- Page 1 Toll Free 800-365-6060 WWW.AISINTERFACE.COM TECH SUPPORT 833-AIS-TECH LRMOD1 REAR CAMERA INTERFACE FOR SELECT LAND ROVER...
- Page 2 VIDEO IN MOTION • Operation voltage 10.5 – 14.8V • Stand-by power drain <2mA Parts inside the box • Operation power drain ~60mA • Power consumption ~0,08W • Temperature range -30°C to +80°C • Weight 44g TECH SUPPORT 833-AIS-TECH WWW.AISINTERFACE.COM...
- Page 3 1.Connect female 8pin Molex connector of harness to male 8pin Molex connector of CANbox. 2.Transfer female system-connector of vehicle harness from rear of radio module into male system-connector of harness. 3 Plug female system-connector of into male socket on the rear of radio module. WWW.AISINTERFACE.COM TECH SUPPORT 833-AIS-TECH...
- Page 4 6pin connector. Use red front is to lock the pins in the connect- Connect female grey-red 6pin connector to 6pin male port of the monitor. Connect the video RCA of the rear-view camera to female RCA con- nector of adapter CAB-LR10-R. TECH SUPPORT 833-AIS-TECH...
