i4Home i4H-XSW-01 Manual

Introduction:

i4H-XSW-01 Remote Switch works with i4Home Management System i4H-LS-20; it receives the On/Off
command from the Base Unit to control the power of appliance or light. Each i4H-XSW-01 can be
assigned as switch #1 to #8.
Since the command is broadcasted to all the switches, if necessary user can assign several i4H-XSW-01s
to the same switch number and control them simultaneously.

Button and Indications

Button: Local On/Off control and code learning.
Buzzer: Switch On: 2 short beeps,
Switch Off: One long beep.
Code Learning: continuous short beeps for 30 sec.
LED: Continuous on when switch on.
Flash when switch off and code learning

Operation:

* Code learning:
1, Press the button for 5 Sec. (Beeper sounds and the Operation LED flashes).
2, Select the switch number that will be assigned to the switch (# 1 ~# 8) from the Base Unit , cloud
web browser or Mobile App then send switch On or Off command.
3, If the XSW-01 receives valid command within 30 sec. then the code learning is successful.
* Remote operation: After successful code learning the i4H-XSW-01 can be controlled by the Base Unit
Remotely.
* Local operation: Press the button momentary to toggle the switch On and Off.
Note: 1, RF switch #8 is for IPCam control. Switch off when entering into "Disarm" and "Home"
mode, switch on when entering into "Away" mode automatically for i4H-LS-20.
2, "All Off" command doesn't work on RF switch.
Remote Control Power Switch, i4H-XSW-01
i4H-XSW-01F (Type F)
On/Off/Enroll
Button
Beeper
LED
5
