United Electronic Industries DNx-AO-308-353 User Manual

8-channel, 16-bit, high voltage analog output board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DNx-AO-308-353
—
User Manual
8-Channel, 16-bit, High Voltage
Analog Output Board, up to ±40V, ±5mA,
for the PowerDNA Cube and RACK Series Chassis
April 2020
PN Man-DNA-AO-308-353-0910
© Copyright 1998-2020 United Electronic Industries, Inc. All rights reserved.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DNx-AO-308-353 and is the answer not in the manual?

Questions and answers

Summary of Contents for United Electronic Industries DNx-AO-308-353

  • Page 1 DNx-AO-308-353 — User Manual 8-Channel, 16-bit, High Voltage Analog Output Board, up to ±40V, ±5mA, for the PowerDNA Cube and RACK Series Chassis April 2020 PN Man-DNA-AO-308-353-0910 © Copyright 1998-2020 United Electronic Industries, Inc. All rights reserved.
  • Page 2 COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS. Products sold by United Electronic Industries, Inc. are not authorized for use as critical components in life support devices or systems. A critical component is any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness.

  • Page 4: Table Of Contents

    DNx-AO-308-353 Board........
  • Page 5 . DNx-PC-913 and AO-308-353 Interconnection Diagram..........6 . Physical Layout of AO-308-353 Board................ 7 . Diagram of AO-308-353 Board Position Jumper Settings .......... 7 © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353LOF.fm...
  • Page 6 List of Tables . DNA-AO-308-353 Technical Specifications................3 © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353LOT.fm...

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction Chapter 1 Introduction This document outlines the feature set and use of the DNx-AO-308-353, an 8-channel, high voltage, analog output board. Organization This DNx-AO-308-353 User Manual is organized as follows: 1.1.1 Introduction This chapter provides an overview of DNx-AO-308-353 board features, accessories, and what you need to get started.
  • Page 8 This manual describes the AO-308-353 High Voltage, 16-bit, 8-channel, ±40V Analog Output board only The other products in the series are described in separate documents. © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap1.fm...
  • Page 9 Refer to the Typical Performance Characteristics for cooling fan is required. Refer to the Typical Performance Characteristics for more more details. detail. © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap1.fm...

  • Page 10: Device Architecture

    Logic AOut7 16-bit Boost AOut7 Ground Protection DIO (3) Calibration Calibration DNA-PC-903 EEPROM Reference ±45V Figure 1-2. Block Diagram of AO-308-353 Device Architecture © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap1.fm...

  • Page 11: Board Connectors And Wiring

    DIO2 22 4 DIO1 AGND 21 DIO0 –15V (20mA) OUT 20 +15V (20mA) OUT AGND Figure 1-3 DB-37 I/O Connector Pinout of the AO-308-353 © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap1.fm...

  • Page 12: Interconnecting A Dnx-Ao-308-353 And A Dnx-Pc-913

    Using an AO-308-353 with a DNx-PC-913 as the ±45V external power supply requires interconnections between the two boards as shown in necting a DNx- Figure 1-4 below. AO-308-353 and a DNx-PC- Interconnection Between DNx-PC-913 and DNx-AO-308-353 DB-37 Connector DB-37 Connector DB-37 (female) DNx-PC-913 37-pin connector:...

  • Page 13: Physical Layout Of Ao-308-353 Board

    All I/O Layers are sequentially enumerated from top to the bottom of the Cube - Open - Closed Figure 1-6. Diagram of AO-308-353 Board Position Jumper Settings © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap1.fm...

  • Page 14: Chapter 2 Programming With The High-Level Api

    In simple mode, the delay between samples is determined by software on the host computer. In buffered mode, the delay between samples is determined by the AO- 308-353 on-board clock. © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap2.fm...

  • Page 15: Writing Data

    If you want to reuse the object with a different set of the Session channels or parameters, you can manually clean up the session with the following: session.CleanUp(); © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap2.fm...

  • Page 16: Chapter 3 Programming With The Low-Level Api

    #define DQ_LN_CLCKSRC1 (1L<<3) // CL clock source MSB #define DQ_LN_CLCKSRC0 (1L<<2) // CL clock source 01 - SW,10 - HW,11 –EXT #define DQ_LN_ACTIVE (1L<<1) © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap3.fm...
  • Page 17 AO-308x , either clock triggers all converters. Aggregate rate = Per-channel rate * Number of channels Note that acquisition rate cannot be selected on per-channel basis. © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap3.fm...

  • Page 18: Channel List Settings

    To convert current into A/D representation (AO-308-420 only), use the following formula: Raw = (mA+Offset)/(Span/0xFFFF), where mA is the desired level in mA. © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap3.fm...
  • Page 19 TIMEOUT_DELAY, &RdCfg); // Receive IOM crucial identification data DqCmdEcho(hd0, DQRdCfg); // Set up channel list for (n = 0; n < CHANNELS; n++) { © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap3.fm...
  • Page 20 // buffer into ACB) &avail); // available free // space in buffer STEP 3: Start operation. // Start operations DqeEnable(TRUE, &bcb, 1, FALSE); © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap3.fm...
  • Page 21 // available free space //in buffer STEP 5: Stop operation. DqeEnable(FALSE, &bcb, 1, FALSE); STEP 6: Clean up. DqAcbDestroy(bcb); DqStopDQEngine(pDqe); DqCloseIOM(hd0); #ifndef _WIN32 DqCleanUpDAQLib(); #endif © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 Chap3.fm...
  • Page 22 Cube) should be added to the DNA Cube. B. Board Calibration Please note that if you perform calibration yourself, the factory calibration warranty is void. © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File:AO-308-353 ChapAppx.fm...
  • Page 23 Support Support email Jumper Settings support@ueidaq.com Support FTP Site Manual Conventions Manual Organization //ftp.ueidaq.com ii Support Web Site Photo of DNA-AO-308-353 layer www.ueidaq.com © Copyright 2009 Tel: 508-921-4600 www.ueidaq.com Vers: 1.4 United Electronic Industries, Inc. Date: September 2010 File: AO-308-353IX.fm...
