Carrier UPC Open Installation And Integration Manual

Carrier UPC Open Installation And Integration Manual

Hide thumbs Also See for UPC Open:
Table of Contents

Advertisement

Quick Links

U
P
C
O
p
e
n
U
P
C
O
p
e
n
I
n
s
t
a
l
l
a
t
i
o
n
a
n
d
I
n
t
e
g
r
a
t
i
o
n
G
u
i
d
e
I
n
s
t
a
l
l
a
t
i
o
n
a
n
d
I
n
t
e
g
r
a
t
i
o
n
G
u
i
d
e
CARRIER CORPORATION ©2011
A member of the United Technologies Corporation family · Stock symbol UTX · Catalog No. 11-808-468-01 · 1/12/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPC Open and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carrier UPC Open

Summary of Contents for Carrier UPC Open

  • Page 1 CARRIER CORPORATION ©2011 A member of the United Technologies Corporation family · Stock symbol UTX · Catalog No. 11-808-468-01 · 1/12/2012...

  • Page 3: Table Of Contents

    Wiring specifications for CCN ....................... 9 To wire the CCN equipment to the UPC Open..................9 Select or create a custom control program and graphic for the UPC Open ............10 Local access to the UPC Open ..........................11 Start-up ..................................12 Configuring the UPC Open's properties ......................

  • Page 5: Introduction

    BACnet network, where it can be monitored or controlled by a Building Automation System (BAS). NOTE A future release of the UPC Open will support installation on a Modbus, N2, or LonWorks network. UPC Open...

  • Page 6: Specifications

    LON-OC port 14-pin communication port supports the LonWorks Option Card (future) CCN port (Port 2) 5-pin port supports EIA-485 3-wire connection to a single Carrier CCN controller Rnet port For SPT sensors and a BACview in any of the following combinations, wired in a daisy-chain configuration: •...
  • Page 7 .44 lbs (.2 kg) BACnet support Conforms to the Advanced Application Controller (B-AAC) Standard Device Profile as defined in ANSI/ASHRAE Standard 135-2004 (BACnet) Annex L Listed by UL-916, (Canadian Std C22.2 No. 205-M1983), CE, FCC Part 15- Subpart B-Class A UPC Open...

  • Page 8: Installation

    • Ensure that you are properly grounded. Screw the UPC Open into an enclosed panel using the mounting slots on the coverplate. Leave about 2 in. (5 cm) on each side of the controller for wiring. Mounting hole dimensions 4.8 in. (12.2 cm) between mounting slot center lines.

  • Page 9: Wiring The Upc Open For Power

    The UPC Open is powered by a Class 2 power source. Take appropriate isolation measures when mounting it in a control panel where non-Class 2 circuits are present. The UPC Open is a half wave device. Half wave and full wave devices cannot share power. Examples of a full wave device are a CVC or ICVC in an applied chiller.

  • Page 10: Configuring The Bas Port For Bacnet Ms/Tp

    MAC address to the end of the Network Number. The Network Number of a new UPC Open is 16101A. Thus, a controller with a MAC address of 20 results in a Device Instance of 16101 + 20, which is a Device Instance of 1610120.

  • Page 11: Wiring The Upc Open To The Ms/Tp Network

    The following example shows the BAS Port DIP Switches set for 76.8k (Carrier default), and MS/TP. Wiring the UPC Open to the MS/TP network The UPC Open communicates using BACnet on an MS/TP network segment communications at 9600 bps, 19.2 kbps, 38.4 kbps, or 76.8 kbps.

  • Page 12: To Wire The Upc Open To The Bas Network

    Connect the communications wiring to the BAS port’s screw terminals labeled Net +, Net -, and Shield. NOTE Use the same polarity throughout the network segment. Insert the power screw terminal connector into the UPC Open's power terminals if they are not currently connected.

  • Page 13: Wiring Specifications For Ccn

    Verify the LED lights TX2 and RX2 are flashing to indicate the UPC Open is communicating on the CCN Port. NOTE If the CCN target address differs from what the UPC Open is configured for (default 0, 1), then only the transmit LED flashes about 1 time per second.

  • Page 14: Select Or Create A Custom Control Program And Graphic For The Upc Open

    Select or create a custom control program and graphic for the UPC Open The field-installed UPC Open does not come from the factory with a control program or graphic. You must load a control program and graphic as part of the installation/commissioning of the UPC Open. You can select a control program and graphic from ApplicationBuilder that has all the configurations that are currently available on a factory-installed UPC Open.

  • Page 15: Local Access To The Upc Open

    NOTE At the present time, Field Assistant is the required local access user interface for UPC Open start-up, commissioning, operation, and troubleshooting. The 3 versions of BACview only provide rudimentary driver information.

  • Page 16: Start-Up

    NOTES If the UPC Open is used in a Multiple Chiller Application, then you must change the address of the chillers and the CCN address of all the UPC Open controllers to ensure they are all unique. In this application, the maximum number of UPC Open controllers allowed on the CCN bus is 3.
  • Page 17 In chiller applications, verify the chiller is configured in CCN mode. If the chiller is not in CCN mode, then the UPC Open is not able to force points or write to the chiller. Refer to the specific chiller's documentation for information on how to setup the chiller to be in CCN mode.

  • Page 18: Troubleshooting

    Troubleshooting Troubleshooting If you have problems mounting, wiring, or addressing the UPC Open, contact Carrier Technical Support. The UPC Open LED's The LED’s indicate if the controller is speaking to the devices on the network. The LED’s should reflect communication traffic based on the baud rate set. The higher the baud rate the more solid the LED’s become.

  • Page 19: Serial Number

    The UPC Open's 10-year Lithium CR2032 battery provides a minimum of 10,000 hours of data retention during power outages. CAUTION Power must be ON to the UPC Open when replacing the battery, or your date, time, and trend data will be lost.

  • Page 20: Appendix A: Single Point Linkage And Device Address Binding

    Single Point Linkage The UPC Open receives data from other Open controllers when they are installed as part of an Open system. The data transfer may take the form of Single Point Linkage (SPL), which is automatic, or Device Address Binding, which you must configure.

  • Page 21: Device Address Binding

    Device Address Binding As described previously, Device Address Binding allows the UPC Open to receive data from other Open controllers when they are connected by a network. You must configure this method. Currently, the UPC Open allows Device Address Binding (DAB) only for System Space Temperature.

  • Page 22: Compliance

    ASHRAE. ASHRAE does not endorse, approve or test products for compliance with ASHRAE standards. Compliance of listed products to requirements of ASHRAE Standard 135 is the responsibility of the BACnet manufacturers Association (BMA). BTL ® is a registered trademark of the BMA. UPC Open...
  • Page 24 CARRIER CORPORATION ©2011 A member of the United Technologies Corporation family · Stock symbol UTX · Catalog No. 11-808-468-01 · 1/12/2012...
