Motor City Wash Works CROSS-OVER WRAPCHYD03 Series Installation Manual

For cotton cloth, star foam or c-channel foam brushes
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

TABLE OF CONTENTS

Troubleshooting.......................................................................................................................Page: 43
Exploded Views.......................................................................................................................Page: 47
Warranty................................................................................................................................Page: 61
Equipment Utilities
ELECTRICAL
120 VAC, 1 PH, 12 W VALVE UL® CERTIFIED
HYDRAULIC
PNEUMATICS
(INCLUDING OPTIONAL RETRACT PANEL)
WATER
Equipment Specifications and Features
Convenient 115VAC Single Phase Supply Minimizes Installation Cost
Compact Design: Utilizes only 14'-0" of Tunnel Space
Only 10'-00" Overall Height
Vehicle Clearance of More than 91"
Supplied Standard with MCWW Foam Streamers™ for Added Lubrication and Cleaning
Great Cleaning up to 180 CPH
Aluminum Structure with Color Skinz™ Snap-On UHMW Colored Covers... Great Appeal!
Electric or Hydraulic Drive Available
Choice of Cleaning Media between Cotton Cloth™, C-Channel and Star Foam
© Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A.
8MANLWRPCROVR01
FOR COTTON CLOTH™, STAR FOAM or C-CHANNEL FOAM BRUSHES
HYDRAULIC DRIVE
WRAPCHYD[ . . . . . ]03
6 GPM @ 1000 PSI
2 SCFM @ 100 PSI
RECLAIMED OR FRESH:
4 GPM @ 40 PSI
www.motorcitywashworks.com
09-16-20
CROSS-OVER™ INSTALLATION MANUAL
Part # WRAPCHYD[ . . . . . ]03
ELECTRIC DRIVE
WRAPCELE[ . . . . . ]03
POWER:
120 VAC, 1 PH, 12 W VALVE UL® CERTIFIED
MOTORS:
3 HP (2 X 1.5 HP)
13.2-6 AMP @ 208-460 VAC, 3 PH
UL® RECOGNIZED, CSA CERTIFIED, CE MARK, IEC IP 55
N/A
2 SCFM @ 100 PSI
(INCLUDING OPTIONAL RETRACT PANEL)
RECLAIMED OR FRESH:
4 GPM @ 40 PSI
Phone: 248.313.0272 ▪ Fax: 248. 313.0271
WRAPCELE[ . . . . . ]03
Page: 1
Page: 1
Page: 2
Page: 2
Page: 12
Page: 17
Page: 18
Page: 20
Page: 22
Page: 23
Page: 24
Page: 25
Page: 28
Page: 33
Page: 40
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CROSS-OVER WRAPCHYD03 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Motor City Wash Works CROSS-OVER WRAPCHYD03 Series

Summary of Contents for Motor City Wash Works CROSS-OVER WRAPCHYD03 Series

  • Page 1: Table Of Contents

    Aluminum Structure with Color Skinz™ Snap-On UHMW Colored Covers… Great Appeal!  Electric or Hydraulic Drive Available  Choice of Cleaning Media between Cotton Cloth™, C-Channel and Star Foam Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 2: Suggested Tools And Installation Materials Page

    Locate where the wrap around will be installed and verify that the area is sufficiently large for your MCWW CROSS-OVER™ WORKING ENVELOPE and DIMENSIONS (see Picture #1 though #5). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 3 Pic #1 Cross-Over™ with Cotton Cloth™ Overall Envelope 15'-5" [185"] 14' [168"] Pic #2 Cross-Over™ with Foam Overall Envelope Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 4 Pic #3 Cross-Over™ with Cotton Cloth™ Overall Dimensions 15'-5" [185"] 19' [228"] Pic #4 Cross-Over™ and Accelerator™ Top Wheel Overall Envelope Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 5 Position the BACK OF THE DRIVER’S SIDE LEG 45” AWAY FROM THE INSIDE EDGE OF THE INSIDE GUIDE RAIL (See Picture #7). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 6 LEVEL THE DRIVER’S SIDE LEG as well as THE HEAD ASSEMBLY. Finally, LEVEL THE PASSENGER’S SIDE LEG and secure to the floor. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 7 Remove the PASSENGER’S SIDE PRIMARY ARM POSITIVE STOP ASSEMBLY, FLIP AROUND AND SECURE TO THE CROSS BEAM (as shown in Picture #11). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 8 8” X 48”OD-1/4” 8” X 48”OD-1/4” 10” X 48”OD-1/4” Pic #12 Star Foam Hub Pic #13 Star Foam Hub Assembly Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 9 CLAMPS holding the cores in place (as shown in Picture #18 and 19). Raise or lower the entire core assembly. Re-tighten the clamps in the new position. Re-install the core piece. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 10 3/8” SLASH 1/8” THICK 8”X18”-0”AC 3/8” SLASH 1/8” THICK 10”X18”-0”AC 3/8” SLASH 1/8” THICK Pic #20 Bottom Hub Fill Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 11 10" X 23" 16 PCS 3/8" SLASH 1/8" THICK Pic #23 Top Hub Fill Pic #21 Top Hub Fill Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 12: Electrical Installation Page

    You may power your CROSS-OVER™ WRAP AROUND on either the driver’s side or the passenger’s side CONNECTION BOXES (as shown in picture #24 below). (NEUTRAL) 8 DCALWRPPNL0003 Pic #24 Electrical Box Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 13 TO THE MOTOR LEADS, FOLLOWING THE APPROPRIATE CONNECTION DIAGRAM BELOW OR ON THE MOTOR PLATE (PICTURE #26) FOR PROPER VOLTAGE. Pic #26 Motor Connection Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 14 RETRACT AIR PANEL, CONNECT THE OVERLOAD CONTACTS WITH THE EMERGENCY STOP CIRCUIT (SEE PICTURE #28). Pic #27 Starter with Air Panel Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 15 VFD’S FAULT CONTACTS. IN THE EVENT OF A FAULT FROM THE VFD, THE WRAP HAS TO BE RETRACTED TO AVOID POSSIBLE DAMAGES TO THE CAR OR THE EQUIPMENT. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 16 Pic #29 Inverter Panel Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 17: Pneumatic Installation Page

    2 SCFM @ 100 PSI 3/8" OD FOR AIR 3/8" OD PUSN-ON FITTING 1/2" OD FOR SOLUTION Pic #30 Utilities Location Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 18: Optional Retract Air Panel Installation Page

    Connect the air panel SOLENOID VALVE to ONE 120 VAC OUTPUT FUNCTION from the car wash controller and through the STARTER PANEL or the INVERTER PANEL (see picture #27 AND 29). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 19 MAIN AIR INLET Pic #32 Retract Air Panel CONNECT 3/8” AIR LINE TO RETRACT AIR PANEL Pic #33 Secondary Cylinder Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 20: Optional Mirror Bump Air Panel Installation Page

    STAY ON UNTIL THE DRIVER’S SIDE WHEEL HAS PASSED BEYOND THE MIRROR AREA (OR ABOUT 9’ LONG). Pic #35 Bump Air Panel 12” Before Front of Car Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 21 Set the air pressure of each air panel regulator to about 10 TO 20 PSI LESS THAN THE PRIMARY CYLINDER AIR PRESSURE. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...

  • Page 22: Foamer Installation Page

    IT CAN BE PURCHASED SEPARATELY THROUGH YOUR LOCAL MCWW DISTRIBUTOR (PART# FOAMDLUTNSTN001). 3/8" AIR LINE 1/2" SOLUTION LINE Pic #38 Streamers Air-Solution Lines Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 23: Water Feed Installation Page

    CROSS-OVER™ WRAP AROUND UNIT; IT CAN BE PURCHASED SEPARATELY THROUGH YOUR LOCAL MCWW DISTRIBUTOR (PART# APPLDLNSTN004). Pic #40 Water Connection Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 24: Hydraulic Installation Page

    PERFORMANCE OF THE EQUIPMENT AND LEAD TO PREMATURE WEAR OR MAJOR DAMAGE TO THE CROSS-OVER™ HYDRAULIC SYSTEM OR ITS COMPONENTS. Pic #40 Hydraulic Schematic Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 25: Start-Up Procedures Page

    FAILURE TO DO SO MAY LEAD TO MAJOR EQUIPMENT DAMAGE IF ONE OF THE TWO WRAP MOTOR OVERLOAD RELAYS TRIPS OR MALFUNCTIONS. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 26 Pic #41 Cross-Over™ Air Panel Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 27 PORTION OF CLEANING ON THE REAR OF THE VEHICLE. Pic #43 Positive Stop Position 1 Pic #44 Positive Stop Position 2 Pic #45 Positive Stop Position 3 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 28: Operation Page

    P/S PRIMARY ARM Pic #46 Cross-Over™ Arms D/S PRIMARY LIMIT SWITCH P/S PRIMARY LIMIT SWITCH Pic #47 Cross-Over™ Limit Switches Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 29 PRIMARY LIMIT SWITCH (see Picture #41) turning OFF the solenoid valve, releasing the air slowly from the SECONDARY ARM. LIMIT SWITCH OPENS Pic #49 Vehicle Push D/S Wheel Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 30 SECONDARY ARM again (See Picture #52). The secondary arm is now fully knuckled back and ready to extend and clean the rear area of the vehicle. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 31 If the secondary arm is not wiping the rear of the vehicle fast enough and can’t keep up with the conveyor speed, INCREASE THE SECONDARY AIR PRESSURE (see Picture #41). LIMIT SWITCH CLOSES Pic #53 D/S Secondary Arm Extends Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 32 Finally, the secondary arm will finish its travel (wiping) and OVERLAPPING the middle area of the vehicle rear end (see Picture #55). WHEEL CROSSES OVER THE MIDDLE AREA Pic #55 P/S Secondary Arm Cross Over Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 33: License Plate Adjustment Page

    Repeat same with the DRIVER’S SIDE.  In the mechanical room, Locate and secure the air panel to the wall (see Picture #3). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 34  Connect the existing blue air line to the blue line coming from the new cylinders (see picture below). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 35 NOTE: CHANGING SECONDARY ARM BUMPER STOP POSITION WILL CHANGE THE BUMP OUT OVERALL TRAVEL DIMENSION Pic 5: Adjusts Bumper Stops Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 36 Primary and Secondary Connections (With All Options) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 37 (DRIVER’S or PASSENGER’S SIDE) and that both brushes are moving out (as shown on picture #7 below). Pic 7: Test Bump Out Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 38 Pic #8 Turn ON DRIVER SIDE Air Panel 12” Before Front of Car Pic #9 Turn ON PASSENGER SIDE Air Panel 12” Before Front of Car Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01...
  • Page 39 PAN EL - OPTIONAL N EW L IC ENSE PLA TE B UMP VA L VE PANEL Pic #11 Air Schematic Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 40: Maintenance Page

    Wash your equipment with a solution made of a mild degreaser and water. Rinse thoroughly.  Perform daily maintenance. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 41 Pic #50 Passenger Side Wheel Bearings GREASE POINTS GREASE POINTS Pic #51 D/S Secondary Arm Bearings Pic #52 P/S Secondary Arm Bearings Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 42 GREASE POINTS GREASE POINTS Pic #53 P/S Primary Arm Bearings Pic #54 D/S Primary Arm Bearings Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 43: Troubleshooting

    <https://store.motorcitywashworks.com/Team360/CrossoverWraps/Documents/Media%20Links%20Cro ssOverWraps.pdf> For all of MCWW current manuals, videos, bulletins and information click the below link. <MCWW Documentation Hub> Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 44 “With MCWW supplied Check that MAC valve retract panel”. is energized allowing air to flow to the Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 45 Ensure primary arm has engaged limit switch(s). Verify primary arm limits switch(s) are Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 46 Verify brush spin signal is not turning off before wash is completed. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 47: Exploded Views

    Exploded Views: Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 48 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 49 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 50 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 51 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 52 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 53 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 54 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 55 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 56 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 57 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 58 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 59 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...
  • Page 60 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. www.motorcitywashworks.com 8MANLWRPCROVR01 09-16-20...

  • Page 61: Warranty

    Warranty and Return Procedure: Motor City Wash Works warrants this product to be free of defects in material and/or workmanship for a period of one year. During the warranty period MCWW will at its discretion, at no charge to the customer, repair or replace this product if found defective, with a new or refurbished unit, not to include costs of removal or installation.
