  • Page 1 WARRIOR 360...

  • Page 2: General Instructions

    Please, read carefully before using the unit. Thank you! General Instructions Read the instruction in this manual carefully and thoroughly, as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to read about its operation and relative instructions.
  • Page 3 Up to 200 steps in each chase; totally 1200 steps can be stored. 18 groups of chases run simultaneously, each with up to 36 steps, each step with up to 36 chases; fade time and speed of each step adjustable; 3-pin DMX out ×...
  • Page 4 18 fixture selection buttons once selected, the LED indicator on the button will be flashing. Activate Multi (LED indicator on) to open more fixtures. ◆ ◆ ◆ ◆ Sliders and LED Indicators There are 20 sliders, each with an LED indicator, on the front panel. With these sliders and the 18 fixture selection buttons, all 360 channels can be controlled directly by manual.
  • Page 5 ★ ALL: When a chase is running, press this button to adjust the speed and slope of all the steps in the chase. ★ DEL: To delete a scene/chase/chase group, or to delete a step when programming. ★ Latch: Press this button to latch two or more scenes /chases / chase groups, so that they can run simultaneously.

  • Page 6: Rear Panel

    ★ Group: 1 group of chase, with 18 chases ★ 1—18: 18 number buttons for use of scenes, chases and chase groups. ★ Multi: Press this button to select two or more fixtures (LED indicator on); If the LED indicator of this button is off, only one fixture can selected.
  • Page 7 ★ Power on: Please confirm the power supply is correct for the controller before connection. After power on, the controller will start reseting. You may see the LED indicators flashing. ★ Fixture selection: After power on, the fixture selection buttons are inactivated and the sliders are not ready to work..

  • Page 8: Run A Scene

    don’t want to save the value of a certain channel, press and hold Release and then push the slider to release the channel, the LED indicator of the slider will be off. It is recommended to release the unnecessary channels to avoid unexpected lighting effects. If it prompts error when saving a scene, it means there is an existing scene running in the number button, or the new scene is blank not for save.
  • Page 9 Press Program save the chase and exit the programming mode. B: Create the scenes first and then add the scenes into the chase. Step Description Create scenes (See “Create a Scene”). Press Program to enter programming mode Select one of Chase1 and Chase2 to store the chase. Select a number from 1--18 as the number of the chase.

  • Page 10: Run A Chase

    Note: In making the lighting effects, the LED indicators of the irrelevant sliders should be off. If not, you can press and hold Release and then push the slider to release them. Any channel with output value will be stored into the chase. VIII.

  • Page 11: Setup Of Slope Channels

    selection. A flashing LED indicator on the number button indicates an existing chase. Select the desired chases to add into the chase group. Once selected, the chase will start running. Up to 48 steps can be added. Inactivate E/XY (LED indicator off), then adjust running speed by the X/Speed function wheel.

  • Page 12: Troubleshooting

    The channels that have been assigned to the function wheels will automatically with slope when the chase is running. Other channels can also be set up with slope, too. Step Description Press Program to enter programming mode Press SlopeSet. Select the desired fixture. Push the channels that you want to set up with slope till the LED indicators of the sliders are on.
