AMS ALPHA 4000 Series Installation Manual

Wireless data receiver

Advertisement

ALPHA
Wireless
Data Receiver
Installation
Manual
for use with the
ALPHA 215, Big Dot®, 4000 Series, 7000 Series, and 300 Series
Electronic Message Centers

Table of Contents

Installation Instructions ...............................................1
ALPHA 215 .......................................................2
ALPHA Big Dot®..............................................5
ALPHA 4000 Series.........................................8
© 1996 Adaptive Micro Systems
ALPHA 7000 Series.......................................12
Form No. 9708-8080
ALPHA 300 Series .........................................16
8/26/96

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALPHA 4000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMS ALPHA 4000 Series

  • Page 1: Table Of Contents

    ALPHA 215, Big Dot®, 4000 Series, 7000 Series, and 300 Series Electronic Message Centers Table of Contents Installation Instructions ..........1 ALPHA 215 ............2 ALPHA Big Dot®..........5 ALPHA 4000 Series.........8 © 1996 Adaptive Micro Systems ALPHA 7000 Series........12 Form No. 9708-8080 ALPHA 300 Series .........16 8/26/96...
  • Page 2 NOTE: Due to continuing product innovation, specifications in this document are subject to change without notice. Copyright © 1996 Adaptive Micro Systems, Inc. All rights reserved. Trademarked names appear throughout this document. Rather than list the names and entities that own the trademarks or insert a trademark symbol with each mention of the trademarked name, the publisher states that it is using the names for editorial purposes and to the benefit of the trademark owner with no intention of improperly using the trademark.
  • Page 3: Installation Instructions

    Velcro strips (Optional. For flush wall mount where applicable. Not pictured below.) 3-foot Extender Cable (Optional use. Not pictured below. Used to connect the Data Receiver to an ALPHA 4000 Series or 7000 Series sign when wall mounting either of these signs.) Modular Plug (Optional use.
  • Page 4 Note: If you’re using an ALPHA Big Dot® sign, go to page 5. If you’re using an ALPHA 4000 Series sign, go to page 8. If you’re using an ALPHA 7000 Series sign, go to page 12. If you’re using an ALPHA 300 Series sign, go to page 16.
  • Page 5: Alpha 215

    ALPHA™ Wireless Data Receiver Installation Manual ALPHA 215 Data Receiver Setup (continued) Step 4: Get the Jumper from your Data Receiver Kit. The Jumper top Jumper (right) is a small dark piece of plastic. Jumper bottom When installing the Jumper, be careful not to drop it inside the ALPHA 215 case. STOP If the Jumper falls inside, service may be required to remove it.
  • Page 6 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 215 News Service Setup (continued) Step 6: Insert the Data Receiver cable plug into the Receiver Cable RS232 Port on the back of the sign. Then place the cable in the Cable Groove: Figure 5: Completed installation.
  • Page 7 Note: If you’re using an ALPHA 215 sign, go to page 2. If you’re using an ALPHA 4000 Series sign, go to page 8. If you’re using an ALPHA 7000 Series sign, go to page 12. If you’re using an ALPHA 300 Series sign, go to page 16.
  • Page 8: Alpha Big Dot

    ALPHA™ Wireless Data Receiver Installation Manual ALPHA Big Dot® Data Receiver Setup (continued) Step 4: Get the Jumper from your Data Receiver Kit. The Jumper top Jumper (right) is a small dark piece of plastic. Jumper bottom When installing the Jumper, be careful not to drop it inside the ALPHA Big Dot® STOP case.
  • Page 9 ALPHA™ Wireless Data Receiver Installation Manual ALPHA Big Dot® Data Receiver Setup (continued) Step 6: Insert the Data Receiver cable plug into the left Receiver Cable port on the back of the sign. Then place the cable in the Cable Groove: Figure 9: Completed installation.
  • Page 10: Alpha 4000 Series

    Step 2: Remove the Access Cover located on the side of the unit, by grasping the Front Tab and sliding the Access Cover off: Access ALPHA Cover 4000 Series Front Tab Communication Ports Power supply Figure 10: ALPHA 4000 Series sign (front & back). Figure 11: Access Cover removal.
  • Page 11 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 4000 Series Data Receiver Setup (continued) Step 3: After removing the Access Cover, find the Two-Prong Receptacle located at the bottom of the EPROM: EPROM Two-Prong Receptacle Three-Prong Receptacle Figure 12: The compartment under the Access Cover.
  • Page 12 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 4000 Series Data Receiver Setup (continued) Step 6: Next, find the Three-Prong Receptacle located below the Two-Prong Receptacle. If the existing jumper is not on the leftmost two pins (for RS232), then remove the...
  • Page 13 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 4000 Series Data Receiver Setup (continued) Step 7: Insert the Data Receiver cable into the bottom Communication Port—the RS232 port—on the back of the sign: Insert Receiver cable plug into the bottom RS232 port (as shown here) Figure 15: Data Receiver cable installation.
  • Page 14: Alpha 7000 Series

    If you’re using an ALPHA 215 sign, go to page 2. If you’re using an ALPHA Big Dot® sign, go to page 5. If you’re using an ALPHA 4000 Series sign, go to page 8. If you’re using an ALPHA 300 Series sign, go to page 16.
  • Page 15 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 7000 Series Data Receiver Setup (continued) Step 3: After removing the Access Cover, find the Two-Prong Receptacle located at the bottom of the EPROM: EPROM Two-Prong Receptacle Three-Prong Receptacle Figure 17: The compartment under the Access Cover. Step 4: Get the Jumper from your Data Receiver Kit.
  • Page 16 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 7000 Series Data Receiver Setup (continued) Step 6: Next, find the Three-Prong Receptacle located below the Two-Prong Receptacle. If the existing jumper is not on the leftmost two pins (for RS232), then remove the jumper and place it over these two pins: Jumper Make sure the Three-Prong...
  • Page 17 ALPHA™ Wireless Data Receiver Installation Manual ALPHA 7000 Series Data Receiver Setup (continued) Step 7: Insert the Data Receiver cable into the bottom Communication Port—the RS232 port—on the back of the sign: Insert Receiver cable plug into the bottom RS232 port (as shown here) Figure 20: Data Receiver cable installation.
  • Page 18: Alpha 300 Series

    If you’re using an ALPHA 215 sign, go to page 2 If you’re using an ALPHA Big Dot® sign, go to page 5. If you’re using an ALPHA 4000 Series sign, go to page 8. If you’re using an ALPHA 7000 Series sign, go to page 12.
