Page 4: Introduction
But the basic elements are still the same: line of site between the communication nodes, and individual line coding. It is all about performance. GeoDesy FSO offers systems with the highest power budget available on the market. - Page 5 To meet the demands for every higher bandwidth, Limited Europe) continues to invest heavily in research and development with the newest product line which offers Gigabit speeds being launched. GeoDesy FSO Next This manual describes the series of free space laser transmission system. GeoDesy FSO Next...
-
Page 6: Optical Free-Space Transmission
1.3 Optical Free-space Transmission The principle used in free space laser transmission is very similar to the one is used for fibre optic transmission. The difference is while fibre optic devices use electronics and optics optimized for transmission to the air. Also one can observe to the similarity in the transmission properties. -
Page 7: Typical Applications
Urban areas Where only leased lines are available with limited speed, and high rental cost. With GeoDesy FSO links you can establish on line LAN-to-LAN connections. Industrial areas Where you have noisy environment with high EMI or RFI. Factory buildings, airport objects can be connected through laser link. -
Page 8: Interfaces For The Giga Next Af Series
2 Interfaces for the Giga Next AF Series 2.1 1000Mbps TP interface GeoDesy FSO Giga Next AF series products are designed to provide easy-to-use and cost-effective solution for interconnecting Local Area Networks. By utilizing standard Category 5e cable and using standard IEEE802.3af interface the deployment of the system is easier than ever before. -
Page 9: Sites Of Installation
3 Sites of installation 3.1 Key factors of operation There are four key issues that the site survey has to shed light on. Proper system operation cannot be guaranteed without satisfying all of the four requirements. Clear line of sight - The entire optical path between the two ends must be free of any obstacles. - Page 10 It is not only the building that has to be solid, but the support structure too. Antenna GeoDesy FSO poles and security camera holders are not suitable for the units.
-
Page 11: Distance Measurement
3.3 Distance measurement Because the units were designed, and calibrated for certain distance operations the higher distance will decrease the availability. GeoDesy FSO pre-calibrates and pre- tests every unit shipped to the customer. To ensure that the unit you are about to buy fits to the needs, the first step is to measure the distance. -
Page 12: Eye Safety
CLASS 1M LASER PRODUCT Type LB P0500E1000TP LBH-«s/n» Input Power -48VDC IEEE 802.3af compilant Laser Wavelength 785nm Manufactured by: GeoDesy FSO 1162 Budapest, Kondorfa u. 6-8, HUNGARY, Tel.:+36-1-453-7440 Fax.:+36-1-240-3570 www.GeoDesy FSO.com GeoDesy Kft. Telefon: 06-1-481-2050 Fax.: 06-1-481-2049 E-mail: info@geodesy-fso.com http://www.geodesy-fso.com... -
Page 13: The Mounting Bracket
In the following chapter you will find detailed description of the bracket fastenings. 5.1 Mounting brackets for the X Series GeoDesy FSO provides the mounting bracket and all the necessary components series units. A simple fixing technique of this bracket can be seen on the... - Page 14 Packet list for the bracket: 3pcs 8x110 screw for bracket fixing 3pcs 8x100 plastic wall-plug for bracket fixing 2pcs M6x90 bolt Head fixing 3pcs M6x25 screw Head fixing 3pcs M6 bolt head fixing 6pcs 6mm spacer bracket and head fixing 6pcs 6mm spring spacer bracket and head fixing Mounting Hole Patterns GeoDesy Kft.
-
Page 15: System Installation
6 System installation 6.1 On the table test Warning! Do not look either into the transmitter or the receiver optics because at this distance even the reflected laser beam can be dangerous to your eyes. Operating the system on much shorter distance than presumed originally can cause saturation or even permanent damage to the receiver. -
Page 16: Alignment Of The Px0500E1000Tp
6.1.1 Alignment of the PX0500E1000TP The first step after the unit was placed to the bracket, and the units facing each other. On the back of the receiver you can find the LEDs and LCD screen for the local received level and the remote received level. -
Page 17: Fine Tuning
6.1.3 Fine tuning 1. Site start moving laserhead with the horizontal fine adjustment screw looking at the Remote end received level 2. Using the fine adjustment screws, lighten as many LEDs as possible Repeat step 1-2 on Site B. If necessary try step 1-2 on both sites again. -
Page 18: Af Adjusment Method
6.3 AF adjusment method What is AF after all? AF stands for Auto Focus. Geodesy FSO Giga Next AF equipped with the lates innovation from Geodesy. An automatic focusing control system. The system is capable of changing its beam divergency depending on the changes of the environment. - Page 19 AUTO FOCUS mode (enabled). The equipment will automatically improve the remote level to the most ideal position. Note: Geodesy FSO shall not be responsible for any failures from improper handling of the device. If any other screw than the coarse lockers or the fine adjustment is moved, might decrease the stability of the installation.
-
Page 20: Connecting To Your Network
6.4 Connecting to your Network 6.4.1 PoE 802.3 af connection. BOX1.1(FO) 6.4.2 System layout BOX1.0(FO) GeoDesy Kft. Telefon: 06-1-481-2050 Fax.: 06-1-481-2049 E-mail: info@geodesy-fso.com http://www.geodesy-fso.com... -
Page 21: System Layout With Geo20
6.4.3 System layout with GEO20 Beside the GeoDesy laser equipment (buckup) you can only use GeoDesy’s GEO20 Radio equipment. In the case of using a different backup solution, could cause undesired operation. Please referr to support@geodesy-fso.com for more inforamation about the compatibility. BOX 1.0(FO) GeoDesy Kft. -
Page 22: Management
7.1 Features The Inband network-monitoring unit is a newly developed highly featured monitoring for GeoDesy FSO manufactured laser links. This high quality equipment allows the user to monitor the link statuses such as detector voltage transmitter status, and many other features of the Laser link. Nevertheless, this chapter is intended to describe the usage of this network monitoring, and its connection and relationship with the GeoDesy FSO laserheads. -
Page 23: Status Info Screen
Status info screen Clicking on the Device Setup you will enter the main status information screen, which will give you good summarized information of the device, such as status information of the transmitters, detector level, or temperature values. Laser ON: Transmitter transmitts Temperature: ambient temperature inside the device. -
Page 24: Device Setup
Device setup The device setup screen leads you to the main monitoring options. Here the alarms can be set and main information about the Laser head. Device name: uniqe identifier of the device Managed head: Type of the laserhead Temperature alert level: when the temperature reach this value, the alarm will be triggered. -
Page 25: Network Setup
Software version: software of the laser head. NPASW SW version: Network Port Auto SWitchover version. GBIC-compatibility mode:On or OFF. If there are two connectors under the laser head them the GBIC-compatibility mode should be ON (the is GBIC-module in it) but if there are 3 or 4 them the GBIC- compatibility modeshould be OFF (the is NPASW module it). - Page 26 Subnet mask: you can set the subnet mask of the local device. Default gateway: The default getway setting for the local device. Auto MDI/MDI-X: this enables the Auto setting for the MDI/MDI-X, some old switch types might report incompatibility here it can be switched off.
-
Page 27: Snmp Setup
SNMP Setup One of the main features of the device is the SNMP(Simple Network Monitoring Protocol). The SNMP settings can be set on this page. Trap address: The IP address of the SNMP trap over the network. Trap events in the system you have possibility to setup three different trap event. -
Page 28: Security
Security On the security section you can set the username and the password for the unit. If you have forget the usernam and/or the password please contact The technical support. MGM Trusted-host filtering: Here you can adjust two addresses wehre you can till in from which computer with you reach the MGM! To adjust you will hove to adjust a filter. - Page 29 increasing remote load: the AF adjusts the laser beam to increase remote level. decreasing remote load: the AF adjusts the laser beam to decrease remote level. optimizing remote load: the AF adjusts the laser beam to optimal remote level. Manual focus control: After setting the Manual Focus controls you can adjust the manual focus by clicking on the „STEP”...
-
Page 30: Mandatory Management Activation
Mandatory Management Activation Thank you for buying our product. Please read this note carefully. From software version (3.2.1218/R090x)! The product you have bought has fully functional management software, which has limitation only in time. The unit activation request should be sent to activation@geodesy-fso.com. -
Page 31: Firmware Update
Firmware update The firmware update has the following steps: Run FTP client Log-in to the Laser-head Copy Geodesy_FWUpdate_Vxx.sys over Log in the laserhead Click on update Wait 50-60 seconds Restart the laserhead Run FTP client FTP client setup IP address: the IP address of the device (192.168.100.220 or 192.168.100.221 as a factory default ) or the IP address you gave to the system earlier –... - Page 32 copy the file over to the Laserhead Log off the FTP server Now the Update button will be active Click on update and the update process will start it takes upto 60 seconds. The LEDs on the back of the device will go off than lit one after the other. Make sure that the system power is fixed and the power will not go off during the update process.
-
Page 33: Network Interface Software Update
7.2 Network Interface software update 1. Connect the RJ11 and RS232 cable (update cabel) between the laser head and the PC. 2. Enter into the management of the laser head and into the device info. 4.Click on the „Update” button. 5.Click on OK button. - Page 34 10. Click on Load Hex File button and then choose the attached .HEX file (new software) 11.Click on the Program button. 12.Click on Run application button: the laser head will restart with the new software. 13. Click on the Disconnect button and close the program. GeoDesy Kft.
-
Page 35: Update Cabel
7.2.1 Update cabel GeoDesy Kft. Telefon: 06-1-481-2050 Fax.: 06-1-481-2049 E-mail: info@geodesy-fso.com http://www.geodesy-fso.com...
