INSTALLATION AND OPERATION MANUAL
This manual serves the following
Model Names:
TEC-F01
TEC-F04
TEC-F16
TEU-F01
TEU-F04
TEU-F16
TE(C,U)-F Series
ETHERNET OVER COPPER EXTENDER WITH
PASS-THROUGH POE UP TO 15 WATTS
The Ethernet over copper line supports up to sixteen channels of 10/100Mbps
Ethernet with Pass-through PoE over twisted pair cable (CAT-5, UTP), or over
coaxial cable. The single channel units may be powered by a PoE switch or the
included power supply. Four and sixteen channel units operate from local power.
These units provide the ultimate flexibility for extending a powered device (PD)
over long distance copper. DIP switches are provided for user-selection of local or
remote, 10 or 100Mbps, and 1 pair or 4 pair (UTP) settings.
The TE(C,U)-F16 are 1RU rack mountable units. The TE(C,U)-F04 units are
interchangeable between stand-alone or card mount configurations, or may be DIN-
rail mounted by the addition of model SBP-UDR. The TE(C,U)-F01 units are stand-
alone, or may be DIN-rail mounted by the addition of model SBP-UDR adaptor.
TE(C,U)-F SERIES
INS_TE(C,U)-FX 08/12/19 PAGE 1
Advertisement
Table of Contents
Summary of Contents for Wisenet TEC-F Series
- Page 1 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES TE(C,U)-F Series ETHERNET OVER COPPER EXTENDER WITH PASS-THROUGH POE UP TO 15 WATTS The Ethernet over copper line supports up to sixteen channels of 10/100Mbps This manual serves the following Ethernet with Pass-through PoE over twisted pair cable (CAT-5, UTP), or over Model Names: coaxial cable.
- Page 2 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES FIGURE 1 – TEC-F01 SINGLE CHANNEL COAX UNIT ETHERNET EXT DISTANCE Power: Operates on PoE power Black (AC or DC–) OR 9 to 36 VDC Black w/ White OR 24 VAC Stripe (AC or DC+) Power Consumption: 1.5 W FIGURE 2 –...
- Page 3 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES FIGURE 3 – TEC-F04 FOUR CHANNEL SURFACE OR RACK MOUNT COAX UNIT CH1 EXT CH1 ETHERNET DISTANCE CH2 EXT CH2 ETHERNET DISTANCE CH3 EXT CH3 ETHERNET DISTANCE CH4 EXT CH4 ETHERNET DISTANCE Black (DC-) Black w/ White Stripe (DC+) Operating Power: 9 to 15 VDC...
- Page 4 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES FIGURE 5 – TEU-F04 FOUR CHANNEL SURFACE OR RACK MOUNT UTP UNITS CH1 EXT CH1 ETHERNET DISTANCE CH2 EXT CH2 ETHERNET DISTANCE CH3 EXT CH3 ETHERNET DISTANCE CH4 EXT CH4 ETHERNET DISTANCE Black (DC–) Black w/ White Stripe (DC+) Operating Power: 9 to 15 VDC...
- Page 5 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES FIGURE 7 – TEC-F16 MULTICHANNEL RACK COAX UNITS Black (DC–) Black w/ White Stripe (DC+) Operating Power: 9 to 15 VDC Power Consumption: 20W Data rate DIP switch Data rate DIP switch Data rate DIP switch Data rate DIP switch See Installation See Installation...
- Page 6 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES FIGURE 8 – TEU-F16 MULTICHANNEL RACK UTP UNITS Black (DC–) Black w/ White Stripe (DC+) Operating Power: 9 to 15 VDC Power Consumption: 20W Data rate DIP switch Data rate DIP switch Data rate DIP switch Data rate DIP switch See Installation See Installation...
-
Page 7: Application Diagrams
INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES APPLICATION DIAGRAMS Ethernet Connection Note: Coaxial applications use TEC modules; UTP applications use TEU modules. Extended Connection PoE Power PoE Pass-Through Mode Local Remote TE(C,U)-F01 TE(C,U)-F01 PoE Camera Ethernet Switch or Midspan Non-PoE Mode Local Remote Ethernet... -
Page 8: Installation Instructions
INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES INSTALLATION INSTRUCTIONS 1 - SET 10/100 SWITCH Locate the 10/100 data rate DIP switch on the unit. Set the data rate according to bandwidth required. NOTE: The data rate must be set the same on both the local and remote units. 2 - SET WIRE PAIR DIP SWITCHES (UTP MODELS ONLY, FOR COAX MODELS SKIP TO STEP 3) Locate the wire pair DIP switch on the unit. -
Page 9: Application Notes
INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES APPLICATION NOTES Mixed PoE and Non-PoE systems can be implemented. All Non-PoE systems require local power. PoE powered operation requires that a PoE Camera be connected, and that the camera power requirements are understood. Multiple Channel units (TE(C,U)-F04, TE(C,U)-F16) require 9 to 15 VDC for proper operation. - Page 10 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES PRODUCT DIMENSIONS FIGURE A FIGURE B Dimensions are for a small size module Dimensions are for a standard module 0.8cm [0.31in] 0.4cm [0.16in] 4.19cm 0.62cm [1.65in] [0.24in] 13.2cm [5.2in] 11.9cm [4.7in] 6.37cm [2.50in] 8.38cm 7.5cm [3.3in] [2.9in]...
- Page 11 INSTALLATION AND OPERATION MANUAL TE(C,U)-F SERIES INSTALLATION CONSIDERATIONS These units are supplied as Standalone/Rack mounted module. Units should be installed in dry locations protected from extremes of temperature and humidity. SBP-C14 / SBP-C03 CARD CAGE RACKS CAUTION: Although the units are hot-swappable and may be installed without turning power off to the rack, Hanwha recommends that the power supply be turned off and that the rack power supply is disconnected from any power source.
