Diver's Manifold Block
Product Part #s 300-145, 300-150, 300-155
User Guide
Document Part #: 100-134
Kirby Morgan Dive Systems, Inc.
1430 Jason Way
Santa Maria, CA 93455, USA
Telephone (805) 928-7772, FAX (805) 928-0342
E-Mail: KMDSI@KirbyMorgan.com, Web Site: www.KirbyMorgan.com
Guide prepared by: KMDSI
© ⅯⅯⅩⅢ Kirby Morgan Dive Systems, Inc. Document # 130329001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kirby Morgan 300-145 and is the answer not in the manual?

Questions and answers

Related Manuals for Dive System Kirby Morgan 300-145

Summary of Contents for Dive System Kirby Morgan 300-145

  • Page 1 Diver’s Manifold Block Product Part #s 300-145, 300-150, 300-155 User Guide Document Part #: 100-134 Kirby Morgan Dive Systems, Inc. 1430 Jason Way Santa Maria, CA 93455, USA Telephone (805) 928-7772, FAX (805) 928-0342 E-Mail: KMDSI@KirbyMorgan.com, Web Site: www.KirbyMorgan.com Guide prepared by: KMDSI ©...
  • Page 2 Kirby Morgan Manifold Block If you use an EXO-26 or other full face mask for surface-supplied div- ing, a manifold block which has a one way valve (also referred to as a “non-return” valve) and provides for correct attachment of the umbili- cal is essential.
  • Page 3 Kirby Morgan Manifold Block The one way valve is a very important component. It prevents the flow of air out of the mask in the event of a sudden lowering of pressure in the umbilical supply hose due to an accidental break in the hose or fitting. Not only would the emergency air be lost if the one way valve failed (con- current with a hose or fitting break) but the diver could be “squeezed,”...

  • Page 4: Testing The Manifold Block

    Kirby Morgan Manifold Block Testing the Manifold Block Prior to assembling a bailout system, the one way valve and emergency valve should be tested for proper function. Equipment Needed: -Manifold Block -Bailout bottle -1st Stage regulator w/octopus and scuba reg hose attached -DCS system with an umbilical supply hose -Bucket of water...
  • Page 5 Kirby Morgan Manifold Block Disconnect the hose from the emergency valve. 5) Quickly open the emergency valve by turning the knob. You should hear the trapped air escaping through the emergency valve. Testing The Emergency Valve 1) With all the accessory holes plugged on the manifold block, attach the umbilical hose to the one way valve.
  • Page 6 Kirby Morgan Manifold Block The diver’s umbilical must always be connected by a snap hook to the harness. Note the submersible pressure gauge used to monitor the bail-out supply. WARNING Never dive without attaching the umbilical to some type of harness or clip on the diver’s body.
  • Page 7 Kirby Morgan Manifold Block The mounting plate secures the manifold block to the diver’s harness. Mounting plate Bail-Out Bottle (Emergency Gas Supply) The diver should always dive with a bailout bottle when diving surface- supplied, no matter how experienced or what the water depth. Should the diver become unexpectedly entangled underwater, or if the top side air supply fails, the bailout bottle must provide the few extra minutes of air the diver needs to deal with the emergency and return to the surface.
  • Page 8 Kirby Morgan Manifold Block Over-Pressure Relief Valve The first stage regulator must have at least two low pressure ports. One port is used for the connector hose to the emergency valve and the second is used to install an over-pressure relief valve (Part #200-017). If the first stage develops a leak, the full pressure of the tank could be placed on the low pressure hose.

  • Page 9: Post Dive Procedures

    Kirby Morgan Manifold Block Manifold Block Maintenance Daily- A daily pre-dive inspection should be done prior to using the Manifold Block. Carefully inspect the assembly for any sign of damage or worn components. Tools: open end wrenches, 1”, 11/16”, 9/16”, 5/8” and a 5/16 Allen wrench. 1) Check to ensure all the port plugs are installed and are tight.
  • Page 10 Kirby Morgan Manifold Block Annual Overhaul of the Manifold Block Assembly. The KMDSI manifold block should be rebuilt on an annual basis, or when damage or corrosion is suspected or found. Tools required: Table vise, 1” open end wrench (2ea), l l/16”, 5/8”, and 9/16”...
  • Page 11 Kirby Morgan Manifold Block © Copyright Kirby Morgan Dive Systems, Inc. All rights reserved. Document # 130329001 ⅯⅯⅩⅢ...
  • Page 12 Kirby Morgan Manifold Block 6) Carefully clean the manifold block body with a nylon toothbrush and vinegar solution. Remove all traces of old lubricants, dirt and corrosion. Rinse with fresh water and blow dry with compressed air or allow to air dry.
  • Page 13 Kirby Morgan Manifold Block 2) Inspect the body interior for foreign matter of any type and clean, if necessary. Clean in accordance with the KMDSI cleaning instructions. If corrosion is present, clean using the acidic solution as outlined in the KMDSI cleaning procedures.

  • Page 14: Cleaning And Lubricating

    Kirby Morgan Manifold Block 6) Test the operation of the valve. Disassembly of the Emergency Gas Supply Valve Tools Required: 11/16 inch Open End Wrench 1 inch Open-end Wrench Torque Wrench Attachments & Torque Wrench 3/8 inch Slotted Flat Blade Screwdriver Soft Jaw Vice Lubricant Teflon Tape...
  • Page 15 Kirby Morgan Manifold Block replacement as long as the valve operates smoothly and does not leak. To replace the packing place the packing nut in a vise and carefully work the packing out with a small screw driver, taking care not to damage the threads of the packing nut.
  • Page 16 Kirby Morgan Manifold Block WARNING Do not use any sealant on pipe threads on Kirby Morgan products other than Teflon tape or other approved sealants. Other sealants may not be oxygen com- patible and may lead to fire or explosions which may cause severe personal injury or death.
  • Page 17 Kirby Morgan Manifold Block 11) Test the valve by attaching it to an emergency air supply source. There must be no leakage of gas past the stem or through the packing nut. Turn on the bailout bottle and leave the supply on for several hours. There must be no drop in pressure in the system if the valve is operating properly.
  • Page 18 Kirby Morgan Manifold Block and fresh water. Cleaning for 15 minutes in an ultrasonic sink, if avail- able, with the 50/50 vinegar solution is highly recommended. Repair parts are available. Normal replacement parts include the O-ring, soft seat, spring, and hex nut. The O-ring should be replaced at least an- nually.
  • Page 19 Kirby Morgan Manifold Block nut, if either part is excessively corroded or shows signs of wear and/or damage. Inspect the soft seat for nicks, cuts, and wear and replace if any damage is found. Replace the entire assembly if any damage to the valve body is present.
  • Page 20 Kirby Morgan Manifold Block DANGER Do not use oxygen, or mixed gas contain- ing more than 23% oxygen by volume, for lift checking the relief/bleed valve. The use of oxygen, or mixed gas, in a high- pressure supply system not designed and cleaned for oxygen service, can result in a fire or explosion causing serious injury or death.

  • Page 21: Troubleshooting

    Kirby Morgan Manifold Block (1) in (clockwise) 1/8th turn. Slowly bring up pressure and recheck. Continue this procedure as necessary until the relief valve consistently vents at a pressure between 180- 200 p.s.i.g. (12.40-13.78 bar). If the valve does not start venting when the gauge reads 200 p.s.i.g. (13.78 bar), slowly back out on the adjustment screw (counter clockwise) until the valve starts venting, forming bubbles in the soap solution.
  • Page 22 Kirby Morgan Manifold Block Reassembly of the Manifold Block Assembly. 1) Apply Teflon tape to the pipe threads on the Emergency Gas Supply valve starting two threads back from the open end of the pipe thread. Only one and one half wraps of tape is all that is necessary. 2) Reinstall the emergency valve into the manifold block and tighten.

  • Page 23: Warranty

    Kirby Morgan Manifold Block WARRANTY KMDSI warrants every new mask, helmet, SCUBA regulator, Manifold Block or Diving Control System (DCS) (each, a Product) to be free from defects in workmanship for a period of three hundred sixty five (365) days from the date of purchase from a KMDSI authorized dealer.
  • Page 24 Kirby Morgan Manifold Block Product or any parts which KMDSI determines during the applicable warranty period are defective in workmanship or material covered by this warranty. All exchanged parts are the property of KMDSI. The buyer’s exclusive remedy and the KMDSI’s entire liability in contract, tort, or otherwise is the payment by KMDSI of the buyer’s actual damages up to but not to exceed the amount paid by the buyer for the Product.
