Summary of Contents for SRP GT
- Page 1 OTHER LANGUAGES, DOWNLOAD THE MANUAL AT SIMRACING-PRO.COM SPANISH FRENCH PORTUGUESE ITALIAN GERMAN...
-
Page 3: Table Of Contents
INDEX 1. GENERAL INFORMATION ....................3 1.1. Preliminary warnings ..................... 3 1.2 Manufacturer's address: ..................3 1.3. Technical Service Address ..................3 2. DESCRIPTION OF THE PEDALS..................4 2.1. General description ....................4 2.2. List of parts supplied....................4 2.3. Working principle ....................4 2.4. - Page 4 8.2. Replacement of elements ..................14 9. ATTACHMENTS ......................15 9.1. Plan of general measures: ................... 15 10. DECLARATION OF CONFORMITY ................16 11. “CE” BRANDING ......................17 12. WARRANTY ....................... 17 13. RECEIPT OF TECHNICAL DOCUMENTATION ............. 17...
-
Page 5: General Information
1. GENERAL INFORMATION 1.1. Preliminary warnings Be sure to observe the safety and warning notes in this manual when using the pedals. It is essential that you follow these instructions for the pedals for issue-free operation and to be able to file a claim under the warranty. The pedals must be used for the purpose for which they were built. -
Page 6: Description Of The Pedals
1 pc. 10 mm open-end wrench 1 pc open end wrench 13 mm 1 x 2m USB cable / USB-C to USB-A 1 user manual / CE certificate 1 Warranty form 2.3. Working principle The SRP GT pedals They have the following functions: Driving Simulation... -
Page 7: Intended Use
2.4. Intended use Driving simulation when playing PC car racing games. Do not carry out activities other than those for which the pedals are designed with elements other than those indicated here. The manufacturer of the pedals declines all responsibility for failure to comply with this warning. Do not exceed the working capacity of the pedals. -
Page 8: Warnings And Safety Instructions
Weight and dimensions Model Length, mm. Width, mm. Height, mm. Weight, Kg. SRP GT 8.1 KG See general dimensional drawing 9.1. 4.3. Storage No particular measures are recommended with regard to storage. If the user leaves it unused for a long time, it is recommended to protect it from dust by covering it properly and disconnecting it from any power source beforehand. -
Page 9: Location
5. LOCATION The pedals have been designed and are built expecting their assembly. -
Page 10: Unpacking
5.1. Unpacking After transport and unloading, with the pedals in the vicinity of the intended assembly site, unpacking should be carried out with the utmost care and attention. The pedals should not be installed if any damage is observed during unpacking. In case of questions, do not use the product and ask the supplier for information. -
Page 11: Reviews Before Starting
-The electrical connection of the pedals is 5V via USB. As indicated in the data sheet, or in the general dimensional and connection drawing. - The pedals require a stable, standardised supply voltage that is between the operating ranges of the pedals for proper operation. -
Page 12: Instructions For Use
7. INSTRUCTIONS FOR USE 7.1. Pre-inspection and adjustments ● Before starting the machine, check that the pedals are connected correctly. ● Check the status of the LED indicators to determine that everything is correct. See point 6.2 7.2. Uses of the controls The pedals have two/three pedals, depending on the model. - Page 13 By unscrewing the two screws A (see enclosed drawing) the cams can be adjusted in the range of 70° to 90° Recommendations: 70º seat position in GT 90º seat position at F1 (lying down) Applicable to the three cams accelerator, brake and clutch.
- Page 14 Loosen screw B (see drawing below) to raise the piston for more firmness and to lower it for less firmness. Applicable to all three pistons equally: accelerator, brake and clutch. BRAKE TRAVEL ADJUSTMEN Watch video tutorial on SRP YouTube channel: srp simracing-pro...
-
Page 15: Download And Use Of The Application
THROTTLE TRAVEL ADJUSTMENT. By loosening the hexagon socket screw C (see enclosed drawing), unscrewing part D shortens the route. Unscrew a max. of 15 mm The pedal is supplied at a maximum route. 7.4 - Download and use of the application. Download the application in the download area of the website simracing-pro.com Execute and follow the steps of the application for a good configuration. -
Page 16: Maintenance
8. MAINTENANCE 8.1. General cleaning Introduction It is advisable that you dust the machine periodically. DO NOT use cleaning fluids in the area of the plate, as this could cause damage to the machine. Remember that by keeping the machine in an optimum state of cleanliness and maintenance, its performance will be better and it will last longer. -
Page 17: Attachments
9. ATTACHMENTS 9.1. Plan of general measures:... -
Page 18: Declaration Of Conformity
10. DECLARATION OF CONFORMITY... -
Page 19: Ce" Branding
11. “CE” BRANDING The plate is stamped with the manufacturer's brand, the CE conformity brand and the manufacturer's social information. On the top of the plate, the specific data of the pedals is specified: brand, model, serial number and year of manufacture. The last box contains the essential technical data of the pedals: the voltage, 12.
