ANAVI Infrared pHAT
ANAVI Infrared pHAT
Convert Your Raspberry Pi to Powerful Remote Control
Convert Your Raspberry Pi to Powerful Remote Control
DISCLAIMER
DISCLAIMER
Raspberry Pi and the Raspberry Pi logo are registered trademarks of the Raspberry Pi Foundation. ANAVI, the ANAVI logo and combinations thereof, are registered
trademarks of Leon Anavi. Other product names may be trademarks of others and the rights belong to their respective owners.
The information in this document is provided in connection with Anavi products. No license, express or implied or otherwise, to any intellectual property right is
granted by this document or in connection with the sale of Anavi products.
This work is licensed under the Creative Commons Attribution-ShareAlike 3.0 Unported License. To view a copy of this license, visit
http://www.creativecommons.org/licenses/by-sa/3.0/.
ANAVI Infrared pHAT hardware design is licensed under a Creative Commons Attribution-ShareAlike 3.0 Unported License.
The software examples are released under MIT and the rest of the software is available under GPLv3.
It is possible that the pictures in this manual differ from the latest revision of the board.
The product described in this document is subject to continuous development and improvements. All particulars of the product and its use contained in this
document are given by Anavi in good faith. However all warranties implied or expressed including but not limited to implied warranties of merchantability or fitness for
purpose are excluded. This document is intended only to assist the reader in the use of the product. Anavi shall not be liable for any loss or damage arising from the
use of any information in this document or any error or omission in such information or any incorrect use of the product.
This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation purposes only and is not considered by Anavi to be a finished
end-product fit for general consumer use. People handling the product must have electronics training and observe good engineering practice standards. As such, the
goods being provided are not intended to be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including
product safety and environmental measures typically found in end products that incorporate such semiconductor components or circuit boards.
There is no warranty for the design materials and the components used to create ANAVI Infrared pHAT. They are considered suitable only for ANAVI Infrared pHAT.
CHAPTER 1: Overview
CHAPTER 1: Overview
Introduction
Introduction
ANAVI Infrared pHAT is an open source hardware Raspberry Pi add-on board with IR receiver, transmitter, UART and 3 I2C slots for sensors. ANAVI Infrared pHAT was
started as a hobby project by Leon Anavi in January 2017. The project allows you to convert your Raspberry Pi into a smart remote control using the open source
software LIRC.
ANAVI Infrared pHAT is designed with the free and open source electronics design automation suite KiCAD. No soldering is required. You can assemble ANAVI
Infrared pHAT to your Raspberry Pi with your bare hands.
Anavi is fully compatible with the Raspbian GNU/Linux distribution and open source sample applications are provided.
Features
Features
ANAVI Infrared pHAT Raspberry Pi HAT includes:
IR LED
IR photo sensor
Slots for up to 3 plug and play I2C sensors
Supported Raspberry Pi Versions and Models
Supported Raspberry Pi Versions and Models
ANAVI Infrared pHAT is compatible with the following Raspberry Pi versions and models:
Raspberry Pi 4 Model B
Raspberry Pi 3 Model B
Raspberry Pi 2 Model B
Raspberry Pi 0
Raspberry Pi 0 W
Raspberry Pi Model B+
Raspberry Pi Model A+
ANAVI Infrared pHAT is NOT
NOT compatible with the earlier 26-pin models of Raspberry Pi 1 Model B & A's.
Target Market
Target Market
ANAVI Infrared pHAT is a Raspberry Pi HAT suitable for existing Raspberry Pi customers interested in home automation, software development and Internet of Things.
The board is appropriate for embedded programming enthusiasts, GNU/Linux gadget fans, students as well as web and/or mobile app developers. The main usage of
the board is embedded software development and controlling IR devices without the urge of understanding perfectly the hardware.
Advertisement
Table of Contents
Summary of Contents for ANAVI Infrared pHAT
-
Page 1: Chapter 1: Overview
Anavi in good faith. However all warranties implied or expressed including but not limited to implied warranties of merchantability or fitness for purpose are excluded. This document is intended only to assist the reader in the use of the product. Anavi shall not be liable for any loss or damage arising from the use of any information in this document or any error or omission in such information or any incorrect use of the product. -
Page 2: Board Version
Board Version Board Version Revision 1.0 of ANAVI Infrared pHAT was used while writing this document. It is possible that it is outdated so it is always recommended to check the latest sources from the GitHub page of the board. -
Page 3: Chapter 3: Software
Installation Installation In order to work correctly, ANAVI Infrared pHAT requires an up-to-date kernel, I2C to be enabled, and a few libraries to get started. After booting microSD card with Raspbian, open a terminal and follow the steps below: Raspbian... - Page 4 GND line of UART UART on ANAVI Infrared pHAT. Type in the following command on your computer if you are using GNU/Linux distribution to access ANAVI Infrared pHAT. Alternatively if your OS is Microsoft Windows use putty. The recommended USB to UART serial modules for ANAVI Infrared pHAT are any with CP2102 or Olimex USB-Serial-Cable-F .
- Page 5 Setting up LIRC Setting up LIRC Perform the steps below to build LIRC from source, to patch it and to enable the infrared receiver and transmitter on ANAVI Infrared pHAT: Install dependencies sudo su -c "grep '^deb ' /etc/apt/sources.list | sed 's/^deb/deb-src/g' > /etc/apt/sources.list.d/deb-src.list"...
- Page 6 Start outputting raw data from the IR receiver mode2 -d /dev/lirc1 Point a remote control at the IR receiver on ANAVI Infrared pHAT and press its buttons. If the IR receiver is configured successfully you will see similar output: space 3662230...
- Page 7 Using driver default on device /dev/lirc1 irrecord - application for recording IR-codes for usage with lirc Copyright (C) 1998,1999 Christoph Bartelmus(lirc@bartelmus.de) This program will record the signals from your remote control and create a config file for lircd. A proper config file for lircd is maybe the most vital part of this package, so you should invest some time to create a working config file.
- Page 8 Device Tree (DT) in Linux is a description of the hardware in a system. The DT overlay adds a number of optional elements. The EEPROM of ANAVI Infrared pHAT contains DT overlay with description of the peripheral devices on the HAT. After adding Anavi to your Raspberry Pi and booting...
- Page 9 Circut). I2C uses two wires, labelled SDA (Serial Data) and SCL (Serial Clock). To function properly, I2C requires a pullup resistor on each of those lines therefore ANAVI Infrared pHAT includes two 4.7kohm resistors labelled as R6 and R7. If for one reason or another you need to disable the I2C pullup resistors remove R6 and...
-
Page 10: Chapter 7: Revision History
Is ANAVI Infrared pHAT software free and open source? Yes, the official ANAVI Infrared pHAT software is free and open source. The examples are available under MIT license and the rest is available under GPLv3. Please contact us if you are working on a commercial product and you would like to use the software under alternative commercial license.
