assembly onto the cap flange
7. Insert the inner pole into the pole assembly and
secure with screw knob.
8. Carefully place the dryer head onto the stand and
secure with screw.
OPERATION
DRYER SHOULD ONLY BE USED ON A STURDY FLAT
SURFACE. THE ROLLER STAND IS INTENDED TO STAND
ON THE FLOOR. DO NOT PLACE ON ELEVATED
SURFACES LIKE TABLES AND ETC.
General Operation
1. Plug unit into power source
2. Select the desired heat setting (68°-131°F)
3. The timer knob turns the unit ON/OFF (0-60min)
4. Select the desired time setting
5. Lower hood over clients head
Adjusting the Wind Volume
To adjust the wind volume, push in/out the side tab located on
the hood.
