Summary of Contents for ATLANTECH LUX
- Page 1 ATLANTECH LUX AND LUX ONE BOX INSTALLATION MANUAL WWW.ATLANTECH.IT...
- Page 2 STEP 1 ACTIVITY: - Realization of the hole or the exca- vation, to housing the upper box of the Atlantech Lux foundation, to run in the first case by hydraulic auger and bits, in the second by excavator bucket. The depth of the hole or of the exca-...
- Page 3 STEP 2 ACTIVITY: - Positioning and infixing of the Atlan- tech Lux foundation into the pre- drilling or excavation work carried out in section 1. The screwing is made through the use of an Atlantech in- stallation plate hooked to the auger...
- Page 4 SECTION 3 ACTIVITY: - ONLY FOR LUX MODELS: Installation of the cast iron frame of the manhole cover on the Atlantech Lux box with the possibility of fixing it using nuts and bolts. - Insertion of the corrugated into the...
- Page 5 (5 / 10cm) with mortar or har- dening resins. - Realization of traditional electrical connec- tions. - ONLY FOR LUX MODELS: closure of the box with a special spheroidal cast iron cover. MEANS AND ACCESSORIES: - Suitable means for the installation of the...
- Page 6 TECHNICAL NOTES FOR INSTALLERS - The Atlantech box must, under all circumstances, be buried for at least half of its height (for example in the ATLUX Heavy, Medium and Small Plus models the height of the upper box is 80cm, the buried part must be at least 40cm).
