Summary of Contents for Suaoki UT387B
- Page 1 UT387B Wall Detector User Manual...
- Page 2 Thank you for choosing Suaoki. UT387B is a rapid hand-held wall detector which can be used to detect metals, beams and live wires hidden in the wall (including floor and ceiling). Please read the manual carefully before use and follow the instructions.
-
Page 3: Lcd Display
Indicator Light LCD Display Screen ZOOM Button Metal Detection Button AC Wire Detection Button Mute Button Wood Detection Button Power Button Sensing Area (SENSOR) Battery Cover LCD Display [ Figure 3 ] Battery Level Mute Icon Metal Icon Wood Icon ZOOM Icon AC Wire Icon AC Electric Field Signal... -
Page 4: Operating Guidance
Operating Guidance Note: Make sure that the detection area is dry before use. If the device has gone through abrupt changes in ambient temperature, do not use it immediately and give some time for the device to adapt to the environment. Please note that the operating temperature of this device falls between 0°C to 40°C. - Page 5 button at the same time for three seconds. Then, the detector would turn off by itself to complete the manual calibration. The purpose of manual calibration is to eliminate the influence of undesirable variables around, using the current environment as a basis for comparison.
- Page 6 2)Wood detection Step 1: Take sample of the wall material Press the unit against the wall. Long press ZOOM button. The green light would be on. “ZOOM” signal and the triangular signal would disappear on screen. Signal bar and “AUTOCAL √” sign would appear on the screen.
-
Page 7: Maintenance And Cleaning
disturbance coming from other electric fields, the stronger the signal, the closer the detector gets to the live wire. Note: 1. DO NOT place your hand on the wall, which may shield the signal and interfere with detection result. 2. This product could be used to detect AC wire (110V, 50-60Hz). However, the signal would be weaker when the wire is grounded, and thus it would be more difficult to detect AC wire. -
Page 8: Waste Disposal
is found in the process of use, please contact the after-sales service. Do not disassemble and repair it by yourself. Waste Disposal Damaged detector and its accessories shall be recycled in compliance with the state environmental protection requirements. Product Specifications Maximum detection depth: ▪... -
Page 9: Package Content
Our company provides customers with warranty of 12 months from the date of purchase. Contact us For any inquiries or comments concerning our products, please send an email to support@suaoki.com, and we will respond to you as soon as possible. EN-8... - Page 10 MADE IN CHINA Web: www.suaoki.com E-mail: support@suaoki.com...
