Summary of Contents for SANKO SK-2200
Page 1
NEEDLE & IRON PIECE DETECTOR SK−2200 (WIDE SPAN TYPE) INSTRUCTION MANUAL CAUTION ● Before using the Detector, read this INSTRUCTION MANUAL thoroughly for correct use. ● Keep this INSTRUCTION MANUAL carefully and refer to it when necessary. ● In the event of any doubt arising, the original INSTRUCTION MANUAL in Japanese is to be final authority.
CONTENTS ITEM PAGE CAUTIONS IN OPERATION 1.OUTLINE 2.PRINCIPLE 3.FEATURES 4.APPLICATIONS 5.SPECIFICATIONS 6.NAME OF PARTS AND FUNCTIONS 6‑1 Main body (Front view) 6‑2 Main body (Rear view) 6‑3 Probe 7.SPECIFICATIONS OF MULTI-CHANNEL SYSTEM 8.INSTALLATION 8‑1 Power source 8‑2 Frame 8‑3 Installing position of the probe 8‑4 Installing position of the probe cable and the main body 8‑5 Accessories &...
CAUTIONS IN OPERATION ● Before using the Detector, read this INSTRUCTION MANUAL thoroughly for correct and safety use. ● Keep this INSTRUCTION MANUAL carefully and refer to it when necessary. ● The Detector helps to simplify and to raise efficiency of detecting/inspecting work of iron needles and broken needles straying in sewn garments.
1.OUTLINE SANKO NEEDLE & IRON PIECE DETECTOR SK-2200 is the Detector for detecting iron needles, nails and broken pieces etc. straying in various kinds of textile products and industrial products by means of the ultrahigh sensitive sensor and the circuit assembled.
5.SPECIFICATIONS ● Model Needle & Iron Piece Detector SK-2200 ● Method Magnetic induction ● Alarm device Electronic buzzer, LED lamp ● Alarm output No-voltage contact output (With hold reset function) Contact capacity AC 250V, DC 125V, 5A (Peak value) ● Detectable object Iron needles and iron pieces straying in sewn products and textile etc.
6.NAME OF PARTS AND FUNCTIONS 6‑1 Main body (Front view) ①Power source lamp ・The lamp will go on when the power source switch ② ON. ・The lamp will go on with red color until the circuit become stable for 5 to 7 seconds. After that the color changes to green to advise us ready for detecting.
6‑2 Main body (Rear view) ⑦Receptacle of the probe connector (PROBE) ・The receptacle of the main body for connecting the cable connector ⑮ with the probe cable. ⑧Output terminal (OUTPUT, RESET, GND) ・The terminal is for connecting the no-voltage contact output, reset, GND to outside. ○...
Page 8
⑨Fuse holder (FUSE) ・The fuse holder containing the fuse (1A) ⑩Power source cord (POWER AC 100 to 240V) ・Connect the cord to the independent receptacle which differs a breaker to prevent the influence by a power source noises. ⑪Buzzer switch ・ON-OFF switch for the alarm buzzer ⑫.
6‑3 Probe Plan Front View ⑬Probe ・Move the object to be examined crosswise to a length direction. Iron pieces etc. can not be detected when the object is not moved. (Refer to 2. PRINCIPLE on page 3.) ・The speeds 30 to 50m per minute are recommended. The detection in the speeds less than these speeds is possible but the detecting sensitivity will become low.
7.SPECIFICATIONS OF THE MULTI‑ CHANNEL SYSTEM ◎ The detecting element in the probe is divided into 2 to 4 channels, and the removing time is shortened by limiting the places where the detected needles or iron pieces are straying. ◎ The alarm lamps ⑥ of the main body indicate the detected places for each channel. ◎...
8. INSTALLATION SK-2200 is the Detector to detect iron pieces applying the principle of magnetic induction. The Detector detects iron pieces which move relatively against the probe ⑬ (sensor part) in principle, so that it will react to iron-made objects nearby and work incorrectly when the probe ⑬...
8‑4. Installing position of the probe cable and the main body Vibration and swinging of the probe cable ⑭ cause malfunction. The position of the probe and the main body is ideal that they are installed as close as possible to protect them from invasion of the noise from the probe cable ⑭. Note: Even if in this case, keep a distance more than 1m at least.
9.OPERATING INSTRUCTIONS The Detector is provided with the no-voltage contact output function and hold・reset functions built-in to control external lines. ◆ No-voltage contact output This no-voltage contact output signal converts the power source of the motor and the marker in external lines to ON or OFF.
9‑1. Operating method Ⅰ [In case the Detector is used without no‑voltage contact output・hold function] Operations Cautions 1 Confirm both power source switch ② OFF and hold switch ④ OFF. 2 Following the previous item 8. INSTALLATION ・Connect the same numbered probe after on page 10, correctly install the main body and confirming the number of the main body.
Page 15
7 Commencing the detecting work. ・After confirming the detecting ability ・Objects to be inspected must be moved according to previous item 6, operate the ・The alarm lamp ⑥ will keep on going on under Detector for detection (needle detection) hold switch ④ ON condition. moving the objects to be measured.
9‑2. Operating method Ⅱ [In case the Detector is used with no‑voltage contact output・hold function.] ● The no-voltage contact output and hold reset function are used to hold the control of the outside line ・ marking・alarm lamp etc. Operations Cautions 1 Confirm both power source switch ②...
Page 17
6 Confirming the detecting ability ◆ In case the probe is installed in line: After running the line, confirm the detecting ・Objects to be inspected must be moved. ability with the testing objects on which the samples of breaking needles and iron pieces desired to detect were stuck with tape etc.
