- Page 1 DURAFIT GLIDER DFIMBR01 DURAFIT GLIDER OWNER’S MANUAL IMPORTANT! Please read all instructions carefully before using this product. Retain this manual for future reference. The specifications of this product may vary slightly from the illustrations and are subject to change without notice.
- Page 2 Before You Start Thank you for purchasing this Bike! For your safety and benefit, read this manual carefully before using the machine. Prior to assembly, remove components from the box and verify that all the listed parts were supplied. Assembly instructions are described in the following steps and illustrations. IMPORTANT SAFETY NOTICE PRECAUTIONS BE SURE TO READ THE ENTIRE MANUAL BEFORE YOU ASSEMBLE OR OPERATE YOUR...
- Page 3 EXPLODED DIAGRAM - 2 -...
- Page 4 PARTS LIST DESCRIPTION Q’TY DESCRIPTION Q’TY Main frame Extension sensor wire Seat frame Foam grip Handlebar Square end cap Guide rail Square end cap Handlebar post Bushing Front stabilizer Bracket Rear stabilizer Saddle Handle Backrest Carriage bolt M8×L76 Plug Carriage bolt M8×L45 Round end cap Acorn nut M8 40L/R Crank...
- Page 5 STEP 2: Lock the Pedal (27L/R) to the Crank (40L/R) with wrench. Please note: lock the left pedal (27L) in counter-clockwise and lock the right pedal (27R) in clockwise as shown. And make sure the pedal (27L/R) are locked tightly during your movement, otherwise the pedal teeth will be broken.
- Page 6 STEP 4: A: Attach the Handlebar (56) to the Handlebar post (5) with the Hex bolt (49), Spring washer (13) and Washer (46). Then put the Handlebar cover(54) on it. B: Connect the Extension pulse wire 2(45) and Extension sensor wire (30) with the wire of Computer (44), then fix Computer (44) to Handlebar post (5) with Cross pan head screw (55).
- Page 7 B: Lock the Saddle (36) on the Seat frame (2) with Allen screws (14) and Washer (15) . If you still can’t solve the problems after taking the solutions above, please contact our Customer Care @ contactus@durafit.in or 6383151885/7806811343 to resolve the issue through our Pan- India Service Network.
- Page 8 WARM-UP and COOL-DOWN A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. WARM-UP The purpose of warming up is to prepare your body for exercise and to minimize injuries.
