Summary of Contents for Partizan PAS-EMHK12

  • Page 1 Keypad PAS-EMHK12 Service manual WWW.PARTIZAN.GLOBAL 2019...

  • Page 2: Table Of Contents

    3.11 Users Operation & Reset to Factory Default 4. CONTROLLER MODE – page 8 4.1 Set Wiegand Input Formats 4.2 Programming 4.3 PAS-EMHK12 Connected with Keypad Reader 4.4 Add PIN Users 4.5 Delete PIN Users 5. WIEGAND READER MODE – page 10...

  • Page 3: Product Features & Specifications

    The PAS- EMHK12 is a universal keypad, can work as standalone keypad, access controller or standard Wiegand output reader. The PAS-EMHK12 supports 600 users, it supports multi access modes in either card access, PIN access, Card+PIN access, or multi cards/PINs access, it can read 125KHz EM & HID for Low Frequency and 13,56MHz MIFARE for High Frequency tokens, cards and tags.

  • Page 4: Basic Configure

    BASIC CONFIGURE Programming Step Keystroke Combination Enter Program Mode * (Master Code) # (Factory default is 123456) Exit Program Mode 2.1 Set Master Code Programming Step Keystroke Combination 1. Enter Program Mode * (Master Code) # 2. Update Master Code 0 (New Master Code) # (Repeat New Master Code) # (Master code is any 6 digits)

  • Page 5: Standalone Mode

    3. STANDALONE MODE PAS-EMHK12 can be worked as Standalone Reader for single door. (Factory default mode) --- 8 0 # Connection Diagram Attention Install a 1N4004 or equivalent diode is needed when use a common power supply, or the keypad might be damaged.

  • Page 6: Add Card User

    3.1 Add Card User Programming Step Keystroke Combination 1. Enter Program Mode * (Master Code) # Add Card User 2. Add Card: Using Auto ID 1 (Read Card) # (Allows PAS- EMHK12 to assign The cards can be added Card to next available User ID continuously.

  • Page 7: Delete Users

    3. Exit 3.6 Set Access Mode For Multi cards/PINs access mode, the interval time of reading cards/inputting PINs cannot exceed 5 seconds, or else, the PAS-EMHK12 will exit to standby automatically. Programming Step Keystroke Combination 1. Enter Program Mode * (Master Code) # 2.

  • Page 8: Set Strike-Out Alarm

    Programming Step Keystroke Combination 1. Enter Program Mode * (Master Code) # 2. To disable door open detection 5 0 # (factory default) 5 1 # 2. To enable door open detection 3. Exit 3.8 Set Strike-out Alarm The strike-out alarm will engage after 10 failed card/PIN attempts (Factory default is OFF). It can be set to deny access for 10 minutes after engaging or disengage only after entering a valid card/PIN or Master code.

  • Page 9: Controller Mode

    4. CONTROLLER MODE PAS-EMHK12 can work as Controller, connected with the external Wiegand reader. (Factory default mode) --- 8 1# Connection Diagram Attention: Install a 1N4004 or equivalent diode is needed when use a common power supply, or the reader might be damaged (1N4004 is included in the packing).

  • Page 10: Pas-Emhk12 Connected With Keypad Reader

    Remarks: 4 means 4 bits, 8 means 8 bits, 10 means 10 digits virtual number. 4.4 Add PIN Users To add PIN users, after enter into programming mode on PAS-EMHK12, PIN(s) can be input/added on either PAS-EMHK12 controller or the external Keypad Reader.

  • Page 11: Wiegand Reader Mode

    5. WIEGAND READER MODE PAS-EMHK12 can work as Standard Wiegand Reader, connected to the third-party Controller --- 8 1 # Connection Diagram Note: When set into Wiegand Reader mode, nearly all settings in Controller Model will become invalid. And Brown & Yellow wires will be redefined as below: •...
