Summary of Contents for Fabco Power-Mite 110
- Page 1 POWER POWER MITE MITE ® ® INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS 10918 The Originators of Belt Driven & Hydraulically Powered AC Generators The Originators of Belt Driven & Hydraulically Powered AC Generators MANUAL 102-11 MANUAL 102-11...
-
Page 3: Table Of Contents
9) REPLACEMENT PARTS ....9 10) OPTIONAL VOLTAGE REGULATOR ..10 11) OTHER FABCO POWER PRODUCTS ..12... -
Page 4: Introduction
INTRODUCTION The Power-Mite 110 and P/M/ 220 AC Electric Generator is a unique ® miniature power source that mounts easily on any gasoline or diesel engine. The Power-Mite provides AC power whenever and wherever ® you need it. For over 50 years the Power-Mite™ 110 has proven to be a reliable, miniature heavy-duty power source. -
Page 5: Mounting
MOUNTING The Installation Must Be Performed By A Qualified Mechanic using the standard mounting hardware supplied. The installer should figure how to use the component parts furnished with the unit before attempting the installation. (REFER TO THE ILLUSTRATIONS ENCLOSED IN THIS MANUAL FOR PART DESCRIPTIONS AND IDENTIFICATION) NOTE: ONLY USE ONE BELT TO DRIVE THE POWER-MITE GENERATOR. - Page 6 Mounting to the engine permits the generator to become an integral part of the driving engine, isolated from the engines’ floating mounts. This precaution does not include the throttle or control panel, these may be placed in the most convenient and accessible places. The Power-Mite generator is supplied with a double groove pulley for ®...
-
Page 7: Control Panel Wiring
CONTROL PANEL WIRING SEE PAGE # 10 FOR OPTIONAL VOLTAGE REGULATOR The AC generator control panel furnished is used for control and monitoring for the AC generator. The Power Panel has two double AC grounding type receptacles and a voltmeter which monitors the AC output voltage. -
Page 8: Initial Start Up And Operation
BLACK CONTROL BOX WHITE GREEN Connect Red wire from switch to positive of the Power Mite™ battery.(+) Generator FIGURE 1 INITIAL START UP AND OPERATION PROCEDURE Every AC generator has been thoroughly tested and inspected before it leaves the factory. Only a minimum of service is necessary for the AC generator to give years of satisfactory power output. -
Page 9: Frequently Asked Questions
ANSWERS TO SOME FREQUENTLY ASKED QUESTIONS Can I operate a three phase motor? ANS: No, only single phase motors up to 1 horse power. Will it charge a battery? ANS: No. AC POWER cannot be used to charge a battery, however it will operate a 120 VAC input DC battery charger. -
Page 10: Operation
OPERATION Start engine, switch Power-Mite on, adjust speed control for nee- ® dle in “HIGH GREEN” area, and keep in green, readjust engine speed if necessary. Turn off Power-Mite before shutting engine ® off. Never leave switch in the “on” position when engine is not running. -
Page 12: Replacement Parts
REPLACEMENT PARTS PART # DESCRIPTION QUANTITY 572024 Housing 572025 End Plate MP-2 572026 End Plate MP-1 572027 Field Poles 572028 Field Pole screws 572029 Field Coils 572030 Brush Holder 572031 Brushes 572032 Brush Holder Caps 572033 Armature w/Slip Rings 572198 Armature/Blue Max 572236 Armature 220 Volt... -
Page 13: Optional Voltage Regulator
572054 Dual Receptacle 120 VAG Dual Receptacle 120 VAG 572341 Twist Lock Receptacle 240 VAC 572345 Pulley 3” Single Groove 572055 Lamp Assembly 572056 Complete Control Panel 572259 Complete Control Panel W GFI 572057 Control Box shell 572058 Adjustable Arm Bracket 572074 Circuit Breaker (OVERLOAD) 572020... - Page 14 220 VAC outputs when used with the corresponding Power- Mite generator models ask your local dealer. ® WARRANTY TERMS EACH FABCO POWER GENERATOR IS WARRANTED TO THE ORIGINAL OWNER TO BE FREE FROM DEFECTS IN MATERIAL OR WORKMANSHIP UNDER NORMAL USE AND SERVICE FOR ONE (1) YEAR FROM THE DATE OF PURCHASE.
-
Page 15: Other Fabco Power Products
OTHER INNOVATIVE FABCO POWER PRODUCTS Fabco Power manufactures a full line of VEHICLE MOUNTED hydraulic powered generators from 3,000 to 12,000 watts. The hydraulic driven gener- ators are used in many industries where reliable portable electric power is needed such as Telephone & Utilities, Fire &... - Page 17 Fabco Power • 1570 Kings Highway • Chester, NY 10918 Fabco Power • 1570 Kings Highway • Chester, NY 10918 tel: (845) 469-9151 • fax: (845) 469-7871 tel: (845) 469-9151 • fax: (845) 469-7871 The Ori To view all Fabco Power's innovative products To view all Fabco Power's innovative products visit our web site at www.fabcopower.com...
- Page 18 Fabco Power PO Box 582 Chester NY 10918 845-469-9151 www.fabcopower.com GFCI GENERAL INFORMATION The Powermite 110 belt-driven generator system was introduced in 1962. Over the years there have been questions about using it in conjunction with Ground Fault Current Interrupters, also known as GFI’s or GFCI’s. In a residential or industrial setting, there are the three conductors in a standard 120 volt electric outlet (240 volts in most countries outside the US) HOT, NEUTRAL and GROUND. The ground terminal is affixed to a water main and/or a ground rod. The hot and neutral provide the 120 volt power to home appliances. The neutral line is tied to the ground at only ONE POINT inside the circuit breaker panel.
