CliniMix
Lead Safe
with Universal Door 20 Bottom In & Out
PRODUCT CODE:
- 101.10.70.10
TABLE OF CONTENTS
1.0
INTRODUCTION .......................................................................................................................... 1
2.0
SAFETY ....................................................................................................................................... 2
3.0
DESCRIPTION ............................................................................................................................. 2
4.0
DIMENSIONS ............................................................................................................................... 2
4.1
TECHNICAL DATA ...................................................................................................................... 3
4.2
FLOW SIZING GRAPH ................................................................................................................ 3
5.0
WATER SUPPLY CONDITIONS ................................................................................................. 4
5.1
INTRODUCTION .......................................................................................................................... 4
5.2
SUPPLY PRESSURE REQUIREMENTS .................................................................................... 4
6.0
INSTALLATION ........................................................................................................................... 5
7.0
COMMISSIONING ....................................................................................................................... 6
8.0
MAINTENANCE AND SERVICING ............................................................................................. 7
9.0
DISINFECTION .......................................................................................................................... 10
10.0
WARRANTY ........................................................................................................................... 11
11.0
TROUBLESHOOTING ........................................................................................................... 12
12.0
APPENDIX ............................................................................................................................. 13
1.0
INTRODUCTION
−
®
CliniMix
Thermostatic Mixing Valve Cabinets are designed to protect users from scalding or cold water
shock by providing tempered water to the desired outlets.
−
This stainless steel hinged cabinet kit is a lockable cabinet with 20mm copper fittings (2 in and 1 out), which
allows secure installation and safe, simple maintenance of thermostatic mixing valve.
−
Flat faced connections allow removal of the valve without disturbing the pipework.
−
In the event of either hot or cold water supply failure the valve will shut down.
−
Suitable for installation in low pressure systems and will operate with a working pressure as low as 20kPa.
−
Units come complete with right angle isolating ball valve, non-return valve and strainer assemblies.
−
Can be installed in any configuration with the water outlet in the horizontal or vertical position, and inlet
connections can be rotated to suit inlet pipework.
−
Complies with the requirements of AS/NZS 4032.1 - Thermostatic Mixing Valves.
TM
TMV SS Cabinet Assembly
Version 1, 15 June 2020, 1 of 16
