RACK AND PINION HOIST
MABER
ONE-PHASE
INSTRUCTION AND MAINTENANCE MANUAL
THIS MANUAL IS AN INTEGRATED PART OF THE MACHINE
IMPORTANTE WARNING:
This instruction manual should be completely read carefully before putting the equipement to
use; all the assembly instructions, the use and maintenance must be precisely
precluded to unauthorized personnel.
MABER costruzioni srl
36050 Bressanvido (VI) Italy via S. Benedetto, 14/P z.a.
Telefono: +39-0444-660871 Fax: +39-0444-660872
14/09/98 –libretto uso manutenzione MB500/120 - SP
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB500/120-SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Maber MB500/120-SP

  • Page 1 This instruction manual should be completely read carefully before putting the equipement to use; all the assembly instructions, the use and maintenance must be precisely precluded to unauthorized personnel. MABER costruzioni srl 36050 Bressanvido (VI) Italy via S. Benedetto, 14/P z.a. Telefono: +39-0444-660871 Fax: +39-0444-660872...

  • Page 2: Table Of Contents

    PREFACE This manual is supplied along with the sold machine and contains guidelines for its transportation, assembly, operation and maintenance, as specified in the guidelines outlined in the EU 89/392 Machine directive. CONTENTS List of sections and paragraphs with page references: Analytical index page 38 CE declaration of Compliance...

  • Page 3: "Ce" Declaration Of Compliance

    This declaration issued by the manufacturer must be stamped and signed by the same and stored with the original machine documentation. MABER Costruzioni s.r.l. whose legal head office is in 35014 Fontaniva - Padova - Italy - Via Casoni Basse, 16 and whose offices and plant are in Via S.

  • Page 4: Machine Identification

    The equipment of which to the present manual is identified by the following elements, that which must be cited with a request for additional information of replacement: MANUFACTURER: MABER Costruzioni s.r.l. Via S.Benedetto, 14/P 36050 Bressanvido VICENZA (ITALY) CLIENT: CITY/TOWN:...

  • Page 5: Description Of The Machine

    DESCRIPTION OF THE MACHINE The MB 500/120 SP RACK AND PINION HOIST is a goods lift that allows elevation up to 120 m. in height, along the support column, anchored to a wall or scaffolds designed to bear loads transmitted up to a max. load. of 300 kg. The lift is basically made up of the following parts: A base fitted with adjustable worm screws.
  • Page 6 The drawing illustrates the standard basic version of the machine: The machine is fitted with a separate centrifugal-mechanical emergency brake (patented) that automatically starts up if the descent speed exceeds approx. 20% of the normal preset values. The device enables a ratchet gear that allows the deck to stop in a damped and gradual way at any point of the vertical column.

  • Page 7: Machine Application

    MACHINE APPLICATION The MB 500/120 SP RACK AND PINION HOIST must be used only to lift goods and equipment up to a maximum loaded weight evenly distributed on the deck of 300 kg. The equipment may be only used for professional purposes by personnel authorised by the owner over 18 years of age and who have been previously trained in compliance with the regulations and guidelines of this manual.

  • Page 8: Unauthorised Uses Of Lift

    In MB 500/120 RACK AND PINION HOIST operation any misuse of the equipment is not allowed. This particularly includes: - carrying persons and animals, - carrying protruding loads, - carrying goods that have not been properly tied, - carrying loose goods, - Operation in harsh weather conditions (thunder storms, wind, snow etc.) - Operation in conditions of poor visibility (fog, night darkness etc..) - Operation in wind speeds over 40 km/hour when assembling the rack...

  • Page 9: How To Consult The Manual

    The manufacturer’s guarantee is valid for 12 months after the delivery date of the equipment and is limited to the replacement of parts that are to the incontrovertible judgement of the manufacturer defective due to materials used or to manufacturing . La guarantee is always and only valid for goods delivered ex works and any other kinds of compensation, besides the description in the above point, are not considered.

  • Page 10: Technical Description

    TECHNICAL DESCRIPTION The MB 500/120 RACK AND PINION HOIST is a machine designed to elevates goods up to 300 kg. A motor-powered moving deck slides on a special vertical column up to 120 m in height. The vertical column is attached to the wall or support frame every 6m. The base (1) is made up of a welded tubular frame, at the end of which 4 worm screws (2) are installed to regulate vertical alignment of the machine.
  • Page 11 The motor drive unit (11) is made up of a welded tubular bar and section bar frame. It is fitted with a series of guide rollers. It is driven by a self-acting electric gear motor (12) that enmeshes on the rack of the vertical column (3) via a pinion,. An emergency brake (14) starts when (in descent) the normal operating speed is exceeded.

  • Page 12: Specifications

    SPECIFICATIONS Working capacity on the storey (evenly distributed load) 300 kg. Max. height of the vertical column: 120 m. Lifting speed: m/min. Height of the vertical column modules: 1.5 m/each Weight of the vertical column modules: kg/each Max. vertical distance of the wall securing bolts: Height from ground of the temporary assembly and disassembly bolt: Deck width: 1.5 m.

  • Page 13: Safety Regulations

    SAFETY REGULATIONS The MB 500/120 SP RACK AND PINION HOIST has been designed and produced in compliance with the current safety regulations. The user has to heed all safety regulations required for the type of equipment used, the work environment and the effective operating conditions, for him/herself and for other working in the vicinity.

  • Page 14: Machine Transportation

    MACHINE TRANSPORTATION The machine is delivered completely assembled (base, initial column, loading deck) and equipped with fittings, fixed to pallets with metal straps; a set of modular elements of the column is packed under the base, on the same pallet. The other modular elements of the column are packaged (approx.

  • Page 15: Loading/Unloading Support

    LOADING - UNLOADING SUPPORT To make easier the loading or unloading of the lift on motor vehicles, some detachable supports can be optionally requested, which allows the operation to be carried out without using any other lifting devices. Two uprights (1), 1 left-hand cross-piece and 1 right-hand cross-piece (2-3) are required.

  • Page 16: Installation

    INSTALLATION The lift must be installed only by skilled workers authorised for operation. The machine must be installed on a floor able to bear the following loads relative to the height of the vertical column Column Machine Working Total height weight capacity load...
  • Page 17 Caution: Regular tightening of the 4 vertical column screws ensure the necessary operating machine stability. Periodically check they are tightened. Only use class 8.8 (12) screws. Check the vertical alignment of the column again in both directions and make the necessary corrections by always turning the worm screws on the base, and finally clamping after the operation.

  • Page 18: Assembling The Vertical Column

    ASSEMBLING THE VERTICAL COLUMN After installing the base of the lift, the modular elements of the column can now be assembled. For this purpose two operators may board the lift and operate as described in this section. !!! WARNING!!! While assembling the machine, never turn the deck, and keep it in the locked position.

  • Page 19: 14A. Emergency Brake Test

    14a. !!! CAUTION - EMERGENCY BRAKE TESTS !!! The test must be conducted about every 3 months and/or whenever machine assembled personnel trained in compliance with the guidelines outlined below: To conduct the test the following conditions must be met: The machine must be firmly secured.
  • Page 20 If you are in the assembly stage, take the following steps: CAUTION: Load at most 3 vertical column modules on the deck. The operators on the deck must always work with their safety belt fastened to the deck to ensure they are suspended if they slip off. Raise the deck up to the top limit of the pre-assembled column, lower the guard (1) and couple the new module, making sure with utmost care that the screws are tightened.
  • Page 21 !!! CAUTION!!! Should the electric power supply fail while assembling or disassembling the vertical column and consequently the deck stops at a height with persons on board, the lift can be lowered by operating the motor brake: TAKE THE RELEASE LEVER (1) SCREWED ON THE MOTOR CASING AND SCREW IT ONTO THE NEARBY HOLE.

  • Page 22: Standard Wall Mounting

    The wall mounting, that must be secured every 6 m., is used to vertically support the whole frame and is this a very important element of the machine. Therefore, very firmly tighten all screws and clamps and frequently check they are tightened properly. Warning!!! Not to interfere with the bolts, fasten the release lever (a) of the turning plate parallel to the deck wall.
  • Page 23 Place the element (1) by first loosing the screw (3). Then place the element (2) and adjust its distance. Fit elements (1) and (2) to a wall with wall-plugs or to a metal frame with clamps able to bear the indicated loads. Check the vertical alignment of the machinery. Loosen the screw (3) until it touches the pipe of the vertical column.

  • Page 24: Trial Before Use

    After conducting the above checks, the machine manager is advised to sign an operation authorisation form, according to the guidelines laid down. MABER MB 500/120 RACK AND PINION HOIST OPERATION The machine must be used only after carefully reading the following paragraphs. Should you have any doubts on lift operation or on any malfunctions that may occur immediately before operation consult the manufacturer’s technical support service.

  • Page 25: Operator's Guide

    CHECKS AND TIPS BEFORE START UP Before using the lift make sure that: All safety measures have been enabled, The operating area is regularly cordoned off, The storey accesses are properly closed with moving or similar barriers, The machine is properly placed on the ground and it can bear the total weight, The vertical column is firmly secured to the wall every 6 m., The machine has not been tampered with, Electric connections have been made properly,...

  • Page 26: Start-Up

    START-UP To start up the machine: Enable the main power knob on the control panel, Grip the control board, Press the start button, Press the up button to raise the deck a few metres, Release the control and check the machine stops regularly (must stop instantly), Press the down button and return to the bottom terminal switch.

  • Page 27: Adjustments And Regulations

    ADJUSTMENTS AND REGULATIONS The MB 500/120 SP RACK AND PINION HOIST does not require any special adjustment after being delivered. However, if need be, take the following steps to adjust the service and emergency brakes: Should the machinery not be moving and tend to slip, the service brake needs adjusting.

  • Page 28: Periodic Maintenance

    MAINTENANCE OF THE MB 500/120 SP RACK AND PINION HOIST The MB 500/120 SP RACK AND PINION HOIST has been designed and produced by selecting the right components to reduce maintenance to ensure its efficient operation. However, the user has to make sure periodic maintenance is regularly carried out to always maximise machine efficiency.The simple operations and the few check required, if performed regularly let you always keep the machine in efficient and safe working order.

  • Page 29: Non-Routine Maintenance

    NON-ROUTINE MAINTENANCE At least once a month, or whenever you doubt their efficiency, check the service and emergency brakes work properly. These operations need to be performed only by trained and authorised personnel since the efficiency and safety of the machine depend fundamentally on these parts. All maintenance jobs must be carried out with the deck on the ground, at the bottom terminal switch, and with the power off (Unplug the power supply cable and switch off the main power knob on the control panel).

  • Page 30: Technical Support Service

    TECHNICAL SUPPORT SERVICE In all cases of non-routine maintenance (excluding the operations described above), when repairing the machine, when replacing damaged parts or defects, contact only the Manufacturer or the official TECHNICAL SUPPORT CENTRE, represented in your country Specially trained technicians are able to carry out all required MAINTENANCE jobs. MAINTENANCE SCHEDULE Hours of Type of maintenance job...

  • Page 31: Lubricants

    LUBRICANTS The machine employs gear trains with maintenance-free oil-sealed ball bearings. Lubrication must be checked and ensured only for following components: Gear motor Only use one of the following lubricants: Temperature -20° / +45° Temperature -20° / +5° Lubricant ISO 3448 VG150-220 ISO 3448 VG100 AGIP BLASIA S 220...

  • Page 32: Electrical Diagram

    ELECTRICAL DIAGRAM MB 500/120 SP RACK AND PINION HOIST, ONE PHASE...

  • Page 33: Failures

    FAILURES The potential failures that may occur on the lift can mainly be attributed to the electric system. In this case is always advisable to contact the manufacturer’s technical support service. Part Control panel Problem The deck is jammed Cause Electric power supply has failed.
  • Page 34 Part Service Brake Problem Slow or inadequate braking cause Linings are worn out Electromagnet is broken remedy Replace linings or the electromagnet. procedure This operation must be carried out by an authorised and pre-trained technician. To this purpose, lower the deck to ground level.

  • Page 35: Spare Parts Legend

    SPARE PARTS The technical support service normally stocks the full range of spare parts for the machine. In the spare parts order the following items must always be quoted: TYPE OF MACHINE SERIAL N° (see section 2 “Machine identification) YEAR OF MANUFACTURE N°...

  • Page 37: Disposing Of The Machine

    DISPOSING OF THE MACHINE When the machine in question must be definitively set up for idling it must be completely disabled and sent to a differentiated scrap recycling service in your area. Take the following steps: - Disconnect the electric system from the main power supply. - Disassemble the whole column - Remove all plastic parts of the machine (pegs, guards, cables, terminal switches etc..) - Remove all electrical parts (junction box, connections, control board, switches etc..)
  • Page 38 ANALYTICAL INDEX Adjustments and regulations Page Assembling the vertical column “ ‘CE’ Declaration of compliance “ Checks and tips before use “ Copy of TÜV Certificate Description of the machine Disposing of the machine “ Electrical diagram “ 14a. Emergency brake (test) “...

  • Page 39: Employment And Intructions Of The Safety Landing Gate

    Code C1200327 1-DESCRIPTION OF THE GATE The gate is mainly composed of: n. 2 battens (upper and intermediate) made of tubular structures; stop band at the base; lateral closing hook of the gate and mechanical blocking system fixed to the gate structure.
  • Page 40 Assemble the unblocking lever on the chassis of the transport drum by fastening it through suitable screws. This position must allow the unblocking lever to be fitted in the unblocking gate box: Load the safety landing gate with blocking gate mechanism on transport drum.
  • Page 41 Open the gate (putting it in vertical position) and assemble the blocking gate box. Use clamps and fix them on the tube of 48mm. Follow the measures specified following pictures correct position of the blocking gate box. Front view of the transport drum View from the drum of the landing floor of the safety landing gate.
  • Page 42 Lower the gate properly in horizontal position. Check if the gate block respect the following features: The central line of the upper slit is lined up to the ‘U’ blocking hook fixed on the gate. The measures specified must be followed. Correct any possible mistakes through proper regulations only at the safety gate.
  • Page 43 3- BUILDING MEASURES 1- Building measures of the blocking gate mechanism 2- Building measures of the unblocking lever The unblocking lever is assembled on the outer side of the chassis of the front closing. The assembly is made by using the blocking plate fixed through suitable screws. Use the lever putting the shaped cam inside the box.
  • Page 44 4- EMPLOYMENT The mechanism which blocks the gates block the rotation of the drum of the rack and pinion hoist when the safety landing gate is open (in vertical position). The operator who uses the hoist must follow these instructions: After having loaded the hoist and closet the loading ramps, makes the hoist go upwards till the landing floor, where a safety landing gate is present, by using the pendant control at the ground level;...
  • Page 45 Position of the rack and pinion hoist during uphill and descent operations When the transport drum is in this position it is not possible opening safety landing gate. When the safety landing gate is closed the drum can be rotated. When the transport drum is not rotated and the unblocking lever is not inside the box the inner mechanism is in the same position of the above picture, thanks to its spring.
  • Page 46 Position of the rack and pinion hoist during loading and unloading operations When transport drum is rotated as in the picture near here the opening of the safety landing gate is possible and the opening of the unloading ramp, too. The opening of the gate automatically blocks the rotation of the transport...
  • Page 47 possible to rotate the drum since the mobile lever can be taken out of the blocking box. 5- SAFETY WARNINGS Against the fall from the landing when the gate is closed The gate has an upper and an intermediate batten and a stop band at the base. Follow the minimum height of the upper batten and the sizes between the battens.

  • Page 48: Technical Drawings

    DISEGNI TECNICI TECHNICAL DRAWINGS DESSINS TECHNIQUES TECHNISCHE ZEICHNUNGEN...
