TRANQUIL Side Table
Dimensions
No. people Assembly Time
Width:
502 mm
Depth:
401 mm
Heigth:
495 mm
Important - Please read these instructions fully before starting assembly
If you need help damaged or missing parts, call the JDW Customer Helpline: 0871 231 2000
Assembly Instructions
Please keep for future reference
1 hr
CAT NO:
JS374
1
/ 20
Advertisement
Summary of Contents for JDW At Home TRANQUIL JS374
- Page 1 No. people Assembly Time Width: 502 mm 1 hr Depth: 401 mm Heigth: 495 mm Important - Please read these instructions fully before starting assembly If you need help damaged or missing parts, call the JDW Customer Helpline: 0871 231 2000 / 20...
- Page 2 As a raw material for making furniture, wood has no equal - from its vibrancy through its aesthetics to its many design possibilities. But the wood from which this furniture is made has even more to offer: The FSC label proves that the wood used comes from forests managed to strict ecological, social and economic standards with lasting effect.
-
Page 3: Parts List
PART LIST PARTS LIST DIMENSIONS TOP PANEL 502x401x16 LEFT SIDE PANEL 353x400x16 RIGHT SIDE PANEL 353x400x16 BOTTOM PANEL 502x401x16 SHELF 468x356x16 DRAWER FRONT 464x224x19 350x118x12 DRAWER LEFT PANEL DRAWER RIGHT PANEL 350x118x12 DRAWER BACK PANEL 419x118x12 (10) DRAWER BOTTOM 429x347x3 (11) BACK PANEL 478x363x3... -
Page 4: Hardware List
HARDWARE LIST 15x12mm 15x10mm 8x35mm 3x13mm 3.5x13mm CAM BOLT CAM LOCK CAM LOCK DOWEL SCREW SCREW 80x14mm 3x20mm 3.5x16mm 4.5x45mm HOLDER SCREW ANGLE BRACKET SCREW SCREW SLIDE ATTACH TO DRAWER BASE BACK FRONT SLIDE ATTACH TO CARCASS FRONT BACK 1x Left / 1x Right L=350 ROLLER RUNER / 20... - Page 5 HARDWARE LIST D20mm 7x50mm 70x50mm CAM LOCK COVER CONFIRMAT SLEEVE FELT PAD 4x16mm ADJUSTABLE FOOT M6 NUT M6 PLASTIC SUPPORT SCREW / 20...
- Page 6 TOP TIPS BEFORE YOU START! 1. Please check that all parts are present before you start the assembly of your furniture, as once assembled, the furniture is exempt from our home approval policy. 2. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the pats required for that step.
- Page 7 STEP 1 15x12mm 8x35mm CAM BOLT CAM LOCK DOWEL INSERT Arrow to the edge of the part STEP 2 15x12mm 8x35mm CAM BOLT CAM LOCK DOWEL INSERT Arrow to the edge of the part / 20...
- Page 8 STEP 3 70x50mm 4x16mm PLASTIC SUPPORT FELT PAD ADJUSTABLE FOOT M6 NUT M6 SCREW CAM BOLT Q, R, S, T, U Q, R, S, T, U Q, R, S, T, U Q, R, S, T, U / 20...
- Page 9 STEP 4 CAM BOLT STEP 5 15x12mm 3.5x13mm 80x14mm CAM LOCK SCREW / 20...
- Page 10 STEP 6 15x10mm CAM LOCK STEP 7 CAM BOLT / 20...
- Page 11 STEP 8 7x50mm CONFIRMAT STEP 9 7x50mm CONFIRMAT / 20...
- Page 12 STEP 10 STEP 11 1/2 turn / 20...
- Page 13 STEP 12 D20mm CAM LOCK COVER SLIDE STEP 13 Left / Right 3x13mm L=350 SCREW ROLLER RUNER Right Left / 20...
- Page 14 STEP 14 1/2 turn STEP 15 1/2 turn / 20...
- Page 15 STEP 16 1/2 turn STEP 17 1x Right 3.5x13mm L=350 SCREW ROLLER RUNER / 20...
- Page 16 STEP 18 1x Left 3.5x13mm L=350 SCREW ROLLER RUNER STEP 19 / 20...
- Page 17 STEP 20 1/2 turn STEP 21 D20mm CAM LOCK COVER / 20...
- Page 18 STEP 22 3x20mm HOLDER SCREW H, I H, I H, I H, I / 20...
- Page 19 STEP 23 3.5x16mm 4.5x45mm ANGLE BRACKET SCREW SCREW Wall fixings are not supplied with this product as different wall materials require different types of fixing devices ( such as Rawl plugs used on brick work).You must use fixing devices suitable for the type of wall you intend to mount this product to.
- Page 20 STEP 24 / 20...
