Summary of Contents for Varioverse HDC
- Page 1 Manual...
-
Page 2: Table Of Contents
Content Varioverse™! Parts! Tippet / Line strength! Setting the Maximum Drag! Spool Change! Tuning the Minimum Drag! Disassembly! Maintenance! Retrieve Change! and for (even) more info, visit: www.varioverse.com Copyright © 2010 Chivarov. All rights reserved. -
Page 3: Varioverse
Varioverse™ Varioverse™ is an unique Drive & Drag system patented by Chivarov: EP 1993353, US 7,694,907 It allows you to safely reel and intuitively control the drag force by merely turning the handle. Basic Operation When you reel-in against the fish pull, the drag increases simultaneously. -
Page 4: Parts
Parts or visit www.varioverse.com/pdf/hdc_parts_en.pdf... -
Page 5: Tippet / Line Strength
Tippet / Line strength Our testing has revealed that the advertised tippet/line strength is often not equal to the actual strength under fishing conditions. It depends on such factors like aging, weathering (incl. exposure to UV-light), knots, amount of impulse and steady stress during a fight. -
Page 6: Setting The Maximum Drag
Setting the Maximum Drag The maximum drag is to be set before fishing in order to protect your tackle during a fight. Therefore it should be set corresponding to your weakest tackle component, whether tippet or line. For setting the maximum drag proceed according to the following steps: Turn the Handle (25) fully back and hold it together with the Spool (21) and Frame (1) - Page 7 Hold the Spool and Frame together with one hand and turn the Handle forward with the other hand until you hear a *click* which means you have reached the maximum drag; then pull line out of the Spool or turn the Spool backwards by hand, while holding the Frame with the other hand in order to test if the pre-setting meets your...
-
Page 8: Spool Change
Spool Change To remove and change the Spool: Turn the Handle (25) fully back and unscrew the Wheel (19) until it slightly abuts the Frame (1). Push & turn the Handle backward while holding the Spool (21) and Frame together so as to unlock the Handle, then slip the Handle and Spool out from the Hub (9). -
Page 9: Tuning The Minimum Drag
Tuning the Minimum Drag Hub Pin screw The preferred minimum drag may change, depending on the stripping drag preference. There is an easy way to tune that: Remove the Handle (25) and Spool (21). (see Steps 1 and 2 in Spool Change) The Hub Pin (10) has two more possible... -
Page 10: Disassembly
Disassembly No tools, just your hands and a few seconds: Remove the Handle (25) and Spool (21). (see Steps 1 and 2 in Spool Change) Click-out the Drag Unit (9-20) from the frame axle by pressing it with your thumbs from the frame side. -
Page 11: Maintenance
Maintenance The HDC Varioverse does not require much maintenance. Just keeping the reel clean is enough, but rinsing Clutch it after use is recommendable. After saltwater use it is advisable to clean the reel with more care. Brake it down into its parts, then rinse all, except for: •... -
Page 12: Retrieve Change
Retrieve Change Left? Right? Whatever, you can do it in seconds: Remove the Handle (25) and Spool (21). (see Steps 1 and 2 in Spool Change) Then unscrew the Cap (28), pull out the Sleeve (26) and turn it around; put the Cap back in order to fix the Sleeve in its position.
