CODAN Argus 718V Infusion Pump
End User Workbook &
Competency Assessment
A Step By Step Training Module
NAME: ..............................................
SOUTHERN HEALTH Workbook 718V, Rev 01, Nov 2018 User Manual: 14.547_G_UM_en_A71XV_5.09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Argus 718V and is the answer not in the manual?

Questions and answers

Summary of Contents for Codan Argus 718V

  • Page 1 CODAN Argus 718V Infusion Pump End User Workbook & Competency Assessment A Step By Step Training Module NAME: ..........SOUTHERN HEALTH Workbook 718V, Rev 01, Nov 2018 User Manual: 14.547_G_UM_en_A71XV_5.09...
  • Page 2 To the CODAN Argus 718V Infusion Pump Step by Step Training Module Each page is designed to give you a step by step guide to the CODAN Argus 718V. Work through the book at your own pace. When you are happy that you have sufficient skill required to perform the instructions on each page please initial where indicated.
  • Page 3 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision CODAN Argus 718V Infusion Device Training Module Index Page External Features of the CODAN Argus 718V Infusion Pump Menu Overview Key Functions Options Operating Symbols Standard Operation...
  • Page 4 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 1. External features of the CODAN Argus 718V ♦ User Aim – To become familiar with CODAN Argus 718V external features Front Indicator for mains operation (Battery recharge) Status lamp...
  • Page 5 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision External features of the CODAN Argus 718V ♦ User Aim – To become familiar with CODAN Argus 718V external features Rear Power connection DC connection & interface for a medical PC Nurse call Optional interfaces: RS-232 galvanic isolated;...
  • Page 6 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision External features of the CODAN Argus 718V ♦ User Aim – To become familiar with CODAN Argus 718V external features Front showing Optional Drop Detector Page 6 of 29...
  • Page 7 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision External features of the CODAN Argus 718V ♦ User Aim – To become familiar with CODAN Argus 718V external features Side Drop detector (Optional) User Initials………….. Page 7 of 29...
  • Page 8 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision External features of the CODAN Argus 718V ♦ User Aim – To become familiar with CODAN Argus 718V external features Front Open User Initials………….. Page 8 of 29...

  • Page 9: Menu Overview

    CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 2. Menu Overview ♦ User Aim – For the user to become familiar with the volumetric pump interface/display panel 2.1 Key Functions On/Off Key Switch the unit on or off.

  • Page 10: Battery Info

    CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 2. Menu Overview Options This overview describes all available menus and their sequence of availability. It is possible that not all menus listed on the pump will be activated, since this depends on the configuration settings which have been decided by the trust to best suit your needs.

  • Page 11: Pressure Setting

    CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 2. Menu Overview 2.2. Options continued ♦ Pressure Setting During operation the occlusion pressure limit can be temporarily adjusted depending on the circumstances. If the set value is exceeded, the unit triggers a pressure alarm.

  • Page 12: Operating Symbols

    CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 2. Menu Overview Operating Symbols These symbols appear on the display and describe the relevant operating status of the unit. Unit currently stopped after a restart Infusion running. The indicator lamp is green...

  • Page 13: Standard Operation

    Insert the set right across the middle of the pump ensuring the “Anti free flow clamp” is inserted correctly into its housing as shown: Close the door. Open the roller clamp. You are now ready to use the CODAN Argus 718V. User Initials………….. Page 13 of 29...
  • Page 14 Enter your total infusion time of 8 hours Your rate will automatically be calculated Press the selection key to check this Press start to begin your infusion If two values are entered the CODAN Argus 718V will REMEMBER automatically calculate the third User Initials…………..
  • Page 15 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 3. Standard Operation 3.5 Checking the Infusion Information ♦ User Aim – Demonstrate the ability to check the Infusion information Press the Info Key Row 1: Amount & time of total infusion...

  • Page 16: Alarms And Remedies

    CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 4. Alarms and Remedies 4.1 Pre-Alarms In contrast to alarms, a pre-alarm does not cause an interruption of the infusion. The message appears in the LC display by means of an icon and text and is supplemented by an...
  • Page 17 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 4.2 Alarms Each alarm situation automatically stops the ongoing infusion. An audible signal (loud, repeated whistling sound from 1 to 4 kHz according to IEC60601-1-8) and the flashing red alarm window indicate an error and must be identifiable from a distance.
  • Page 18 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 4.2 Alarms continued ♦ End of Infusion The end of the infusion has been reached This can be in terms of time and/or volume ♦ End of Battery...
  • Page 19 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 4.2 Alarms continued ♦ Technical Safety Inspection is Due Please contact your EBME / Technical service dept. ♦ Stop Pump First! The configuration determines the pump must be stopped first ♦...
  • Page 20 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 4.2 Alarms continued ♦ Insert a Set with the Correct AFF (Anti-Free-Flow) Clamp! The wrong set or a set with an “AFF” has been inserted ♦ Insert Infusion Set First! There is no giving set in the pump ♦...
  • Page 21 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 5. Competency Assessment Name: Date Attended Pump Training Day: Competency Achieved Initial Competency Revisited Assessment User Task To Be Competency Rating – Initials Achieved By: Outcome: Mentor /...
  • Page 22 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 5. Competency Assessment continued Competency Achieved Initial Competency Revisited Assessment User Task To Be Competency Rating – Initials Achieved By: Outcome: Mentor / PASS / FAIL Date...
  • Page 23 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 5. Competency Assessment continued Initial Competency Achieved Competency Revisited Assessment User Task To Be Competency Rating – Initials Achieved By: Outcome: Mentor / Date PASS / FAIL...
  • Page 24 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision 5. Competency Assessment continued Initial Competency Achieved Competency Revisited Assessment User Task To Be Competency Rating – Initials Achieved By: Outcome: Mentor / Date PASS / FAIL...
  • Page 25 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision Appendix I A Quick Guide to Cleaning Disconnect the pump from the mains before cleaning The pump must be kept clean and dry. To maintain full functionality, regular cleaning is recommended.
  • Page 26 2. Infusion Lines Only standard infusions sets with LUER lock connections (A708V/A718V: and Anti Free-Flow Clamp) which have been validated and approved by CODAN ARGUS AG are to be used. The pump must be appropriately calibrated for each type of set.

  • Page 27: Event History

    3. An error message is saved in the data log to assist in location of the error. 4. After the CODAN Argus 718V is switched off, but also after a complete power outage, the setting parameters are preserved for a limited time.
  • Page 28 Med DB (Drug Error Reduction software) The CODAN Argus 718V contains a simple drug library which holds a maximum of 256 drugs. Each library can be filtered for each ward/area. This can be advanced further to include dose calculation and full Drug Error Reduction software.
  • Page 29 CODAN Infusion device training module & competency assessment Quality · Reliability · Precision Appendix IV Useful Websites CODAN: www.codan.de CODAN Argus: www.codanargus.com The British Association of Critical Care Nurses: www.baccn.org.uk The Department of Health: www.dh.gov.uk The Health Protection Agency (HPA): The Medical and Healthcare products Regulatory Agency: www.mhra.gov.uk...
