MAKS WDC mini Quick Start Manual

WIRELESS MAGNETIC CONTACT SENSOR
• available in three colors
• secure two-way radio communication with MAKS PRO
• 868,0 ... 868.6MHz, several channels for
redundancy, range up to 2000 m
• power - lithium battery CR2, up to 5 years of operation
• easy and fast installation
• secure fastening
• efficient on metal doors
• miniature sensor
Security point magnetic contact radio channel detector (sensor) is
designed to monitor the status of structural elements (open/move)
in order to detect an attempt to enter the room. The device sends
an alarm notification to the alarm center MAKS PRO security alarm
system.
Mounted indoors and used to protect doors and windows.
Radio communication
The detector transceiver operates in several channels of
868.0 ... 868.6 MHz band for redundancy.
Secure two-way radio communication.
Distance - up to 2000 m in the open space.
Three grades of power, maximum - up to 20 mW.
Setting up
The detector operates only with the MAKS PRO wireless security
system center, connection to other systems is not provided.
The sensor is connected to the security center and
is configured using the MAKS Setup mobile application.
Batteries
The device uses an CR2 battery (included)
For more information on setting up and operating
the device, please visit www.maks.systems
Characteristics
Reed switch threshold
Maximum number of actuations
ISM wireless interface, up to 2000 m
Power
(lithium battery included)
standby consumption
transmission consumption
service life of battery
Electromagnetic field immunity
Operating temperature range
Case color
Detector dimensions
Magnet dimensions
Weight
7-15 mm
not less than 1,000,000
868,0... 868,6 MHz
CR2 battery 3V
no more than 2 µA
up to 45 mA
5 years
8 V/m
-20°C to +50°C
white, dark brown,
black
85 х 18,5 х 17,6 mm
85 х 11 х 6 mm
56 grams
