Summary of Contents for Kamasa-TOOLS K 9836
- Page 1 Cut-off tool K 9836 400 mm...
- Page 2 This tool is designed for cutting metal, plastic and similar materials in confined spaces. A 75 or 100 mm cutting disc shall be used. SAFETY AND PRECAUTION Read these safety instructions before starting to use the tool and follow the instructions Always use impact resistant eye protection when operating a pneumatic tool.
- Page 3 12 Ensure that the maximum operating speed of the abrasive is equal to or greater that the rated speed of the spindle. 13 Check the protective guard on a regular basis. The protective guard must be securely attached to the device and in good condition. 14 Never put the device down before the tool has come to a complete stop.
- Page 4 PRODUCT SPECIFICATIONS Model No. K 9836 Revolutions 14000 rpm Cutting disc 75 or 100 mm Air connection ¼” NPT Sound level 85,5 dBA Vibration level 3,8 m/s2 Air consumption 113 l/m Max operating pressure 6,3 bar Length 400 mm Weight...
- Page 5 OPERATION INSTRUCTIONS Screw the hose connection on to the compressed air connection. Fit the cutting disc, make sure it lays flat. Position the support flange. It is fitted correctly when it cannot be turned on the spindle. Attach the screw and tighten. Keep the spindle locking knob pressed in to prevent the spindle from rotating.
- Page 6 PARTS K 9836...
- Page 7 PARTS LIST K 9836 Parts name Qt Spare part No Parts name Qt Spare part No Motor housing Button seat Spring pin Air inlet KR 9836-3 Screw Trottle lever Roller shaft Valve shaft Spring O-ring KR 9836-1 Washer Connecter Washer Spring pin...
- Page 8 Kamasa Tools is a registered trademark of KG Knutsson AB, 191 81 Sollentuna, Sweden CE declaration for this product is available as a file on www.kamasatools.com K 9836 www.kamasatools.com...
