MIDAS XL250 LIVE PERFORMANCE CONSOLE Contents Xl250 Specifications Overview and Statistics Xl250 Technical Specification Xl250 Controls Xl2501 Mono Input Module Xl2504 Stereo Input Module Group Output Modules Xl2521 Comms Module... - Page 4 Midas XL250 Features. Multi Functional Application. The XL250 is an extremely flexible and truly ìmulti-functionalî console. It can be re-configured in seconds for applications such as in ear monitoring, wedge monitoring, combinations of both, front of house use and many more. All this is achieved with no compromise to the control functions or layout through use of configurable busses and the controls that feed them.
- Page 5 Audio Busses. The XL250 has 4 fixed busses, 2 aux busses for effects sends and a stereo master bus. The aux busses have independent on/off switching and pre/post fader switching. The remaining 16 busses are configured on a bus by bus basis as mono or stereo. The channel mix controls that feed these busses automatically change from level and level to level and pan with the push of a switch on the group modules.
-
Page 6: Xl250 Specifications Overview And Statistics
XL250 Specification Overview and Statistics. 1. The XL250 is a 23 bus console as follows:- 2 mono aux 16 stereo or mono configurable groups =16 1 stereo master 1 stereo AFL 1 mono PFL TOTAL 2. The XL250 has 8 automute group busses. 3. -
Page 7: Xl250 Technical Specification
XL250 Technical Specification. Input Impedance Mic 2K Balanced Line 20K Balanced Input Gain MicContinuously variable from+ 15dB to + 60dB (all faders at 0dB) Mic + PadContinuously variable from - 10dB to + 35dB Line Level Inputs0dB Maximum Input LevelMic+ 6dBu Mic + Pad + 31dBu Line Level Inputs+ 21dBu CMR at 1kHz... - Page 8 Input Metering Type10 led peak reading plus signal present Range- 25dBu to + 15dBu Colour GreenUp to + 6dBu Normal signal Colour Yellow+ 9dBu to + 12dBu High signal Colour RedOver + 15dBu Signal Very High Quantity 40 Output Metering Type20 led peak reading Range- 36dBu to + 21dBu Colour GreenUp to + 9dBu Normal signal...
- Page 9 MIDA S XL2501 MIDA S XL2504 MIDA S XL2511 MIDA S XL2512 MIDA S XL2513 MIDA S XL2514 MIDA S XL2515 MIDA S XL2521 gain gain left solo solo right left right 48V PAD (pfl) (local) treble treble freq stereo stereo stereo stereo...
-
Page 10: Xl2501 Mono Input Module
MIDA S XL2501 gain treble freq gain bass high pass MIDAS XL2501 Mono Input Module direct auto mutes SAFE mute solo MIDA S XL2501... - Page 11 MIDA S XL2501 The PHASE switch activates a 180 degrees phase change within the The GAIN control gives continuous input amplifier. adjustment of the input amplifier gain gain The PAD switch gives 25dB of from +15dB to 60dB attenuation to the input signal which will allow the connection of high The 48V switch connects 48 volt output microphones or line level...
- Page 12 The INS switch connects the input The insert PRE switch arranges the insert return signal to the input input channel signal to pass through channel signal path. the insert point before the equaliser when activated and after the insert The mono aux MIX controls (1 and point when not activated.
- Page 13 The PAN controls the placement of The DIRECT output control gives the channel within the master stereo continuous adjustment of the direct mix and has a constant power law output level from + 10dB to off. The i.e. - 3dB at the centre position. output is derived from the input channel post equaliser pre fader signal.
-
Page 14: Xl2504 Stereo Input Module
MIDA S XL2504 gain left right 48V PAD treble bass high pass MIDAS XL2504 Stereo Input Module stereo auto mutes SAFE mute solo MIDA S XL2504... - Page 15 MIDA S XL2504 The dual concentric GAIN controls The PHASE switches activate a 180 give continuous adjustment of the degree phase change within the input amplifier gains from + 15dB to corresponding input amplifier. + 60dB. The left channel is on top gain and the right channel is on the The PAD switch gives 25dB of...
- Page 16 The INS switches connects the input insert return signal to the input channel signal path. The insert point The mono aux MIX controls (1 and is pre equaliser . 2) give continuous adjustment of the level sent from the input channel to the aux busses.
- Page 17 The BALANCE (pan) control is used to balance the relative levels of the left and right channel signals stereo that are sent to the master stereo mix. The control has a constant power law, i.e. 0dB at the centre The ST switch connects the post position and + 3dB or off at either fader channel signals to the master extreme setting.
-
Page 18: Group Output Modules
MIDA S XL2511 MIDA S XL2512 MIDA S XL2513 MIDA S XL2514 MIDA S XL2515 stereo stereo stereo stereo stereo stereo stereo master stereo stereo stereo stereo stereo direct direct direct direct direct direct direct direct direct direct MIDAS direct direct direct direct... - Page 19 XL2511 MIDAS The METERS monitor the peak signal levels of the mix group outputs (post fader). The global STEREO switches configure input module MIX controls to act as either mono level and level or as stereo level and pan. This makes the console extremely flexible and quick to reconfigure.
- Page 20 The AUTO MUTE switches assign the mix outputs to the 8 auto mute groups. The SAFE switches disconnect the The INS switches connect the mix channel mutes from the auto mute insert return signals to the mix SAFE SAFE busses. groups.
-
Page 22: Xl2521 Comms Module
MIDA S XL2521 solo solo left right (pfl) (local) talk to groups solo in place frequency level external oscillator pink noise level MIDAS XL2521 talk Comms Module headphone MUTE solo add mode monitor auto mute masters local left mute solo solo right clear... - Page 23 XL2521 MIDA S The METERS monitor the peak signal levels of the stereo AFL left and right solo busses or the PFL bus and local output level. The change solo solo over is automatic as part of the left right monitor AFL switch.
- Page 24 The TALK XLR socket accepts balanced 150 Ohm microphone signals from - 50dBu to - 20dBu and uses an auto ranging gain system to bring the level to nominal 0dBu line level. The TALK control gives continuous adjustment of the talk microphone amplifier signal from + 6dB to off.
- Page 25 auto mute masters The AUTO MUTE GROUP MASTER switches (1 to 8) activate the mute circuits on any appropriately mute group assigned input channels or mix groups. The LOCAL MUTE switch mutes The LEFT switch cuts the AFL the local outputs. right signal and places the AFL left local left...
