LED Lighting and USB
The OPITEC handicraft packs are not toys in a typical off-the-shelf sense, but rather additio-
nal teaching and learning material for educational purposes. This craft pack may only be
constructed by children and adolescents under the guidance and supervision of experien-
ced adults. Not suitable for children under 36 months. Choking hazard!
Stocklist
Plywood
Plywood
Wooden Strip
Acrilyc Glass Rod
USB-charging Cable
LED Light
Wooden Ball with blind hole
Eyebolt
Nail
Lustre Terminal
Resistor 100 Ohm
Grey Cardboard (not included in the kit!)
116.253
Miracle Tree with
Please note:
Quantity
1
1
2
1
1
1
1
1
2
3
1
Tools Required:
Fretsaw or
Hammer
Scroll Saw
Slot Screwdri-
Sandpaper
ver
Square
Size (mm)
220x220x4
Tree Construction
80x80x8
200x30x5
245x6
USB Connection
ø 15
Wooden Ball
12
Cable Mounting
15x1
Connection LED
Wood Glue
All Purpose
Glue
Aadhesive
Pricking Awl
Tape
Ruler
Round File
Description
Base Plate
Frame Strip
Glowstick
Lighting
Wiring
Resistor
Part No.
1
2
3
4
5
6
7
8
9
10
11
Advertisement
Summary of Contents for Opitec 116.253
- Page 1 Tape Please note: The OPITEC handicraft packs are not toys in a typical off-the-shelf sense, but rather additio- nal teaching and learning material for educational purposes. This craft pack may only be constructed by children and adolescents under the guidance and supervision of experien-...
- Page 2 Instructions 116.253 Miracle Tree with LED Lighting and USB Cut off 2 strips with a length of 85mm from each of the two wooden strips (3) as shown. Clean the saw edges. Mark a recess on one of the 85mm strips (3a) as shown and saw out Cut out the template (page 7 + 9) and stick it to the plywood plate with the fretsaw.
- Page 3 Instructions 116.253 Miracle Tree with LED Lighting and USB Mark the middle of the base plate (2) by diagonals. Glue the self-adhe- Pin a nail (9) through the positive pole of the LED (6). Place a second sive LED light (6) centrally to the base plate (2).
- Page 4 Instructions 116.253 Miracle Tree with LED Lighting and USB Alternatively, the miracle tree can also be operated by a 9 V battery. This requires the resistance as well as the third luster terminal. You 100 Ohm also need a battery clip, that ist not included in this package. For...
- Page 5 Instructions 116.253 Miracle Tree with LED Lighting and USB Glue the wooden ball (7) to the acrylic rod by using all purpose glue. Without a break apply glue to the adhesive surfaces of the two remai- Let the glue dry well. (at least 60 minutes!)
- Page 7 Instructions 116.253 Miracle Tree with LED Lighting and USB Template Tree Halves S 1:1 Please note: If you want to produce the curves with a drill, you should drill before sawing out the parts! cutting edge...
- Page 9 Instructions 116.253 Miracle Tree with LED Lighting and USB Template Tree Halves S 1:1...
