9. Once pole is in position use the locking
screws to fix the pole in place as shown in Fig. 8.
Fixing the Finials
10. When you have tightened the screws you
can now mount the finials onto the pole.
Remember to position a ring between the
brackets and the finial (Fig. 9). Additional rings are
available as an accessory.
11. The pole is now ready to accept curtains by
slipping curtain hooks through the eyelets on the
rings.
Drilling Template
Use the template provided to mark the centre
of the pole if you need to drill pilot holes for
the finial screws.
Integra Products Ltd
High Point, Sandy Hill Business Park,
Sandy Way, Amington, Tamworth,
Staffordshire B77 4DU
Fig. 8
8
Fig. 9
9
50mm
35mm
28mm
tel:
+44 (0)1543 267100
fax:
+44 (0)1543 267105
email:
cus.care@integra-products.co.uk
web:
www.integra-products.co.uk
Mix & Match Wooden Curtain Pole
Fitting Instructions
Please read these instructions carefully and
check the contents of the pack against the table
below before attempting to assemble and fix
this product. The fixing screws supplied are for
use where a wooden batten is fixed to the wall.
If you intend to fix the brackets directly to the
wall, you must use the most appropriate wall
plugs and fixings.
Contents s
Pole Length w
1.2m
A Brackets
2
B Poles
1
C Rings
12
D Joining Pin
-
E Finials*
* Finials may differ from those illustrated.
Please ensure the correct wall plugs are used to suit your wall type
L5583
Should any component be missing, please call
the Customer Care Department on 01543
267100.
Tools Required: Spirit level, tape measure, flat
bladed
screwdriver,
crosshead
screwdriver, suitable sized drill bits (pilot hole
for wood screws), pencil, step ladder.
1.5m
1.8m
2.4m
3.0m
2
2
3
3
1
1
2
2
16
18
24
30
-
-
1
1
Sold seperately
(philips)
3.6m
3
2
36
1
