- Page 1 01.4IB.51809 Electric Remote Racking Device (51897G31) for use with Powell Low Voltage Switchgear Equipped with Siemens Circuit Breakers Powered by Safety ®...
- Page 2 Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers Contact Information Powell Electrical Systems, Inc. www.powellind.com info@powellind.com Service Division PO Box 12818 Houston, Texas 77217-2818 Tel: 713.944.6900 Fax: 713.948.4569 Powered by Safety ®...
- Page 3 01.4IB.51809 Signal Words Qualified Person For the purposes of this manual, a qualified As stated in ANSI Z535.4-2007, the signal word is a word that calls attention to the safety sign and person, as stated in NFPA 70E®, is one who has designates a degree or level of hazard seriousness.
- Page 4 Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers This page is intentionally left blank. Powered by Safety ®...
-
Page 5: Table Of Contents
01.4IB.51809 Contents Ch 1 General Information ....................1 A. S ................................2 cope B. p ................................2 urpoSe c. I ....................2 nStructIon ulletInS vAIlABle lectronIcAlly Ch 2 Safety ........................3 A. S ............................3 ondItIon B. S ...............................3 Afety uIdelIneS c. G ................................3 enerAl d. S ..............................4 Afety ABelS... - Page 6 Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers Figures Figure 1 Electric Remote Racking Device for Powell LV Switchgear Equipped with Siemens Circuit Breakers ............6 Figure 2 Close-up of Control Box .................7 Figure 3 Inserting Locking Pins into Hanger Bracket ..........10 Figure 4 Connecting the Motor to the Control Box ...........10...
-
Page 7: Ch 1 General Information
This document and all other documentation shall be fully read, understood, and all warnings and cautions shall be abided by. If there are any discrepancies or questions, the user shall contact Powell immediately at 1.800.480.7273. -
Page 8: S Cope
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers A. S cope WARNING The information in this instruction bulletin Be sure to follow the appropriate safety describes the following Remote Racking precaution while handling any of the Devices for Powell version Siemens LVAR equipment. -
Page 9: Ch 2 Safety
The rules are intended to cover only some of the applicable up-to-date drawings, diagrams, important aspects of personnel safety related to and identification tags. Powell version Siemens LVAR Racking Device. 2. After properly interrupting the load current, c. G OPEN the disconnecting device(s) for each enerAl source. -
Page 10: S Afety L Abels
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers d. S Afety ABelS NOTICE Warning and Caution labels are located in various places in and on the switchgear and on the circuit breaker. Always observe these warnings and caution labels. -
Page 11: Ch 3 Equipment Description
01.4IB.51809 Ch 3 Equipment Description A. G enerAl The Powell Electric Remote Racking Device is an accessory which enables circuit breakers to be racked into and out of switchgear from a distance. The accessory consists of a motor control box (Figure 1, e) and electric racking device assembly (Figure 1, a, c, & d). -
Page 12: Figure 1 Electric Remote Racking Device For Powell Lv Switchgear
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers Figure 1 Electric Remote Racking Device for Powell LV Switchgear Equipped with Siemens Circuit Breakers a. Locking Pin b. Motor Control Box Cord c. Racking Handle Assembly d. -
Page 13: Figure 2 Close-Up Of Control Box
01.4IB.51809 Figure 2 Close-up of Control Box a. Electrical Cord b. “In” Indicator Light c. “Out” Indicator Light d. Power Switch e. In/Out Selector Switch f. Push Button g. Handle Powered by Safety ® Equipment Description... -
Page 14: Ch 4 Installation & Operation
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers Ch 4 Installation & Operation c. S torAGe Shipping and storage of electrical equipment A. r eceIvInG requires measures to prevent the deterioration of the apparatus over a long unused period. -
Page 15: O Peration
01.4IB.51809 d. o 2. Equipment designed for outdoor exposure perAtIon may be stored either in indoor or outdoor storage locations. The equipment must WARNING be protected from airborne external contaminates if stored outdoors. Outdoor Do NOT work on an energized circuit breaker. storage will also require additional care Follow circuit breaker safety guidelines and to maintain temporary covers over... -
Page 16: Figure 3 Inserting Locking Pins Into Hanger Bracket
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers Figure 3 Inserting Locking Pins into Hanger Figure 5 Sliding the Racking Handle Assembly Bracket into Place Figure 6 Activate Remote Racking Device a. Breaker Position Indicator... -
Page 17: I Nserting The Ircuit Reaker Into
01.4IB.51809 Figure 7 Racking Device Installed with e. I nSertInG tHe IrcuIt reAker Into WItcHGeAr Racking Handle Engaged oMpArtMent CAUTION Before installing any circuit breaker into a compartment, the user MUST verify that the circuit breaker rating meets or exceeds the metal-clad switchgear rating. -
Page 18: Inserting The Circuit Breaker Into The Compartment
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers 2) Inserting the Circuit Breaker Into the Physically move the motor control box Compartment to a remote area and connect the power cord (Figure 1, f ) to a 120VAC power Refer to the specific circuit breaker source. -
Page 19: R Emoving The C Ircuit B Reaker From The
01.4IB.51809 f. r f. Lift the racking device by the handle eMovInG tHe IrcuIt reAker froM tHe WItcHGeAr (Figure 3, a). Position the device in oMpArtMent place and insert the pin in the other half of the hinge mounted on the door CAUTION (Figure 3, a & b). - Page 20 Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers o. When the push button is depressed, the “OUT” indicator light (Figure 2, c) will be energized and illuminated. p. When the breaker is fully racked “OUT”...
-
Page 21: Ch 5 Maintenance
01.4IB.51809 Ch 5 Maintenance A. G enerAl A regular maintenance schedule should be established to obtain the best service and reliability from the electric racking device. Actual inspection and maintenance will depend on individual application conditions such as number of racking operations, time between uses, and storage conditions. -
Page 22: Ch 6 Recommended Renewal Parts
Electric Remote Racking Device for 01.4IB.51809 Powell LV Switchgear w/ Siemens Circuit Breakers Ch 6 Recommended Renewal Parts A. o rderInG nStructIonS 1. Order Renewal Parts from Powell at www.powellind.com or call 1.800.480.7273. 2. Always specify the complete nameplate information including: • Device Type... - Page 23 01.4IB.51809 Electric Remote Racking Device (51897G31) for use with Powell Low Voltage Switchgear Equipped with Siemens Circuit Breakers November 2011 Powered by Safety ® Powell Electrical Systems, Inc. Tel: 713.944.6900 • Fax: 713.948.4569 Service Division - Houston www.powellind.com PO Box 12818 • Houston, TX • 77217 info@powellind.com ©2006 Powell Industries, Inc. • All rights reserved.
