Kodiak LGSG13HC Operator's Manual

Gas powered professional stump grinder

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

LGSG13HC

original instruction

Uniguip

2013

Table of Contents

Need help?

Do you have a question about the LGSG13HC and is the answer not in the manual?

Questions and answers

Summary of Contents for Kodiak LGSG13HC

Page 1 LGSG13HC original instruction Uniguip 2013...
Page 2: Table Of Contents
14-16 A. Positioning the LGSG13HC B. Starting the LGSG13HC C. Stump grinding on level surfaces D. Stump grinding below ground E. Shutting down the LGSG13HC Storing the LGSG13HC Maintenance Procedures A. Inspection Schedule B. Preventative Maintenance Procedures 1. Cleaning the LGSG13HC 2.
Page 3: Pre-Operation Note
Powered by a 13 hp HONDA engine, the LGSG13HC is a powerful unit driving tough 355mm cutter wheel with eight replaceable carbide teeth to make stump removal fast and easy. The LGSG13HC has many features which are designed to improve your working experience.
Page 4: Safety Precautions
Safety Precautions 1. READ AND UNDERSTAND OPERATOR'S MANUAL PRIOR TO USE OF STUMP GRINDER 2. Before operating stump grinder, ensure that it is structurally and mechanically safe by checking the following: a. Are all engine controls and the clutch action functioning within acceptable tolerances? b.
Page 5 Safety Precautions cont'd f. ROTATING STUMP GRINDER WHEEL CAN CAUSE SERIOUS INJURY OR DEATH. DO NOT ATTEMPT TO PERFORM ANY REPAIRS, SERVICE, OR DIAGNOSTICS OR TO TRANSPORT OR MOVE THE UNIT UNTIL CUTTER WHEEL HAS COME TO A COMPLETE STOP. FAILURE TO DO SO MAY RESULT IN DEATH g.
Page 6: Guide To Parts Breakdown
This guide aims to serve as a representational guide to the LGSG13HC. Any other uses or application beyond the scope of this document are strictly prohibited. While every attempt has been made to maintain its accuracy The producer reserves the right to update and modify the equipment without prior notification.
Page 7: Machine Parts Breakdown
Machine Parts Breakdown LGSG13HC...
Page 8 Machine Parts Breakdown LGSG13HC...
Page 9: Parts List
Parts List...
Page 10 Parts List...
Page 11 Parts List...
Page 12: Machine Overview 1O-11
Machine Overview The following is a list of important control and operation mechanisms with which the operator must be familiar PRIOR to using the stump grinder. Failure to do so may result in severe injury and/or fatality to the operator and others and may lead to reduced machine life or damage to the stump grinder.
Page 13 Machine Overview cont'd...
Page 14: Contents List
DO NOT ATTEMPT ASSEMBLY OR OPERATION WITHOUT ANY OF THESE LISTED PARTS! Pre-Operation Procedures Before using the LGSG13HC Professional Stump Grinder, please perform the following procedures for the personal and property safety of the operator and jobsite and for optimal performance.
Page 15: Pre-Operation Procedures
Operation Procedures A.Positioning the LGSG13HC 1. Ensure that the stump grinder is completely turned off prior to adjusting or relocating the unit. 2. Position the cutter wheel above the top edge of the stump that is closest to you (see Point A, Figure 1 ) 3.
Page 16: Starting The Lgsg13Hc
Opeation Procedures cont'd B. Starting the LGSG13HC 1. Ensure that the cutter wheel off the ground before starting engine. Follow instructions in the engine m anufacturer's manual to properly start the engine. 2. Start the machine by pulling the start/stop switch located on the control panel.
Page 17 Opeation Procedures cont'd 5. If there is a need to reposition the stump grinder, follow these directions: a. Release the operator presence loop and press the start/stop switch to turn the machine off and follow the engine manufacturer's instructions on shutting down the engine. Ensure that the cutter wheel has come to a complete stop.
Page 18: Stump Grinding Below Ground
3. Apply brake, start engine and press cutting zone of cutter wheel into stump. 4. Remove stump with back and forth motion that is described in section C (see Figure 7) E. Shutting down the LGSG13HC 1. Place throttle in slow position and then stop engine by pushing start/stop switch on control panel.
Page 19: Maintenance Procedures
B. Preventative Maintenance Procedures Maintaining a regular cleaning and lubrication schedule as well as taking time to perform preventative maintenance procedures will prolong the service life of the LGSG13HC. The following are guidelines to setting up a regular maintenance routine for thestump gringder 1.Cleaning the...
Page 20: Maintenance Schedule
3. Lubrication Schedule Regularly scheduled lubrication of the LGSG13HC is essential to smooth performance and extended equipment life. The following schedule is a recommended guide to lubricating your LGSG13HC. The schedule should be adjusted for various environmental conditions and frequency of use.
Page 21: General Service Procedures
Maintenance Procedures cont'd .. C.General Service Procedures The following are general guidelines for servicing common wear components on the LGSG13HC Stump Grinder. ALL MAINTENANCE AND SERVICE WORK MUST BE PERFORMED BY A TRAINED AND EXPERIENCED TECHNICIAN. Ensure that the work area is clean and free of debris prior to starting any maintenance or service work. Small particles may become trapped in key components that may lead to serious damage to the machine and cause severe bodily harm to the operator or technician.
Page 22: Brake Adjustments
Maintenance Procedures cont'd .. 2 Brake adjustments The LGSG13HC Stump Grinder is designed to permit both fine and high travel brake adjustment. During adjustment, inspect all parts and replace any that are worn or damaged. i. Fine travel adjustment a. Place brake lever handle in released position.
Page 23: Changing The Teeth
Maintenance Procedures cont'd .. 3.Changing the teeth Do not proceed with tooth removal until engine is cool. Do not change teeth until the engine has been disabled. Disable engine by removing key from switch and then removing spark plug wires and battery cable. Be sure to wear personal protective equipment.
Page 24: Sharpening Cutter Teeth
Maintenance Procedures cont'd .. 4. Sharpening cutter teeth Sharpening stump grinder teeth produces dust that is hazardous to people and animals. Do not sharpen teeth in the absence of a dust collection system and adequate ventilation. Cutting tools may shatter if they are misused. Be sure to use shields and eye protection when sharpening or in the vicinity of sharpening.
Page 25: Adjusting The Drive Belt
Maintenance Procedures cont'd .. 5 Adjusting the drive belt Do not proceed with drive bolt adjustment until engine is cool. Do not adjust drive belt until engine has been disabled. Disable engine by removing key from switch and then removing spark plug wire and battery cable. Be sure to wear personal protective equipment.
Page 26: I Nformation On Safety Decals
INFOMTION ON SAFETY DECALS Below are the decals available for re-ordering to facilitate maintenance. All decals are available for replacement except that with the serial number of the unit for each number serves as an unique identifier for warranty and support purposes. If you have any questions, please do not hesitate to contact your local weibang authorized dealer for further assistance.
Page 27 Notes...
